K-Array Pinnacle KR402P II – Passive Stereo Line Array System

Product Overview

The K-Array Pinnacle KR402P II is a passive stereo line array system engineered for commercial AV installations that demand high output from a visually discreet footprint. The system pairs four Python KP102 I stainless steel line array elements with two Thunder KS3P I passive 21" subwoofers, all driven and processed by a single Kommander KA104 four-channel DSP amplifier. For integrators specifying a house of worship sound system, auditorium reinforcement, or a multi-purpose room audio installation, the KR402P II delivers full-range stereo coverage with the slim column profile K-Array is known for. Mounting hardware is included, so the package arrives deployment-ready for permanent installation.

Product Description

Each Python KP102 I element is a meter-long, stainless steel column loudspeaker loaded with twelve 3.15" neodymium magnet transducers. The closely spaced drivers produce the long throw and high speech intelligibility characteristic of a pure line array, with controlled 7°–30° vertical dispersion and a wide 90° horizontal pattern that keeps energy on the audience and off reflective ceilings and walls. Stacking two KP102 I elements per side extends vertical pattern control for medium to large rooms.

Low-frequency support comes from two Thunder KS3P I passive subwoofers, each built around a long-excursion 21" neodymium woofer with a 4" voice coil in a compact, lightweight enclosure. The included Kommander KA104 amplifier platform supplies 4x 2500 W at 4 ohms with onboard DSP and factory presets matched to the KP102 I and KS3P I, so system tuning starts from a verified baseline rather than a blank slate. Remote control is available through the K-array Connect mobile app, while K-Framework3 software manages multiple units over wired LAN for larger projects. Because the loudspeakers are fully passive, all electronics live in the rack, simplifying service access in installed environments. Browse the full K-Array collection at Creation Networks for companion components and accessories.

Key Features

• Complete Passive Stereo Package — The bundle includes four KP102 I line array elements, two KS3P I subwoofers, one Kommander KA104 amplifier, and mounting hardware so integrators can specify one part number per room.
• Pure Line Array Performance — Each KP102 I uses twelve closely spaced 3.15" neodymium transducers to achieve long throw and high intelligibility with 134 dB peak SPL per element.
• Controlled Coverage Pattern — The 7°–30° vertical by 90° horizontal dispersion keeps sound focused on listeners and reduces reflections in acoustically difficult rooms.
• Deep, Compact Low End — Each Thunder KS3P I delivers 139 dB peak SPL from a long-excursion 21" neodymium woofer with 2800 W peak power handling at 4 ohms.
• DSP Amplification Included — The Kommander KA104 provides 4x 2500 W at 4 ohms with factory presets for every loudspeaker in the system, plus K-array Connect app control.
• Control System Integration — K-Array publishes plugins for Q-SYS, Crestron, Control4, Kramer, RTI, Savant, and Symetrix, so the amplifier integrates into existing commercial control infrastructure.
• Discreet Stainless Steel Build — The slim, meter-long column profile blends into architecturally sensitive spaces where conventional loudspeaker cabinets would be intrusive.
• Five-Year Manufacturer Warranty — K-Array backs its products with a 5-year warranty policy for long-term installation confidence.

Typical Applications

• House of worship
• Auditorium
• Multi-purpose room
• All-hands room
• Government space
• Commercial meeting space
• Broadcast studio

Technical Specifications

Frequently Asked Questions

What amplifier drives the KR402P II, and is it included?

Yes. The system ships with the Kommander KA104, a four-channel DSP amplifier rated at 4x 2500 W into 4 ohms, with factory presets matched to the KP102 I and KS3P I loudspeakers.

Can the KR402P II integrate with our existing control system?

K-Array provides plugins for Q-SYS, Crestron, Control4, Kramer, RTI, Savant, and Symetrix, and the K-array Connect mobile app handles day-to-day remote control of DSP parameters and routing.

How are the KP102 I columns mounted?

The package includes K-Array mounting hardware, and the KP102 I supports wall, pole, fly, and subwoofer-top mounting through K-Array accessories such as the K-WALL2, K-FLY3, K-JOINT3, and K-FOOT3. Final rigging should be specified by a qualified installer.

Is this system suitable for speech-critical rooms?

Yes. The pure line array geometry of the KP102 I is designed for high speech intelligibility and long throw, which makes the system well suited to houses of worship, auditoriums, and government meeting spaces.

What warranty applies to this system?

K-Array products carry a 5-year manufacturer warranty. Creation Networks supports the sale with pre- and post-installation assistance for commercial AV buyers.

Is a white version available?

K-Array offers Pinnacle systems and KP102 I elements in white and custom finishes. Contact Creation Networks or browse the K-Array collection for available finish options.
