JBL Intellivox DC500 – Flagship Wall-Mount Digitally Steerable Column Array (Amp Bottom)

Product Overview

The JBL Intellivox DC500 (Amplifier at Bottom) is the flagship model in the DDC series of wall-mount digitally steerable column arrays, engineered for large-venue fixed installation requiring precision vertical beam control in architecturally constrained spaces. With an array length exceeding 4 meters and coverage reaching 70 meters, the DC500 delivers consistent SPL and high speech intelligibility in conference halls, atriums, theatres, houses of worship, and transportation hubs. Its 32-driver, self-powered design with integrated 16-channel Class-D amplification mounted at the bottom of the column provides a clean installation profile for wall surfaces where top-mounted amplifier access is limited. Commercial AV integrators choose the DC500 when long-throw performance and flush wall-mount profile are both required in the same deployment.

Product Description

The DC500 features 32 custom-designed 4-inch full-range loudspeakers configured using JBL's patented driver algorithm, which optimizes vertical and horizontal coverage distribution for consistent intelligibility in highly reverberant spaces. Digitally steerable beam technology provides software-controlled vertical tilt and beam shaping, allowing AV system designers to aim the coverage zone without physical adjustment of the column after installation. The 16-channel Class-D amplifier is integrated at the bottom of the array — accommodating installation scenarios where bottom access or wiring entry points are preferred. A switched-mode power supply ensures stable, reliable operation in long-term fixed commercial deployments. Dual line inputs support primary and redundant signal feeds, and onboard DSP handles beam steering, equalization, and delay. The DDC series is designed for flush or near-flush wall-mount applications in spaces where the loudspeaker must follow the vertical surface rather than projecting from a bracket — suitable for side-wall treatment in conference halls, theatres, and transit concourses. Available in black and white, the DC500 integrates architecturally across varied interior finishes.

Key Features

• Wall-Mount DDC Series Design — Engineered specifically for flush and near-flush vertical wall installation, the DC series provides steerable column performance in spaces unsuited to freestanding brackets.
• 32 × 4-inch Full-Range Driver Array — High driver count delivers 70-meter throw with precise SPL consistency, suited to the largest commercial conference and assembly spaces.
• Amplifier at Bottom Configuration — Bottom-mounted amplification suits installations where bottom-entry wiring runs or lower-level access points are required by the installation environment.
• Digitally Steerable Vertical Beam — Software-controlled beam steering via DSP enables precise vertical tilt and coverage zone adjustment without repositioning the column.
• Integrated 16-Channel Class-D Amplifier — Self-powered design eliminates external rack amplifiers, reducing installation complexity and equipment room requirements.
• Subwoofer-Extended Frequency Range — Frequency response includes subwoofer support for program audio applications beyond pure speech reinforcement.
• Dual Line Inputs — Supports primary and backup signal feeds for resilient commercial audio system configurations.
• Slim Architectural Profile — Available in black and white, the DC500 integrates into wall surfaces with minimal visual intrusion in aesthetically sensitive commercial spaces.

Typical Applications

• Conference room — large conference halls requiring flush wall-mount loudspeakers with long-throw coverage and beam-steered intelligibility
• House of worship — large sanctuaries where side-wall placement is preferred over bracket-mounted ceiling or flown arrays
• Auditorium — theatres and performing arts venues requiring wall-integrated column arrays with extended subwoofer-supported frequency range
• Transportation terminal — airports and transit concourses requiring wall-mount long-throw paging coverage with minimal obstruction
• Government space — legislative chambers and assembly halls where flush wall integration is architecturally mandated
• Multi-purpose room — large flexible-use spaces requiring adaptable coverage from wall-mounted arrays

Technical Specifications

Competitor Comparison

What's in the Box

• JBL Intellivox DC500 wall-mount column array loudspeaker (Amplifier at Bottom)
• Wall-mount hardware and installation brackets
• Power supply cable
• Documentation and setup guide

Frequently Asked Questions

What is the difference between the DC500 Amp Bottom and Amp Top configurations?

Both models are electrically identical. The only difference is the physical location of the integrated amplifier module — Bottom or Top. The configuration is chosen based on the installation site's wiring access points and physical mounting constraints. Both deliver the same 70-meter coverage and DSP beam steering performance.

Does the DC500 require a separate subwoofer for low-frequency reinforcement?

The DC500 is specified with an extended frequency range including subwoofer support, which may reduce the need for an external sub in some applications. For applications requiring significant low-frequency output, a matched JBL Professional subwoofer is recommended. Contact Creation Networks for system design guidance.

Is the DC500 compatible with Crestron or AMX control systems?

The DC500 uses DSP-based control software for beam steering and parameter management. Third-party control system integration should be verified with your AV system integrator. Contact Creation Networks for project-specific compatibility guidance.

What is the warranty for the Intellivox DC500?

JBL Professional products are backed by a limited manufacturer warranty. Commercial project warranty terms should be confirmed with an authorized JBL distributor at the time of purchase. Creation Networks provides warranty support coordination for commercial AV installations.

Can the DC500 be used in a multi-column installation?

Yes. Multiple DC500 units can be networked and time-aligned through the system's DSP control software, supporting multi-zone and distributed audio configurations for large commercial spaces.
