LG GSCD069-GR3 Essential Cabinet Outdoor 6.94MM 7000NIT 500X1000X85.1MM
LG GSCD069-GR3 Essential Cabinet Outdoor 6.94MM 7000NIT 500X1000X85.1MM is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
LG GSCD069-GR3 Essential Cabinet Outdoor 6.94MM 7000NIT 500X1000X85...
Product Overview
The LG GSCD069-GR3 is an outdoor direct-view LED cabinet in LG's GSCD Ultra Light series, built around a 6.94 mm pixel pitch and a 7,000-nit brightness rating. It uses a single-SMD configuration in a half-width 500 x 1,000 mm cabinet with an IP65-rated weatherproof design. The lightweight build reduces structural load on host structures. It is engineered for durable, daylight-readable outdoor signage.
Product Description
This half-width cabinet measures 500 mm wide by 1,000 mm high at roughly 84.4 mm depth, providing a vertical building block for tiling tall or custom-shaped walls. The 6.94 mm pitch suits the longer viewing distances common to outdoor facades, while the 7,000-nit output is tuned to compete with direct sunlight. Both the front and back of the cabinet are IP65 certified for stable operation in adverse weather. The Ultra Light design keeps cabinet weight low so large rooftop or facade screens place less load on the building. A modular control unit (PDU) attaches or detaches for easier maintenance, and the product offers a choice of front or rear serviceability. An optional 90-degree corner design supports right-angled installs, and the series is compatible with LG SuperSign CMS, LED Assistant, and ConnectedCare.
Key Features
- 6.94 mm Pixel Pitch — suited to longer outdoor viewing distances.
- 7,000-nit Brightness — high output for demanding daylight environments.
- IP65 Weatherproof — front and back certified for outdoor durability.
- Ultra Light Cabinet — reduces structural load for rooftop and facade installs.
- Half-Width Format — 500 x 1,000 mm cabinet for flexible vertical tiling.
- Modular PDU — control unit detaches for easier maintenance.
- LG Software Compatible — works with SuperSign CMS, LED Assistant, and ConnectedCare.
Typical Applications
The GSCD069-GR3 suits building facades, stadiums, transit hubs, and outdoor plazas, including bright, weather-exposed sites where IP65 protection and high brightness matter. The 90-degree corner option supports wrapped architectural installs.
Technical Specifications
| Specification | Detail |
|---|---|
| Model | GSCD069-GR3 |
| Series | GSCD Ultra Light (Outdoor DVLED) |
| Pixel Pitch | 6.94 mm |
| Brightness | 7,000 nits |
| LED Configuration | Single SMD |
| Ingress Protection | IP65 (front and back) |
| Cabinet Type | Half-Width |
| Cabinet Dimensions | 500 x 1,000 x 84.4 mm |
Specifications sourced from LG vendor data. Unlisted values are omitted rather than estimated.
Frequently Asked Questions
Is the GSCD069-GR3 weatherproof? Yes, both the front and back are IP65 certified for outdoor durability.
How bright is it? It is rated at 7,000 nits for demanding daylight environments.
What is the cabinet format? A half-width 500 x 1,000 mm cabinet for flexible vertical tiling.
What software is it compatible with? LG SuperSign CMS, LED Assistant, and ConnectedCare.
