Product Overview
The Kramer TP-580RXR is an extended-reach HDBaseT receiver for 4K@60Hz (4:2:0) HDMI, bidirectional RS-232, and IR signals, supporting cable runs up to 100m at 4K or 180m at 1080p — significantly beyond the standard 40m/70m reach of the TP-580R. AV integrators specify the TP-580RXR in larger spaces, inter-floor runs, and campus buildings where the display is further from the source rack than standard HDBaseT range permits. It pairs with the TP-580TXR extended-reach transmitter for a matched extended-reach HDBaseT pair.
Key Features
- Extended-Reach HDBaseT Reception — Up to 100m at 4K@60Hz (4:2:0); up to 180m at 1080p over Cat6/7.
- Bidirectional RS-232 and IR — Full control signal pass-through on the HDBaseT link.
- HDCP Compliant — Passes protected 4K HDMI content.
- HDBaseT Certified — Compatible with any HDBaseT-compliant extended-reach transmitter.
- I-EDIDPro EDID Processing — Automatic EDID management.
Technical Specifications
| Parameter | Value |
|---|---|
| Input | 1x HDBaseT (RJ-45) |
| Output | 1x HDMI; RS-232 (bidirectional); IR |
| Max Resolution | 4K@60Hz (4:2:0) |
| System Range | Up to 100m (330ft) at 4K; up to 180m (590ft) at 1080p over Cat6/7 |
| Recommended Pair | Kramer TP-580TXR transmitter |
Frequently Asked Questions
What is the difference between TP-580R and TP-580RXR?
The TP-580R is the standard long-reach receiver: 40m at 4K, 70m at 1080p. The TP-580RXR is the extended-reach version: 100m at 4K, 180m at 1080p. Choose TP-580RXR when the cable run exceeds 40m at 4K or 70m at 1080p.
