JBL AM5212/64 12" 2-Way Loudspeaker (60° x 40°, Black)
The JBL AM5212/64 is a medium-power, 2-way full-range loudspeaker engineered for professional audio applications such as performing arts facilities, theaters, auditoriums, houses of worship, live clubs, sports venues, and themed entertainment spaces.
This model features a 12" Differential Drive low-frequency driver (262H-1) and a 1.5" high-frequency compression driver (2408H-1), delivering clear and consistent sound across a wide frequency spectrum. Its rotatable PT Progressive Transition waveguide provides precise 60° x 40° coverage for vertical or horizontal placement. With bi-amp/passive switchable operation and FIR tuning, the AM5212/64 ensures optimized frequency response, phase alignment, and consistent coverage in demanding installations.
Key Features
-
12" Differential Drive LF driver (262H-1)
-
1.5" HF compression driver (2408H-1)
-
Rotatable PT waveguide with 60° x 40° coverage
-
Bi-amp/passive switchable operation
-
FIR tuning for optimized frequency, phase, and coverage consistency
-
Frequency range: 37 Hz – 20 kHz (-10 dB)
-
Maximum SPL: LF 122 dB / HF 131 dB (bi-amp mode)
-
Passive mode sensitivity: 96 dB SPL
-
Trapezoidal 11-ply birch plywood enclosure with 15° side angles
-
Black DuraFlex finish, optional white
-
15 M10 suspension points for flexible rigging
-
Powder-coated steel grille with acoustically transparent foam
Applications
Performing arts facilities, theaters, auditoriums, houses of worship, live clubs, dance clubs, sports facilities, themed entertainment venues.
Specifications
| Specification | Detail |
|---|---|
| Speaker Type | Passive / Bi-Amp Loudspeaker |
| Configuration | 2-Way |
| LF Driver | 1 x 12" (300 mm) Dual VC Differential Drive 262H-1 |
| HF Driver | 1 x 1.5" (38 mm) Compression Driver 2408H-1 |
| Frequency Range (-10 dB) | 37 Hz – 20 kHz |
| Frequency Response (±3 dB) | 43 Hz – 18 kHz |
| Coverage Angle | 60° H x 40° V (rotatable horn) |
| Crossover Frequency | 1.5 kHz |
| AES LF Power Rating | 300 W / 1200 W peak (100 hrs) |
| AES HF Power Rating | 40 W / 160 W peak (2 hrs) |
| System Power Rating | Passive: 300 W / 1200 W peak (100 hrs) |
| Maximum SPL | LF 122 dB cont / HF 131 dB cont |
| System Sensitivity | LF 97 dB / HF 113 dB SPL |
| Nominal Impedance | LF: 8 Ohms / HF: 8 Ohms |
| Enclosure Type | Trapezoidal plywood |
| Grille Material | Powder-coated steel with foam backing |
| Suspension Points | 4 top, 4 bottom, 2 each side, 3 rear (M10) |
| Input Connector | NL4 Neutrik Speakon & barrier strip |
| Environmental Rating | Mil-Std 810; IP-x3 |
| Dimensions (H x W x D) | 713 x 371 x 458 mm (28.06 x 14.6 x 18.1 in) |
| Weight | 20.2 kg (45 lb) |
| Optional Accessories | M10 x 35 mm shoulder eyebolts, U-Bracket MTU-3 |
