LG LSAB012-T22 – LSAB DVLED P1.2 TAA MAGNIT COB Secondary Cabinet 800Nit 600x337.5x44.9

Product Overview

The LG MAGNIT LSAB P1.2 COB DVLED (LSAB012-T22) is a TAA-compliant secondary/extension direct-view LED cabinet designed to expand modular MAGNIT LSAB video wall configurations in height. Functioning as the middle or stacking extension unit in a multi-cabinet array, it shares the same 1.2mm pixel pitch, 480x270 resolution, and 1,500 nit brightness characteristics as its companion bottom and top cabinets, ensuring visual consistency across the full assembled display. Chip on Board (COB) LED technology and built-in Ethernet connectivity make it a reliable extension component for corporate, government, and commercial AV installations. Trade Agreements Act compliance supports U.S. public-sector procurement requirements.

Product Description

The LSAB012-T22 serves as the secondary or extension cabinet in the MAGNIT LSAB P1.2 COB modular video wall system, designed to stack between the main bottom (-N22) and main top (-U22) cabinets to achieve taller display configurations. Multiple -T22 units can be added to increase the vertical height of the video wall, giving integrators flexibility in building displays scaled to the architectural requirements of the installation site. With a 1.2mm pixel pitch and 480x270 cabinet resolution, this unit maintains the same pixel density as its companion cabinets, ensuring a seamless, uniform image across the full assembled wall without visible panel boundaries or brightness inconsistencies at the joins. The 1,500 nit brightness output keeps the display legible in high-ambient-light commercial environments, including lobbies, conference spaces, and open operations centers. Chip on Board (COB) LED construction eliminates exposed LED component edges, producing a more rugged, impact-tolerant display surface well-suited for environments with regular foot traffic or integrator maintenance access. Built-in Ethernet enables the cabinet to participate in networked content management and system monitoring alongside the rest of the array. At 600 x 337.5 x 44.9mm, the cabinet dimensions are consistent with the bottom and top units in the series, simplifying structural mounting and alignment during installation. TAA compliance under the Trade Agreements Act ensures this cabinet meets U.S. federal and public-sector procurement standards, making it an eligible component for government AV projects requiring fully compliant display systems.

Key Features

• Secondary/Extension Cabinet (-T22) — Designed to stack between bottom and top cabinets, allowing scalable display height in modular MAGNIT LSAB video wall configurations.
• 1.2mm Pixel Pitch (P1.2) — Matches the pixel density of companion cabinets for a seamless, uniform image across the full assembled display.
• Chip on Board (COB) LED Technology — Direct LED-to-PCB bonding improves surface flatness, impact resistance, and color consistency.
• 1,500 Nit Brightness — Maintains clear image visibility in ambient-light commercial environments across the full video wall.
• Built-in Ethernet — Supports network-based content management and remote monitoring within managed AV infrastructure.
• 480x270 Cabinet Resolution — Consistent per-cabinet pixel count enables accurate image tiling and scaling across multi-cabinet configurations.
• Uniform Cabinet Dimensions — 600 x 337.5 x 44.9mm matches companion -N22 and -U22 cabinets for precise structural alignment and clean installation.
• TAA Compliant — Meets Trade Agreements Act requirements for U.S. federal and public-sector AV procurement.

Typical Applications

• Extension units in government and military operations center video walls
• Corporate boardroom and briefing center large-format display expansion
• Broadcast studio and media production display walls
• University auditorium and large lecture hall displays
• Retail flagship and digital out-of-home large-format signage
• Airport and transit hub public information display systems
• Network operations center (NOC) and security monitoring walls

Technical Specifications

Frequently Asked Questions

What does the -T22 suffix indicate?

The -T suffix designates this as a Secondary or Extension cabinet in the MAGNIT LSAB modular system. It stacks between the Main Bottom (-N22) and Main Top (-U22) cabinets to increase the vertical height of the assembled video wall. Multiple -T22 units can be used in a single installation.

Can multiple -T22 cabinets be used in one video wall?

Yes. The -T22 extension cabinet is designed to be stacked in multiples, allowing integrators to build display walls of varying heights by adding the required number of extension units between the bottom and top cabinets.

Does this cabinet match the brightness and resolution of the bottom and top cabinets?

Yes. The LSAB012-T22 uses the same 1.2mm pixel pitch, 480x270 resolution, and 1,500 nit brightness rating as the companion -N22 and -U22 cabinets, ensuring a consistent, seamless image across the full assembled display.

How does COB technology improve the display's durability?

Chip on Board construction bonds LED chips directly to the PCB without individual component packaging, eliminating exposed edges that could be damaged by contact or contaminated by dust. This makes COB displays more rugged than traditional SMD LED alternatives in commercial and high-traffic environments.

Is the LSAB012-T22 eligible for government purchase?

Yes. This cabinet is TAA (Trade Agreements Act) compliant, qualifying it for U.S. federal procurement under GSA schedules and public-sector AV purchasing programs.

What is the physical size of this cabinet?

The LSAB012-T22 measures 600 x 337.5 x 44.9mm, matching the dimensions of the companion bottom and top cabinets for clean structural alignment during installation.

Where can I find the bottom and top cabinet models that pair with this unit?

The LSAB012-N22 (Main Bottom) and LSAB012-U22 (Main Top) companion cabinets are available at creationnetworks.net.
