LG LSAB012-U22 – LSAB DVLED P1.2 TAA MAGNIT COB Main Top Cabinet 800Nit 600x337.5x44.9

Product Overview

The LG MAGNIT LSAB P1.2 COB DVLED (LSAB012-U22) is a TAA-compliant direct-view LED display cabinet that serves as the Main Top unit in a modular MAGNIT LSAB video wall configuration. It delivers a 1.2mm pixel pitch with a 480x270 per-cabinet resolution using direct-view LED technology, designed to complete the upper portion of a multi-cabinet commercial display array. Consistent brightness and color characteristics across the full installed wall make it a dependable top cap for corporate, government, broadcast, and institutional AV installations. Trade Agreements Act compliance makes it eligible for U.S. federal and public-sector procurement programs.

Product Description

The LSAB012-U22 completes the vertical structure of a MAGNIT LSAB P1.2 COB modular video wall by occupying the uppermost position in the cabinet stack. Designed to align precisely with companion bottom (-N22) and extension (-T22) cabinets, it maintains identical physical dimensions of 600 x 337.5 x 44.9mm for clean structural integration and a finished, flush appearance across the full assembled display. With a 1.2mm pixel pitch and 480x270 native resolution, the cabinet contributes consistently to the pixel density of the overall display, ensuring that the tiled image remains uniform from the bottom to the top of the wall without visible seams or brightness drop-off at the panel edges. Direct-view LED technology provides the core display output, with the COB (Chip on Board) construction method used throughout the LSAB series delivering a flat, durable display surface that holds up well in commercial environments with regular access or foot traffic. TAA compliance under the Trade Agreements Act qualifies this cabinet for U.S. government procurement, including GSA schedule purchases, making it a suitable component for federal agency AV installations and publicly funded facility upgrades. The combination of commercial-grade build quality, matching cabinet geometry, and TAA certification makes the LSAB012-U22 a complete and compliant finishing piece for modular MAGNIT LSAB video wall systems at the 1.2mm pitch. Integrators building large-format direct-view LED walls for government, corporate, education, or public-sector clients will find the full LSAB012 cabinet family — bottom, extension, and top — available through Creation Networks.

Key Features

• Main Top Cabinet (-U22) — Designed for the uppermost position in a MAGNIT LSAB modular video wall, completing the display array when paired with -N22 and -T22 cabinets.
• 1.2mm Pixel Pitch (P1.2) — Consistent pixel density with companion cabinets for a seamless, uniform image across the full assembled display.
• Direct View LED Technology — Provides high-quality emissive display output with deep blacks and accurate color reproduction for commercial environments.
• Chip on Board (COB) Construction — LED chips bonded directly to the PCB improve surface flatness, durability, and resistance to dust and incidental contact.
• 480x270 Cabinet Resolution — Per-cabinet pixel count enables accurate image tiling into large-format display configurations.
• Matched Cabinet Dimensions — 600 x 337.5 x 44.9mm aligns precisely with -N22 and -T22 cabinets for clean structural installation and consistent depth profile.
• TAA Compliant — Meets Trade Agreements Act requirements for U.S. federal, state, and public-sector AV procurement programs.
• Commercial-Grade Build — Engineered for continuous-duty operation in demanding institutional and commercial AV deployments.

Typical Applications

• Completion unit for government and military operations center video walls
• Corporate boardroom and executive conference room large-format displays
• Broadcast studio and media production display walls
• University and higher education auditorium displays
• Public-sector facility digital signage and information displays
• Hospitality feature wall and lobby digital signage
• Network operations center and security monitoring display systems

Technical Specifications

Frequently Asked Questions

What does the -U22 suffix indicate?

The -U suffix designates this as the Main Top cabinet in the MAGNIT LSAB modular system. It is installed in the uppermost position of the video wall assembly, completing the display above the -N22 (bottom) and any -T22 (extension) cabinets in the stack.

Is this cabinet compatible with the LSAB012-N22 and LSAB012-T22?

Yes. The LSAB012-U22 is designed as part of the same MAGNIT LSAB P1.2 COB series and shares identical physical dimensions with the -N22 and -T22 cabinets, ensuring precise alignment and a consistent appearance across the full assembled video wall.

Does the top cabinet require different mounting hardware than the bottom or extension cabinets?

The LSAB012-U22 shares the same cabinet dimensions and mounting interface as the companion -N22 and -T22 units. Specific mounting hardware requirements should be confirmed with the installation documentation provided by LG or your AV integration partner.

Is this product TAA compliant?

Yes. The LSAB012-U22 is Trade Agreements Act (TAA) compliant, qualifying it for U.S. federal government procurement under GSA schedules and other public-sector purchasing programs.

How does COB LED construction benefit the display over time?

COB (Chip on Board) technology bonds LED elements directly to the circuit board without individual component packaging. This results in a more uniform, impact-tolerant display surface with consistent color reproduction and reduced risk of pixel-level damage from dust or physical contact during operation and maintenance.

What is the typical viewing distance for a P1.2 display?

A 1.2mm pixel pitch display is generally suitable for minimum viewing distances of approximately two to three feet, covering most professional environments including conference rooms, lobbies, and operations centers.

Where can I find the full MAGNIT LSAB P1.2 COB cabinet family?

The complete LSAB012 series including the Main Bottom (-N22) and Secondary Extension (-T22) cabinets is available at creationnetworks.net.
