Product Overview
The Kramer RC-74DL(G) is the grey-finish variant of the 12-button KNET and Ethernet control keypad with LCD displays and volume knob, designed for in-wall installation in conference rooms, boardrooms, and auditoriums where room aesthetics call for a neutral grey faceplate. Functionally identical to the RC-74DL(B), it delivers the same RS-232, KNET, Ethernet, IR, relay, and GPI/O control capabilities in a 3-gang US wall box form factor. AV integrators specify the grey finish for spaces where grey electrical hardware, grey wall plates, or neutral-tone room furnishings are the design standard. All programming, configuration, and control platform compatibility is shared with the full RC-74DL family.
Key Features
- 12 RGB-Backlit Buttons with LCD Labels — Three groups of four buttons, each with a dedicated 8-character LCD display for programmable labeling.
- Grey Finish Faceplate — Neutral grey color for integration with grey-toned room designs and electrical hardware.
- Volume Knob with LED Bar — Bidirectional rotary digital knob with 5-LED volume indicator.
- Ethernet + KNET + RS-232 — Connects to Site-CTRL over Ethernet, Kramer master controllers via KNET, and serial devices via 3x RS-232 ports.
- 2 IR Emitter Outputs + IR Receiver — Controls IR devices; learns commands from existing remotes.
- 4 Relay Outputs — Contact closure for projection screens, shading, and blinds.
- 3-Gang US Wall Mount — Fits standard US 3-gang in-wall junction boxes.
- K-Config Software Programming — All button logic, LCD labels, and macros configured via Kramer K-Config.
Typical Applications
- Boardroom and large conference room AV control
- Auditorium and multi-purpose room system control
- University lecture hall AV and environment management
- Government meeting chamber control interfaces
Technical Specifications
| Parameter | Value |
|---|---|
| Ports | 1x RS-485, 3x RS-232, 2x GPI/O, 2x KNET (terminal blocks); 1x Ethernet (RJ-45); 1x IR sensor; 1x mini USB |
| Outputs | 2x IR emitter; 4x relay (36V AC/DC, 2A) on terminal blocks |
| Buttons | 12 RGB-backlit with custom-labeled removable caps |
| Displays | 3x 8-character LCD, one per button group |
| Volume Knob | Bidirectional rotary with 5-LED bar |
| Power Consumption | 12V DC, 570mA |
| Mounting | In-wall, standard 3-gang US wall junction box |
| Finish | Grey |
| Operating Temperature | 0° to +40°C (32° to 104°F) |
Frequently Asked Questions
What is the difference between RC-74DL(G) and RC-74DL(B) / RC74DL(W)?
All three are functionally identical. The only difference is the faceplate finish: (B) is black, (G) is grey, and (W) is white. Choose the finish that matches the room's wall plate and electrical hardware color scheme.
Does the RC-74DL(G) require a separate power supply?
Yes. The unit runs on 12V DC, 570mA. A power supply is included. It does not support PoE — for PoE-powered keypads, see the Kramer RC-306 or RC-308 series.
Can this keypad be part of a multi-room Kramer system?
Yes. Via its Ethernet port and Kramer Site-CTRL compatibility, multiple RC-74DL units across a facility can be centrally monitored and managed. KNET connectivity also allows integration with Kramer master controllers and auxiliary keypads within the same space.
