JBL Professional Intellivox HP-DS170 High-Power Beam-Shaping Column...
The JBL Intellivox HP-DS170 is a self-powered, wide-bandwidth, beam-shaping column loudspeaker designed to deliver superior speech intelligibility and music reinforcement in acoustically challenging spaces. Compact yet powerful, it provides precise coverage and high output while blending discreetly into architectural environments.
With a 1.7 m (5’ 7”) array length, the HP-DS170 is ideal for installations where space is limited but consistent coverage is critical. It incorporates ten high-efficiency 6.5" drivers and two coaxially mounted 1" compression drivers, each with dedicated amplification, delivering up to 106 dB SPL at 30 m (100 ft). Its 100° horizontal dispersion ensures wide-area coverage, while Digital Directivity Synthesis (DDS) beam shaping technology allows flexible vertical control for optimal audience targeting.
Built to withstand demanding conditions, the HP-DS170 is IP55-rated for outdoor use, with a stainless-steel (AISI 304) enclosure and epoxy coating. It integrates DSP, RS-485 serial control, and a full range of mounting and customization options, making it a versatile solution for houses of worship, theaters, transport hubs, sports facilities, and more.
Key Features:
-
High-power, wide-bandwidth beam-shaping column loudspeaker
-
DDS Beam Shaping with DSP for precise coverage control
-
Delivers up to 106 dB SPL at 30 m (100 ft)
-
10 × 6.5" drivers + 2 × 1" compression drivers with dedicated amps
-
Compact 1.7 m (5’ 7”) column for discreet installations
-
Horizontal dispersion: 100° wide coverage
-
Stainless-steel enclosure with epoxy coating (IP55-rated)
-
RS-485 serial control for system integration
-
Available accessories and color-matching options
Applications:
-
Fill or delay system for larger Intellivox arrays
-
Houses of worship
-
Theaters and concert halls
-
Transportation halls and public venues
-
Sports facilities
-
Touring sound reinforcement
Specifications Table:
| Category | Details |
|---|---|
| Manufacturer | JBL Professional |
| Model | Intellivox HP-DS170 |
| Type | Beam-Shaping Column Loudspeaker |
| Maximum SPL (30 m) | Continuous: 97 dB, Peak: 105 dB |
| Typical Throw | 10–25 m (33–82 ft) |
| Drivers | 10 × 6.5" loudspeakers, 2 × 1" compression drivers |
| Horizontal Dispersion | 100° |
| Vertical Coverage | Software-controlled beam shaping |
| Amplification | Built-in, per driver |
| DSP | Integrated with DDS beam shaping |
| Enclosure Material | Stainless steel (AISI 304), epoxy coated |
| Ingress Protection | IP55 |
| Dimensions (H × W × D) | 1698 × 198 × 189 mm |
| Height | 1.7 m (5’ 7”) |
| Weight | 56 kg (123 lb) |
| Finish | Enclosure/Grille: RAL 9010 (white), Baffle: RAL 9011 (black) |
| Optional Accessories | Mounting kits, color matching |
