JBL Commercial Series VMA260 60W Bluetooth-Enabled Mixer/Amplifier (8-In/2-Out)

Availability: Call for Availability
Availability: Direct Ship
JBL SKU: VMA260
No reviews
Price:
$548.00 $851.81

Description

The JBL VMA260 is a Commercial Series Bluetooth-enabled mixer/amplifier designed to provide flexible multi-source mixing and amplification for installation in restaurants, educational institutions, fitness centers, and retail stores. It features an 8-in/2-out mixer and 60W of output power. It can be installed in a standard 19” equipment rack with the supplied rackmount kit or set on a surface such as a desk or ledge.

Stream music wirelessly via Bluetooth or connect a USB drive to the front-panel USB Type-A port. Route other sources via Euroblock, RCA, and 1/4" input jacks. The integrated mixer offers level controls as well as bass and treble for each channel. Routing to the Euroblock outputs is configurable. The VMA260 supports voice-activated ducking and priority muting. The front-panel controls and display make operation easy, and remote volume control is possible via a JBL CSR-V module and a standard Ethernet cable (both available separately).

  • Suitable for commercial and industrial use
  • Euroblock, RCA, and 1/4" TRS input connectors
  • Independent bass and treble controls for each output channel
  • Voice-activated ducking during announcements
  • Remote volume control capability using optional JBL CSR-V module and Cat5e cable with RJ45 connectors
  • Priority muting using PTT switch closure
  • Configurable output routing
  • Barrier block output connections to drive 8 Ohms, 70V or 100V speaker systems
  • Media player capable of playing MP3 files from a Bluetooth device or USB drive

JBL VMA260 Specs

 Amplifier
Form Factor/Type Tabletop
Number of Channels 8 Input / 2 Output
Power Rating 4 Ohms / 8 Ohms:
60 W per Channel (1 kHz, 0.5% THD)
Load Impedance / Voltage 4 Ohms (Minimum)
70 V (80 Ohms Minimum)
100 V (160 Ohms Minimum)
Performance
Frequency Response 20 Hz to 20 kHz ±2 dB (Low-Z)
80 Hz to 15 kHz ±3 dB (70/100 V)
Input Sensitivity Mic:
5.5 mVrms
Line:
1.3 Vrms
Stereo RCA:
130 mVrms
I/O Impedance Mic Input:
400 Ohms
Line Input:
20 Kilohms (Balanced)
RCA Input:
50 Kilohms
Insertion Loss 1 dB Maximum
SNR > 76 dB (at Rated Power, A-Weighted)
THD < 0.5% (20 Hz to 20 kHz)
Crosstalk -70 dB (at Rated Power, Mid Gain, 1 kHz)
Signal Processing
EQ 2-Band per Channel:
Bass: ±14 dB at 50 Hz
Treble: ±14 dB at 10 kHz
Connectivity
Phantom Power 27 VDC
Power
AC Input Power 100 VAC, 50 / 60 Hz
120 VAC, 50 / 60 Hz
220 VAC, 50 / 60 Hz
220 to 240 VAC, 50 / 60 Hz
Physical
Operating Temperature 32 to 95°F / 0 to 35°C
Storage Temperature -4 to 185°F / -20 to 85°C
Operating Humidity 0 to 95% (Non-Condensing)
Dimensions 17.0 x 3.5 x 16.3" / 432.0 x 88.0 x 415.0 mm
Weight 25.5 / 11.6 kg
Packaging Info
Package Weight 30 lb
Box Dimensions (LxWxH) 21 x 20.5 x 7"
