LG GSEH100-GRR 10.67mm Pixel Pitch LED Signage Display Cabinet Right Cut

Availability: Call for Availability
Availability: Direct Ship
LG Electronics SKU: GSEH100-GRR
No reviews
Price:
$16,795.00

Description

LG GSEH100-GRR Digital Signage Display - LCD - 8500 Nit

Ultra High Brightness

With a great brightness of 8,500 nits, it clearly delivers content and attracts public attention, which is the suitable display for outdoor visibility.

Quick Installation

The GSEH series is 1.5 times larger than a conventional LED cabinet, making it much easier to fit a screen of the same size.

* Normal size is 1.536 × 1.536 m except GSEH060 (1,152 × 768 mm)
* Conventional LED (e.g. GSED series) cabinet size is 1.0 × 1.0 m

Easy Maintenance

Both front and rear are supported. When rear service is required, the door itself can be removed as it is with an L-shaped hinge, which allows maintenance to be performed in a narrower space.

Compatibility with LG Software Solutions

When connected with LG's CVEA system controller, the GSEH series is compatible with LG software solutions including SuperSign CMS, LED Assistant, and ConnectedCare, which help customers operate their own business properly.

* The availability of the 'LG ConnectedCare' service differs by region, and it needs to be purchased separately. So please contact the LG sales representative in your region for more details.
* The items that can be monitored by LG ConnectedCare : Main Board (Temp., Signal Status, FPGA Ver, Ethernet Connection Status), Receiving Card (Temp., LED Power)
* Actual GUI may vary in different webOS versions.
* SuperSign CMS service needs to be purchased separately.

  • Digital Signage Display delivers a highly realistic sound and immersive visual experience thanks to the high pixel density that shows even the most subtle details
  • Experience luminescent visual images with LCD display



  • Physical Parameter

    Pixel Configuration Single SMD
    Pixel Pitch (mm) 10.67
    Module Resolution (W x H) 18 × 18
    Module Dimensions (W x H, mm) 192 × 192
    Weight per Module (kg) 0.56
    No. of Modules per Cabinet (W × H) 8 × 8
    Cabinet Resolution (W × H) 144 × 144
    Cabinet Dimensions (W × H × D, mm) 1,536 × 1,536 × 222
    Cabinet Surface Area (m²) 2.359
    Weight per Cabinet (kg/cabinet) 104.0
    Weight per Square Meter (kg/m²) 44.1
    Physical Pixel Density (pixels/m²) 8,789
    Flatness of Cabinet ±1.0 mm
    Cabinet Material Al
    Service Access Front and Rear

  • Optical Parameter

    Max. Brightness (After Calibration) 8,500 nit
    Color Temperature (K) 3,500 - 8,500
    Visual Viewing Angle (Horizontal/Vertical) 160 × 140
    Brightness Uniformity 97%
    Color Uniformity ±0.05 Cx, Cy
    Contrast Ratio 8,000 : 1
    HDR Compatibility 16 (HDR10, HDR10 Pro)

  • Electrical Parameter

    Power Consumption (W/Cabinet, Max.) 1,810
    Power Consumption (W/Cabinet, Avg.) 724
    Power Consumption (W/m², Max.) 767
    Heat Dissipation (BTU/h/Cabinet, Max.) 6,177
    Heat Dissipation (BTU/h/Cabinet, Avg.) 2,471
    Heat Dissipation (BTU/h/㎡, Max.) 2,618
    Power Supply (V) 100 to 240
    Frame Rate (Hz) 50 / 60
    Refresh Rate (Hz) 7,680

  • Operation Conditions

    LED Lifetime (Half Brightness) 100,000
    Operating Temperature (°C) -30 to +50
    Operating Humidity 0-90% RH
    IP rating Front / Rear IP65 / IP54

  • Certification

    CE / FCC / ETL

  • Environment

    RoHS, REACH

  • Controller

    CVEA

  • 90 Degree Corner Cut

    Yes

    •

    At Creartion Networks, we do everything we can to create an excellent customer experience. This includes fast shipping and easy returns.

    • Most in-stock orders placed Monday-Friday before 1PM PST ship the same day. Orders placed after 1PM will ship the next day of business. General restrictions apply; please see our full shipping policy here.
    • We offer a 30-day return policy from the delivery date on many products. Product restrictions apply. Restocking fees for the return of open-box items. Please see our full return policy here for more information.
