JBL Ultra-Compact Indoor/Outdoor Background/Foreground Speaker (Pair, Black) - Control 23-1

Save 19%
JBL SKU: Control 23-1
No reviews
Price:
$290.00 $359.88

Description

Ultra-Compact Indoor/Outdoor Background/Foreground Speaker

Sold as a pair, The Control® 23-1 is a two-way 3” speaker with rich sonic character, wide coverage, consistent dispersion, versatile mounting, and a contemporary high-design look that fits into a wide range of decors. This makes Control 23-1 an excellent choice for a wide variety of applications, including retail stores, restaurants, health clubs, theme parks, educational facilities, hospitality, music cafes, leisure venues, and anywhere where a top quality compact indoor/outdoor foreground/background music (and/or paging) speaker is required.
  • Components:
    • 3” woofer with woven fiberglass cone
    • 1/2” PEI diaphragm tweeter with fluid cooling
  • Contemporary, high-design appearance
  • Built-in InvisiBall® mounting hardware*, plus available U-bracket
  • Weather resistant enclosure and transducers
  • Wide 100° x 100° coverage
  • 50 Watt power handling (100 Watt program) in direct 8Ω setting, plus built-in 15 Watt 70V/100V multi-tap transformer.
  • High fidelity sound character with broad frequency response of 70 Hz – 20 kHz.
Active or Passive Passive
Speaker Configuration 2-Way
Power Handling For 100 Hours:
40 W RMS
160 W Peak
For 2 Hours:
100 W Program
50 W RMS
200 W Peak
Constant Voltage / Transformer Taps 100 V:
15 / 7.5 / 3.7 W or 8 Ohms Bypass
70 V:
15 / 7.5 / 3.7 / 1.8 W or 8 Ohms Bypass
Impedance 8 Ohms (Thru Setting)
Drivers
HF Driver 0.5" / 13 mm PEI Tweeter
LF Driver 3" / 76 mm Fiberglass Woofer
Performance
Frequency Response 70 Hz to 20 kHz ±10 dB
95 Hz to 19 kHz ±3 dB
Sensitivity 86 dB
Coverage Angle 100° H x 100° V
Directivity 5.8 (Directivity/Q Factor)
7.2 dB (Directivity Index)
Crossover Low-Pass:
12 dB/Octave
High-Pass:
12 dB/Octave
Recommended High-Pass Filter 70 Hz, 24 dB/Octave
Maximum Input Voltage 17.2 V RMS
34.4 V Peak
Transformer Insertion Loss <0.43 dB
Connectivity
I/O Screw Terminal
Maximum Wire Gauge 12 AWG / 2.5 mm
Environmental
Certifications RoHS, UL
*as per Manufacturer
IP Rating IP44
Physical
Color Black
Construction Material High-Impact Polystyrene, Metal Grille
Dimensions 7.9 x 5.6 x 4.4" / 200 x 141 x 111 mm
Weight 4 lb / 1.8 kg
Packaging Info
Package Weight 9.155 lb
Box Dimensions (LxWxH) 12.5 x 9.45 x 7.15"
