ViewSonic LDM163-182 163" All-in-One Direct View LED Display
Product Overview
The ViewSonic LDM163-182 is a 163" all-in-one direct view LED display built for mid-to-large commercial spaces where Full HD image quality and a manageable footprint are required. At 1.875mm pixel pitch with native 1920 x 1080 resolution, it provides sharp, detailed imagery at typical boardroom and conference room viewing distances of 8 feet or more. The all-in-one design incorporates power, processing, and display into a single unit with no external video wall controller required, simplifying installation and reducing ongoing system maintenance. Rated for 24/7 commercial operation, the LDM163-182 is suited for corporate lobbies, conference centers, control rooms, and any fixed installation where a large-format, high-brightness display is required continuously.
Product Description
The LDM163-182 measures 142.9" wide by 80.4" tall with a 31mm ultra-slim profile. Glue-on-Board (GOB) surface treatment encapsulates the LED array in a resin layer, providing IP54 dust and moisture resistance and increased surface durability for high-traffic environments. The display runs Android 9.0 with a quad-core RK3399 processor, 4GB DDR4 RAM, and 32GB internal storage, supporting standalone digital signage content playback and app-based workflows without a connected PC. Built-in Wi-Fi (2.4GHz/5GHz) and pre-installed vCast software provide wireless content sharing from up to four simultaneous sources via Picture-by-Picture, as well as Picture-in-Picture for secondary content windows. AirPlay and Google Cast are supported natively. LAN control integration with Crestron and ViewSonic Manager enables centralized fleet management across multi-display facilities. RS-232 serial control is also available for legacy control systems. Four HDMI 2.0 inputs with HDCP 2.2 support accommodate any current-generation video source, including 4K content downscaled to native 1080p. Dual 30W integrated speakers provide room-fill audio for presentations without a separate PA system, with S/PDIF and 3.5mm outputs for connecting to professional audio distribution equipment. The detachable control bar extends up to 10 meters from the display, simplifying ADA-compliant installations. Front-accessible hot-swap LED modules with vacuum tool enable field maintenance without rear access.
Key Features
- 163" Direct View LED at 1.875mm Pixel Pitch — Large-format display surface optimized for boardrooms, conference centers, and mid-size auditoriums with viewing distances of 8 feet or more.
- Full HD Resolution (1920 x 1080) — 1080p native resolution with 13-bit grayscale for smooth tonal transitions in video and graphics content.
- 600 Nits / 6,500:1 Contrast Ratio — High brightness suitable for mixed-light environments; 100-level brightness adjustment for precise dimming.
- GOB Surface Treatment with IP54 — Glue-on-Board resin protection against dust and moisture; appropriate for high-traffic lobbies, gymnasiums, and public spaces.
- 24/7 Commercial Operation Rating — Designed for permanent continuous-operation installations in commercial environments.
- All-in-One Architecture — Power, processing, and display integrated in a single unit; no external video wall controller required.
- Detachable Control Bar (up to 30ft) — Separates from the display up to 10 meters for ADA-compliant, clean wall installations.
- Front Hot-Swap LED Modules — Front-accessible for field replacement; auto-configures on installation using included vacuum suction tool.
- Built-in Wi-Fi + vCast Content Sharing — Wireless multi-source sharing with PBP (4 sources) and PIP; AirPlay and Google Cast supported.
- Crestron / LAN / RS-232 Control — Compatible with leading commercial AV control systems for enterprise and campus deployments.
- Dual 30W Integrated Speakers — Built-in stereo audio with S/PDIF and 3.5mm outputs for professional audio connectivity.
- Android 9.0 Embedded OS — Standalone digital signage capability; 4GB RAM, 32GB storage, compatible with network-based CMS platforms.
- 100,000-Hour LED Lifespan — Commercial-grade longevity for permanent installations with minimal maintenance intervals.
- 31mm Ultra-Slim Profile — Mounts nearly flush to the wall at 31mm depth; 53mm total with wall mount; ADA compliant.
Typical Applications
- Corporate boardrooms and conference centers
- Higher education lecture halls and auditoriums
- Corporate lobby digital signage
- Government and municipal meeting spaces
- Command and operations centers
- School gymnasiums and common areas
Technical Specifications
| Screen Size | 163" |
| Display Type | Direct View LED |
| LED Surface Treatment | Glue-on-Board (GOB) |
| Pixel Pitch | 1.875mm |
| Native Resolution | 1920 x 1080 |
| Viewable Area | 142.9" (H) x 80.4" (V) |
| Brightness | 600 nits (100-level adjustable) |
| Contrast Ratio | 6,500:1 |
| Refresh Rate | 3,840Hz |
| LED Grayscale | 13-bit |
| LED Lifetime | 100,000 hours |
| Aspect Ratio | 16:9 |
| Viewing Angles | 170° H / 170° V |
| Ingress Protection | IP54 |
| Operation Rating | 24/7 |
| Embedded OS | Android 9.0 |
| CPU | RK3399 |
| Memory | 4GB DDR4 |
| Storage | 32GB (26GB available) |
| HDMI Inputs | 4x HDMI 2.0 with HDCP 2.2 |
| HDMI Output | 1x HDMI 1.4 |
| USB | 1x USB 3.0, 1x USB 2.0, 1x USB-C |
| Ethernet (RJ45) | 3x |
| Wi-Fi | 2.4GHz / 5GHz 802.11n |
| RS-232 | 1x |
| Audio Output | 2x 3.5mm |
| Internal Speakers | 30W x 2 |
| Power Consumption (Typical) | 919W |
| Power Consumption (Max) | 2,642W |
| Operating Temperature | 0–40°C (32–104°F) |
| Physical Dimensions (WxHxD) | 142.9" x 80.4" x 1.2" (3630 x 2042 x 31mm) |
| Net Weight | 456 lbs (207 kg) |
| Warranty | 3-year limited warranty |
| Certifications | FCC, cTUVus |
Frequently Asked Questions
Q: What is the recommended minimum viewing distance for the LDM163-182?
A: With a 1.875mm pixel pitch, the minimum comfortable viewing distance is approximately 6–8 feet. Most conference room and boardroom deployments will have audience seating at 8–20 feet, placing this display well within optimal range for those environments.
Q: Does this display support content sharing from mobile devices?
A: Yes. Built-in Wi-Fi and vCast software support wireless presentation from Windows, Mac, iOS, and Android devices. AirPlay and Google Cast are natively supported without additional hardware.
Q: Can the LDM163-182 display content from multiple sources simultaneously?
A: Yes. Picture-by-Picture supports up to four independent sources displayed simultaneously in a tiled layout. Picture-in-Picture supports a secondary source overlaid on the main content.
Q: What control system integrations are supported?
A: The LDM163-182 supports Crestron control, LAN-based control via IP, and RS-232 serial control. ViewSonic Manager provides cloud-based remote management for multi-display deployments.
Q: What power circuit is required for installation?
A: Typical consumption is 919W with a maximum draw of 2,642W. Verify with your electrical contractor that an appropriate dedicated circuit is available before scheduling installation.
Q: Is field service possible without removing the entire display?
A: Yes. LED modules are hot-swappable from the front using the included vacuum suction tool. Replacement modules auto-configure to their position. No rear wall access is required for routine maintenance.
