Kramer VP-440H2 Compact 5-Input 4K60 4:4:4 Presentation Switcher/Scaler

Product Overview

The Kramer VP-440H2 is a compact 5-input 4K60 4:4:4 presentation switcher and scaler designed for conference rooms, training rooms, and boardrooms that need to switch between multiple HDMI and USB-C sources with integrated scaling. It accepts five inputs including HDMI and USB-C and scales them to a consistent 4K60 4:4:4 output, ensuring uniform display quality across source types. The compact form factor suits under-table, credenza, or equipment rack installation in medium-sized commercial meeting spaces.

Product Description

The VP-440H2 handles the most common conference room source types: HDMI from room equipment, USB-C from laptops, and additional HDMI for video conferencing or media sources. The integrated scaler converts each input to a consistent 4K60 4:4:4 output, maintaining full color fidelity on connected 4K displays. This is important in boardrooms and training rooms where source types vary between presenters and display compatibility must be guaranteed. RS-232 and Ethernet control allow integration with room control systems for facilities requiring centralized AV management. The compact 5-input design suits conference rooms that do not need a full matrix switcher but require more than a basic 2-input auto switcher.

Key Features

• 5 Inputs including USB-C — Accepts HDMI and USB-C inputs for both traditional and BYOD laptop connectivity.
• 4K60 4:4:4 Scaling — Built-in scaler delivers full-bandwidth 4K output for high-quality commercial display systems.
• Compact Form Factor — Suitable for under-table, credenza, or rack installation in commercial AV spaces.
• RS-232 & Ethernet Control — Room control system integration for input selection and AV management.

Typical Applications

• Conference room multi-source presentation switching and scaling
• Boardroom HDMI and USB-C input management
• Training room 5-source AV switching
• Corporate meeting space BYOD and room device integration

Technical Specifications

Frequently Asked Questions

Does USB-C support video input only or also charging?

USB-C input supports video (DisplayPort Alt Mode). Charging capability via USB-C depends on the VP-440H2’s specific USB-C power delivery specification — refer to the Kramer datasheet for confirmation.

Does it support 4K60 on all inputs?

The VP-440H2 scales all inputs to 4K60 4:4:4 output. The input signal does not need to be 4K — the scaler upconverts lower resolutions as needed.

What warranty applies?

Kramer provides a 3-year limited warranty. Contact Creation Networks for support.
