JBL AM5212/26 12-Inch 2-Way Loudspeaker with 120° x 60° Rotatable Horn
JBL AM5212/26 12-Inch 2-Way Loudspeaker with 120° x 60° Rotatable Horn is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise?
Give us a call at 1-888-230-3661 or LiveChat below.
Purchasing 1 or 100, there may be greater savings beyond the advertised price.
JBL AM5212/26 12-Inch 2-Way Loudspeaker with 120° x 60° Rotatable Horn
The JBL AM5212/26 is a professional-grade 12-inch 2-way full-range loudspeaker engineered for versatile, high-quality audio performance. Utilizing JBL’s Differential Drive® dual voice coil and dual magnetic gap 262H-1 low-frequency driver alongside the 2408H-1 high-frequency 1.5-inch compression driver, this system delivers clear, balanced sound with exceptional detail. Its large-format PT™ Progressive Transition waveguide offers precise 120° x 60° coverage and can be rotated to suit either vertical or horizontal deployment, allowing flexible placement in venues of any size or configuration.
Designed for both live and installed sound applications, the AM5212/26 employs high-slope passive networks to reduce band overlap while maintaining smooth off-axis response, enhancing arrayability and consistent coverage. The system’s bi-amp and passive mode FIR tuning further optimize frequency and phase response, ensuring excellent tonal clarity, consistent sound dispersion, and minimal distortion. The trapezoidal enclosure, made from 16 mm exterior-grade 11-ply birch plywood, is lightweight yet durable, complemented by finishes in Black DuraFlex™, White, or WRC/WRX weather-resistant options for indoor or outdoor use.
Ideal for performing arts facilities, theaters, auditoriums, worship centers, live and dance clubs, sports venues, and themed entertainment spaces, the AM5212/26 offers a maximum SPL of 122 dB (LF) and 131 dB (HF) in bi-amp mode, with a passive system sensitivity of 96 dB. Its multiple suspension points, robust input connectors, and reliable construction make it a versatile solution for high-performance sound reinforcement, providing professional audio coverage in any demanding environment.
Features:
-
120° x 60° rotatable coverage for flexible deployment
-
262H-1 Differential Drive® 12-inch low-frequency driver
-
2408H-1 1.5-inch high-frequency compression driver
-
PT™ Progressive Transition waveguide for precise pattern control and low distortion
-
Bi-amp/Passive switchable with FIR tuning for optimized performance
-
Trapezoidal 16 mm 11-ply birch plywood enclosure, lightweight and durable
-
Available in Black, White, and WRC/WRX weather-resistant finishes
-
Suitable for performing arts, auditoriums, worship spaces, clubs, sports arenas, and themed entertainment
Specifications Table:
| Specification | Detail |
|---|---|
| Frequency Range (-10 dB) | 37 Hz – 20 kHz |
| Frequency Response (±3 dB) | 43 Hz – 18 kHz |
| Coverage Pattern | 120° x 60° |
| Crossover Modes | Bi-amp / Passive switchable |
| Passive Crossover Frequency | 1.5 kHz |
| Transducer Power Rating (AES) | LF: 400 W (1600 W peak) 2 hrs / HF: 40 W (160 W peak) 2 hrs |
| System Power Rating | Passive mode: 300 W (1200 W peak) |
| Maximum SPL (1m) | Bi-amp mode: LF 122 dB, HF 131 dB |
| System Sensitivity | Passive mode: 96 dB SPL |
| LF Driver | 1 x JBL 262H-1 12" Dual Voice Coil |
| HF Driver | JBL 2408H-1 1.5" compression driver |
| Nominal Impedance | LF: 8 Ω, HF: 8 Ω |
| Enclosure | Trapezoidal, 16 mm 11-ply birch plywood |
| Suspension | 15 points, M10 threaded hardware |
| Finish | Black DuraFlex™, White or WRC/WRX optional |
| Input Connector | NL4 Speakon® & barrier strip terminals |
| Dimensions (H x W x D) | 713 x 371 x 458 mm |
| Net Weight | 20.2 kg (45 lb) |
Compare Table:
| Feature | AM5212/26 | AM5212/64 | AM5212/66 |
|---|---|---|---|
| Coverage | 120° x 60° | 60° x 40° | 60° x 60° |
| LF Driver | 12" Dual Voice Coil | 12" Dual Voice Coil | 12" Dual Voice Coil |
| HF Driver | 1.5" Compression | 1.5" Compression | 1.5" Compression |
| System Power Rating | 300 W Passive | 300 W Passive | 300 W Passive |
| Max SPL | 122 dB LF | 122 dB LF | 122 dB LF |
| Orientation | Rotatable | Rotatable | Rotatable |
