The PD595 is a loudspeaker designed for applications requiring high output capability with excellent pattern control.
Key Features
- Horn-loaded, full-range loudspeaker system
- Sophisticated, steep-slope passive crossover network
General
| Product Type | Speaker |
| Enclosure Color | White |
| Image Color Disclaimer | The displayed product image may be a different color |
| Enclosure Material | Birch plywood |
| Design Features | DuraFlex finish, trapezoidal design |
Speaker System
| Speaker Type | 2-way - passive |
| Nominal Output Power | 300 Watt |
| Max (RMS) Output Power | 500 Watt |
| Frequency Response | 50 - 20000 Hz |
| Nominal Impedance | 8 Ohm |
| Max Output Level (Max SPL) | 139 dB |
| Sensitivity | 104 dB |
| Crossover Frequency | 1300Hz |
| Coverage | 90° x 50° |
Speaker System Details
| Driver Details | Speaker: woofer driver - 15" - Horn Speaker: tweeter driver - 1.5" - Horn Loaded Compression Driver (HLCD) |
Miscellaneous
| Compliant Standards | MIL-STD-810, IPX3 |
Dimensions & Weight
| Width | 30.8 in |
| Depth | 26.4 in |
| Height | 30.8 in |
| Weight | 152.12 lbs |
