LG LSBF018-GDL – LSBF DVLED P1.8 TAA L Mitre Cut Indoor Cabinet 600Nit 1200x675x72

Product Overview

The LG LSBF DVLED P1.8 L Mitre Cut indoor LED cabinet is a direct-view LED cabinet designed as the left-side edge panel in angled video wall configurations. With a 1.88mm pixel pitch and 600-nit brightness, this cabinet provides clear imagery at viewing distances from approximately 6–9 feet. The left mitre-cut edge allows a clean angled join when the display turns a corner or meets an adjacent surface at an angle, and the cabinet integrates with standard LSBF flat-panel arrays. TAA compliant for government and institutional AV procurement.

Product Description

The L mitre-cut cabinet is used as the left-side termination panel when a flat video wall transitions around a corner. In practice, this means the left edge of the display cabinet is cut at a precise angle so that when paired with the adjacent wall surface or an R mitre-cut cabinet, the two panels meet cleanly without a visible gap at the corner. This is a common requirement in corporate lobby installations, retail environments, and hospitality spaces where the display must wrap a room corner.

The LSBF series incorporates signal detection status indicators and a diagnostic check button in the main frame structure. Both features are accessible from the front and rear of the installed unit, enabling field technicians to check cabinet status without requiring full access behind the display. Front serviceability enables individual LED module replacement from the front face of the display without dismounting the cabinet.

At 1200 x 675mm with a 16:9 aspect ratio and 600 nits of brightness, this cabinet is well-matched to a wide range of controlled indoor environments including boardrooms, auditoriums, command centers, and house of worship stage displays.

Key Features

• 1.88mm Pixel Pitch — Appropriate for indoor viewing distances from approximately 6 feet.
• L Mitre Cut Edge — Precision left-side angled edge for clean corner joins in angled display configurations.
• 600-Nit Brightness — Calibrated for controlled indoor lighting environments.
• Signal Detection Status Indicator — Integrated in the cabinet frame, accessible from front and rear.
• Dual-Access Diagnostic Check Button — Reachable from both sides of the installed cabinet.
• Front Serviceability — LED module replacement from the front face without cabinet dismounting.
• Durable Frame Construction — Commercial-grade build for permanent installation.
• TAA Compliant — Eligible for government and federally funded procurement.

Typical Applications

• Corporate lobby corner-wrap video walls
• Boardroom and conference room angled display panels
• Retail and hospitality corner digital signage
• Command center multi-surface display arrays
• House of worship stage corner screen transitions
• Broadcast studio angled background configurations
• Auditorium side-wall panel extensions

Technical Specifications

Frequently Asked Questions

When do I use the L Mitre Cut versus the R Mitre Cut variant?

Use the L mitre-cut cabinet as the left termination panel when your display turns a corner to the left. Use the R mitre-cut for a right corner transition. In a full 90-degree corner display, you typically need one of each.

Does this cabinet work with flat LSBF P1.8 cabinets?

Yes. Mitre-cut and flat LSBF cabinets share the same depth and grid dimensions and can be installed together in the same array.

Can modules be serviced from the front?

Yes, the LSBF series supports front-access module replacement without removing the cabinet from the wall structure.

Is an LED video processor required?

Yes. A compatible LED controller or video processor is required to distribute signal across the cabinet array. Contact Creation Networks for guidance on compatible systems.

Is the LSBF018-GDL TAA compliant?

Yes, this cabinet carries TAA compliance for government, education, and federally funded AV applications.
