Lenovo Legion T5 26IAB7 90SU000CUS – High-Performance AV Workstation Tower

Product Overview

The Lenovo Legion T5 26IAB7 (90SU000CUS) is a 26-liter tower workstation built on the 12th Generation Intel Core i7-12700 processor with NVIDIA GeForce RTX 3070 discrete graphics, making it well-suited for compute-intensive commercial AV workflows including digital signage content rendering, broadcast graphics production, multi-stream video processing, and AV system control workloads. With 16 GB DDR5-4800 RAM across two of four available slots, a 1 TB NVMe PCIe 4.0 SSD for fast project access, and a 1 TB HDD for media storage, this system provides the throughput required for professional content production environments. Windows 11 Pro is included.

Product Description

For AV integrators and commercial operators who need a floor-standing workstation in a broadcast studio, digital signage operations center, or content rendering environment, the Legion T5 26IAB7 delivers desktop-class GPU performance at a competitive commercial price point. The RTX 3070 (8 GB GDDR6) supports up to four independent displays via three DisplayPort 1.4a outputs and one HDMI 2.1 port, making it practical for multi-screen digital signage layouts, broadcast preview monitoring, and video wall controller applications. The Intel B660 chipset with Wi-Fi 6 (802.11ax) and Gigabit Ethernet provides dual connectivity options for networked AV environments. The tower form factor (205 x 395 x 420 mm, ~31 lbs) fits under a production desk or in a dedicated equipment area. Memory is expandable to 128 GB DDR5 across four DIMM slots, and the chassis supports up to two 3.5-inch HDDs plus two M.2 NVMe SSDs for storage scaling as project demands grow.

Key Features

• Intel Core i7-12700 (12-core, Alder Lake) — 8 performance-cores and 4 efficiency-cores deliver multi-threaded throughput for real-time video encoding, AV rendering software, and concurrent application workloads.
• NVIDIA GeForce RTX 3070 (8 GB GDDR6) — Supports up to four simultaneous display outputs (3x DP 1.4a + 1x HDMI 2.1), suitable for multi-screen digital signage layouts, broadcast preview monitoring, and content output configurations.
• DDR5-4800 Memory Platform — Higher memory bandwidth compared to DDR4 benefits video processing, composition, and real-time AV rendering workloads. Expandable to 128 GB across four DIMM slots.
• Dual-Drive Storage (NVMe PCIe 4.0 + HDD) — 1 TB PCIe 4.0 NVMe SSD delivers fast OS and application load times; 1 TB HDD provides bulk media and project file storage in the same chassis.
• Wi-Fi 6 + Gigabit Ethernet — Dual network capability allows wired connection to the production network while maintaining wireless access for management or secondary streams.
• Four-Slot M.2 + HDD Expandability — Supports up to two 3.5-inch HDDs and two M.2 NVMe SSDs, allowing storage to scale with growing digital signage content libraries or video archives.
• Windows 11 Pro — Commercial operating system with enterprise management features, BitLocker encryption, and Hyper-V virtualization support for AV control system environments.
• PCIe 4.0 x16 Expansion Slot — Available for additional capture cards, AV interface cards, or GPU upgrades as production requirements evolve.

Typical Applications

• Broadcast studio
• Digital signage content rendering workstation
• Conference room AV control workstation
• Multi-purpose room AV production
• Training room content development
