K-Array Vyper KV52W II – Ultra-Flat White Line Array

Product Overview

The K-Array Vyper KV52W II is an ultra-flat line array speaker in a white aluminum finish, built for commercial AV installations where the loudspeaker must nearly disappear into light-colored architecture. Eight 1-inch neodymium magnet drivers in a half-meter chassis just 22 mm deep deliver 114 dB peak SPL with 10° vertical by 140° horizontal coverage, making it a low-profile white wall speaker for conference rooms, boardrooms, and distributed audio systems. Selectable 16-ohm or 64-ohm impedance allows up to sixteen elements per 4-ohm amplifier channel without 70V lines. Browse the full lineup in the K-Array collection.

Product Description

The KV52W II is the white version of K-Array's half-meter Vyper II element, a frameless precision-extruded aluminum loudspeaker designed for clean, bracketless surface mounting on any flat wall or ceiling. Its eight closely spaced 1-inch neodymium cone drivers provide true line array characteristics — phase coherence, low distortion, and focused listening in both the near field and at distance — across 150 Hz to 18 kHz for articulate speech and program audio. The tight 10° vertical beam keeps energy on the audience and off reflective ceilings and floors, while the wide 140° horizontal pattern covers broad rooms from a single slim element. Selectable 16/64-ohm impedance allows up to sixteen KV52 II loudspeakers on one 4-ohm amplifier channel at 64 ohms, eliminating 70V lines in wide distributed systems where intelligibility and elegance are both mandatory. Two-pin Euroblock connectors simplify terminations, IP65 construction supports indoor and outdoor installations with the included IP accessory, and dedicated factory presets optimize performance on K-Array amplifiers. The same element is offered in black as the Vyper KV52 II, and a recessed in-wall white version is available as the Vyper KV52RW II.

Key Features

• Ultra-Flat 22 mm Profile — At under one inch deep, the element mounts nearly flush to walls and ceilings for minimal visual impact in finished spaces.
• Architectural White Finish — The white aluminum chassis blends into light walls, millwork, and ceilings without paint or covers.
• Eight 1-Inch Neodymium Drivers — Closely spaced cones provide true line array phase coherence and focused listening in the near and far field.
• Frameless Aluminum Chassis — The precision-extruded, frameless design supports clean bracketless application on any flat surface.
• Tight 10° x 140° Coverage — A narrow vertical beam controls reflections while wide horizontal dispersion covers broad rooms from a single element.
• Selectable 16/64-Ohm Impedance — Up to sixteen elements can share one 4-ohm amplifier channel at 64 ohms, removing the need for 70V lines in distributed systems.
• IP65 Rated — With the included IP accessory the element is suitable for indoor and outdoor installations.
• Lightweight 0.8 kg Build — The element installs quickly on miniature K-Array brackets or directly on flat surfaces.
• Dedicated Amplifier Presets — Factory presets ensure optimized performance when powered by K-Array amplifiers.

Typical Applications

• Boardrooms and conference rooms requiring program audio with virtually no visible loudspeaker
• Huddle rooms and commercial meeting spaces using low-profile distributed audio
• House of worship sanctuaries and heritage interiors with white or light architectural finishes
• Government spaces such as chambers and hearing rooms with strict aesthetic requirements
• Multi-purpose rooms and training rooms with on-wall speaker placement

Technical Specifications

Frequently Asked Questions

What amplifier should power the Vyper KV52W II?

The KV52W II is a passive loudspeaker with selectable 16/64-ohm impedance. Dedicated factory presets optimize performance on K-Array amplifiers, but any professional installation amplifier with appropriate power and DSP can drive it. At 64 ohms, up to sixteen elements can share one 4-ohm amplifier channel.

Is mounting hardware included?

Mounting brackets are sold separately so each project specifies exactly what it needs. The frameless chassis also allows clean bracketless surface application on any flat surface. Creation Networks can help select the right mounting package for your installation.

How is the KV52W II different from the KV52RW II?

The KV52W II is the frameless surface-mount version, while the KV52RW II adds a complete frame and clamps for recessed in-wall mounting. Acoustic performance is the same.

Does the KV52W II need a subwoofer?

For speech, the element covers the vocal range from 150 Hz with high intelligibility on its own. For full-range music programs, K-Array recommends pairing it with a compact subwoofer.

Can it be installed outdoors?

Yes. The KV52W II is IP65 rated and suitable for indoor and outdoor installations with the included IP accessory.

What warranty applies to this product?

K-Array provides a 5-year manufacturer warranty, supported by Creation Networks as an authorized dealer. See the full range in our K-Array collection.
