Lab Gruppen LUCIA 240/2 Compact Amplifier for Installations (2 x 120W) - LUCIA240/2

Product Overview

The Lab Gruppen LUCIA 240/2 is a 2-channel, 240W Class-D installation amplifier designed for commercial AV applications where localized amplification near the speaker load is preferred over centralized equipment rooms. Delivering 2x120W into loads from 2 to 16 ohms, this compact half-rack amplifier suits conference rooms, boardrooms, and training facilities. Its built-in DSP, auto load sense, and configuration wizard make it a practical choice for AV integrators and system designers specifying low-complexity, reliable distributed audio.

Product Description

The LUCIA 240/2 is part of Lab Gruppen's LUCIA (Localized Utility Compact Intelligent Amplifier) series, a platform built specifically for decentralized AV system architecture. Rather than routing audio from a central equipment room through long cable runs, the LUCIA 240/2 is installed near the speaker load — behind a display, at a podium, or inside a millwork enclosure — reducing infrastructure costs and simplifying signal distribution. The half-rack enclosure accommodates wall-mount deployment with the included bracket, or can be rack-mounted in pairs using the optional LUCIA-RACKKIT. The Class-D amplifier topology delivers energy-efficient operation without sacrificing audio quality. Onboard DSP includes automatic dynamic loudness contouring and auto load sense, which automatically sets the variable power limiter (VPL) based on the connected speaker load. Inputs include a balanced Euroblock screw terminal and dual RCA unbalanced inputs for source flexibility. Speaker outputs are via Euroblock screw terminals. The LUCIA 240/2 is suited for commercial-grade installations in conference rooms, training rooms, and multi-purpose spaces where a straightforward 2-channel stereo amplifier is needed without matrix routing complexity.

Key Features

• 2x120W Class-D Output — Delivers 240W total across two channels into 2, 4, 8, or 16 ohm loads with energy-efficient Class-D topology.
• Built-in DSP — Comprehensive onboard signal processing including equalization and dynamics eliminates the need for an external DSP in many installations.
• Auto Load Sense — Automatically detects the connected speaker load and sets the variable power limiter accordingly, protecting speakers without manual configuration.
• Configuration Wizard — Guided setup simplifies commissioning for integrators, reducing on-site programming time.
• Automatic Dynamic Loudness Contouring — Maintains perceived tonal balance at lower listening levels without manual EQ adjustment.
• Half-Rack Compact Enclosure — Installs behind displays, at podiums, or in millwork without requiring a dedicated equipment room; rack-mountable in pairs with optional kit.
• Balanced and Unbalanced Inputs — Accepts balanced Euroblock line-level input and dual RCA unbalanced inputs for flexible source connectivity.
• Comprehensive Circuit Protection — Includes protection against short circuit, overload, DC offset, and thermal events for reliable long-term operation.
• 10-Year Limited Warranty — Lab Gruppen's extended warranty reflects confidence in build quality for permanent installation environments.

Typical Applications

• Conference room
• Boardroom
• Training room
• Huddle room
• Multi-purpose room
• Government space
• Commercial meeting space

Technical Specifications

Frequently Asked Questions

Q: What is the difference between the LUCIA 240/2 and the LUCIA 240/2M?

A: The LUCIA 240/2 is a standard 2-channel stereo amplifier. The LUCIA 240/2M adds a 4x4 integrated mix-matrix, allowing multiple audio sources to be routed and mixed to the two output channels — useful when a room needs to switch between or blend sources such as a microphone, media player, and room conferencing system.

Q: Does the LUCIA 240/2 support 70V distributed speaker systems?

A: No. The LUCIA 240/2 is a low-impedance (Lo-Z) amplifier supporting 2, 4, 8, and 16 ohm loads. For 70V or 100V constant-voltage distributed speaker systems, use the LUCIA 240/1-70.

Q: Can the LUCIA 240/2 be rack-mounted?

A: The LUCIA 240/2 is a half-rack form factor and is not natively 1RU rack-compatible on its own. The optional Lab Gruppen LUCIA Rackmount Kit (LUCIA-RACKKIT) accepts one or two LUCIA amplifiers in a standard 19" rack bay.

Q: What inputs does the LUCIA 240/2 accept?

A: It accepts a balanced line-level signal via a 6-pin Euroblock screw terminal and two unbalanced RCA inputs, providing flexibility for both professional AV and consumer source equipment.

Q: Is external DSP required for this amplifier?

A: No. The LUCIA 240/2 includes comprehensive onboard DSP with equalization, dynamic processing, and auto load sense. For many standard installation scenarios, no external DSP is needed.

Q: How is the LUCIA 240/2 physically installed?

A: The included wall-mount bracket allows deployment behind video displays, at podiums, or in concealed locations. It can also be rack-mounted using the optional LUCIA-RACKKIT, which accommodates up to two LUCIA amplifiers in 1RU.

Q: What warranty does the LUCIA 240/2 carry?

A: Lab Gruppen provides a 10-year limited warranty on the LUCIA 240/2, making it appropriate for commercial installations with long expected service life requirements.
