LG LSAP007-N2 – DVLED, P0.78, 768x432 resolution, Signal+Power Redundancy, Main Bottom

Product Overview

The LG LSAP007-N2 is the main bottom cabinet of a direct view LED system featuring a 0.78mm pixel pitch, delivering a native resolution of 768 x 432 pixels per cabinet. Designed for high-availability commercial AV environments, this cabinet incorporates both signal and power redundancy, ensuring continuous operation in mission-critical applications such as control rooms, command centers, and broadcast facilities. Dual-voltage AC input (120V/230V) supports deployment across North American and international installations. As the main bottom cabinet in the LSAP007 series, the LSAP007-N2 serves as the foundational unit for vertically stacked direct view LED configurations.

Product Description

The LSAP007-N2 main bottom cabinet is engineered for commercial and mission-critical direct view LED deployments where system uptime is a non-negotiable requirement. The combination of signal redundancy and power redundancy addresses the two most common failure modes in direct view LED installations, providing a failsafe architecture appropriate for control rooms, network operations centers, broadcast studios, and 24/7 operational environments.

Signal redundancy ensures that if the primary signal path is interrupted, a secondary signal path takes over without display interruption. Power redundancy provides a backup power feed that maintains display operation in the event of a primary power supply failure. Together, these features significantly reduce the risk of display downtime in environments where loss of visual information has operational or safety consequences.

The 0.78mm pixel pitch places the LSAP007-N2 in the fine-pitch category of direct view LED, producing detailed, high-resolution imagery at close viewing distances. This specification makes it appropriate for environments where viewers are stationed close to the display, such as operators at control room workstations, and where fine text, data visualization, and multi-source video content must be rendered clearly.

The 768 x 432 resolution per cabinet is the modular building block for larger array configurations. Multiple cabinets are tiled together to achieve the total display resolution required by the installation, with the LSAP007-N2 serving as the main bottom unit in vertically stacked arrangements. This modular architecture allows the system to be scaled to precise display dimensions while maintaining consistent pixel pitch across the entire array.

Dual-voltage AC input (120V/230V) provides installation flexibility for both domestic and international deployments. This is particularly relevant for organizations operating across multiple regions or for AV integrators supplying global clients who require standardized equipment specifications.

The LSAP007-N2 is a professional-grade product requiring experienced AV installation. Proper cabinet alignment, power distribution planning, signal routing, and redundancy testing are all critical steps in a successful deployment. Creation Networks provides pre-sales consultation and integration support at https://creationnetworks.net.

Key Features

• 0.78mm Pixel Pitch — Fine-pitch direct view LED resolution suitable for close-range viewing in control rooms, command centers, and broadcast environments.
• Signal Redundancy — Secondary signal path maintains display operation if the primary signal source or pathway fails, protecting against unplanned display outages.
• Power Redundancy — Backup power supply ensures continuous operation during primary power supply failures, critical for 24/7 mission-critical installations.
• Dual-Voltage AC Input (120V/230V) — Supports installation in both North American and international facilities without voltage conversion equipment.
• 768 x 432 Resolution per Cabinet — Modular resolution block for building scalable direct view LED arrays at custom sizes and aspect ratios.
• Main Bottom Cabinet Design — Functions as the primary base unit in vertically stacked LSAP007 series configurations.
• Direct View LED Technology — Delivers infinite contrast ratio, wide color gamut, and long service life without the backlighting limitations of LCD displays.
• Commercial-Grade Construction — Built for continuous operation in demanding AV environments including control rooms and broadcast facilities.

Typical Applications

• Control rooms and network operations centers requiring high-availability display infrastructure
• Broadcast studios and live production environments with 24/7 operational requirements
• Command and coordination centers in government, military, and public safety facilities
• Financial trading floors and data visualization environments
• Transportation management centers with continuous display uptime requirements
• Corporate briefing centers requiring fine-pitch direct view LED for detailed content presentation
• International installations requiring multi-voltage compatibility

Technical Specifications

Frequently Asked Questions

What does "main bottom cabinet" mean for the LSAP007-N2?

The main bottom cabinet is the lowest unit in a vertically stacked direct view LED array and contains the primary signal processing and power distribution components for the system. It anchors the configuration and is paired with extension cabinets stacked above it to build out the full display height.

How does signal redundancy work in the LSAP007-N2?

Signal redundancy provides a secondary signal input that the cabinet monitors alongside the primary input. If the primary signal is lost, the cabinet automatically switches to the secondary source, maintaining display output without operator intervention. This protects against cable failures, source device failures, and signal distribution interruptions.

What is the difference between signal redundancy and power redundancy?

Signal redundancy protects against loss of the video signal path, while power redundancy provides a backup power supply within the cabinet. Power redundancy ensures the display continues operating if the primary power supply fails, without requiring a full system restart.

Is the 0.78mm pixel pitch appropriate for my control room application?

At 0.78mm pixel pitch, this cabinet is well-suited for control room operators seated approximately 5 to 10 feet from the display who need to read fine text, monitor detailed data feeds, or view multi-source video simultaneously. The exact suitability depends on operator workstation distance and content type.

Can the LSAP007-N2 be used in an outdoor environment?

No. This cabinet is designed for indoor commercial installation. It is not rated for outdoor use. Environmental requirements including operating temperature range, humidity limits, and ventilation specifications should be confirmed in the full product datasheet.

How many extension cabinets can be stacked with the LSAP007-N2 main bottom cabinet?

The supported configuration size depends on the total power budget and signal distribution architecture of the system. Contact Creation Networks at https://creationnetworks.net to discuss the specific array size you are planning.

Does the dual-voltage input require any configuration or switching between 120V and 230V?

Auto-switching dual-voltage power supplies detect the input voltage automatically and adjust accordingly. However, the specific behavior of the LSAP007-N2 power supply should be confirmed in the product datasheet before installation in a non-standard voltage environment.
