LG LMPB009BANA – Gen2 MAGNIT LMPB Series DVLED, P0.93, 640x360 resolution

Product Overview

The LG Gen2 MAGNIT LMPB Series DVLED at P0.93 pixel pitch delivers a 640x360 cabinet resolution suited to premium boardroom displays, high-end broadcast environments, and large-format visualization walls. Its 0.94mm pixel pitch produces sharp, detailed imagery at close viewing distances where conventional LED products show visible pixel structure. With a 20,000:1 contrast ratio and up to 1,000 nits peak brightness, the display maintains image fidelity in both controlled and ambient-lit environments. This cabinet is designed for professional AV integrators specifying direct-view LED solutions that demand consistent color uniformity across multi-cabinet arrays.

Product Description

The Gen2 MAGNIT LMPB Series represents LG's second-generation MicroLED platform, engineered for demanding commercial AV deployments where image quality and long-term reliability are non-negotiable. The 0.94mm pixel pitch of this cabinet enables close-proximity viewing that is not achievable with standard fine-pitch LED products, making it well suited for executive boardrooms, command and control centers, and immersive visualization suites.

Each cabinet produces a native resolution of 640x360, and multiple cabinets tile together to form larger display configurations. The system supports 96 Hz, 100 Hz, and 120 Hz refresh rates, ensuring smooth motion rendering for video content, data visualization, and live feeds without perceptible flicker. The 20,000:1 contrast ratio produces deep blacks and saturated highlights that maintain visible detail across the full dynamic range of source content.

Typical brightness is rated at 500 nits for sustained operation, with a 1,000-nit peak available for HDR highlights and high-ambient environments. Uniform vivid color performance is maintained across the cabinet face, reducing the need for extensive calibration after installation. The Gen2 platform improves on first-generation MAGNIT in thermal management, module serviceability, and overall cabinet alignment tolerances, all of which reduce total cost of ownership over the display lifecycle. Integration with professional AV control systems is supported through standard interfaces expected in commercial-grade installations. Creation Networks provides pre-sales configuration support and post-sale technical assistance for MAGNIT deployments.

Key Features

• 0.94mm Pixel Pitch — Supports close-proximity viewing distances suitable for boardroom and control room installations.
• 640x360 Cabinet Resolution — High native cabinet resolution that tiles accurately into larger array configurations.
• 1,000 Nit Peak Brightness — Delivers vivid HDR highlights and maintains visibility in moderately lit rooms.
• 500 Nit Typical Brightness — Sustains calibrated output levels for extended daily operation without thermal throttling.
• 20,000:1 Contrast Ratio — Produces deep blacks alongside bright highlights for accurate image rendering.
• 96 / 100 / 120 Hz Refresh Rate — Smooth motion reproduction for video, data feeds, and live content.
• Uniform Vivid Color — Consistent color performance across the cabinet face reduces post-installation calibration time.
• Gen2 MAGNIT Platform — Second-generation MicroLED architecture with improved thermal management and module serviceability.

Typical Applications

• Executive boardrooms and C-suite conference rooms
• Command and control centers
• Broadcast studios and production environments
• High-end corporate lobbies and reception areas
• Immersive visualization and simulation suites
• Premium retail and hospitality feature displays

Technical Specifications

Frequently Asked Questions

What is the minimum recommended viewing distance for this display?

At 0.94mm pixel pitch, the recommended minimum viewing distance is approximately 1.2 to 1.5 meters, making it appropriate for boardroom and conference room settings where viewers sit relatively close to the screen.

Can multiple LMPB009BANA cabinets be tiled into a single display wall?

Yes. The LMPB series is designed for multi-cabinet tiling. Cabinets align with precision tolerances to produce a continuous image surface when configured as an array.

What refresh rates are supported?

This cabinet supports 96 Hz, 100 Hz, and 120 Hz refresh rates, selectable based on the source content and controller configuration.

What is the difference between peak and typical brightness?

Typical brightness of 500 nits is the sustained operating level for extended use. Peak brightness of 1,000 nits is available for short-duration HDR highlights and should not be used as a continuous operating point.

Is professional installation required?

Yes. MAGNIT DVLED systems require installation by a qualified AV integrator with experience in direct-view LED deployment, including structural mounting, power distribution, and controller configuration.

Does Creation Networks offer installation support?

Creation Networks provides pre-sales configuration guidance and can connect customers with qualified installation partners. Contact us at creationnetworks.net for project support.

What control system interfaces does this product support?

The MAGNIT LMPB series integrates with standard commercial AV control interfaces. Consult the LG product documentation and your system integrator for specific protocol compatibility in your installation.
