JBL CBT 70J-1-WH Line Array Column Loudspeaker (White)

Product Overview

The JBL CBT 70J-1-WH is a two-way passive line array column loudspeaker for installed-sound rooms that need high output and consistent coverage from a compact enclosure. It combines sixteen 25 mm tweeters and four 125 mm low-frequency drivers in a coaxial arrangement with JBL Constant Beamwidth Technology for even vertical coverage and reduced out-of-coverage lobing. Asymmetrical vertical coverage and switchable 45°/25° patterns let integrators tune throw for medium- or long-distance applications. Finished in white, it suits houses of worship, auditoriums, and multi-purpose rooms.

Product Description

The CBT 70J-1 uses complex analog delay beam-forming and amplitude tapering to deliver smooth, consistent vertical coverage that straight passive column speakers cannot match. Its asymmetrical vertical coverage directs more energy toward the rear of the room to even out front-to-back levels. A switchable voicing control offers flat response for music or a midrange presence peak for speech. Vertical coverage is switchable between 45° for medium throw and 25° for long-throw applications. Dynamic SonicGuard overload protection guards the high-frequency devices under sustained output, and the included swivel (pan)/tilt wall bracket allows precise aiming. The 70J-1 can be paired with the CBT 70JE-1 extension for added low-frequency output and pattern control. Explore related models in our JBL Professional installed audio collection.

Key Features

• Constant Beamwidth Technology — CBT processing provides constant directivity up to the highest frequencies and reduces out-of-coverage lobing.
• Coaxial driver complement — Sixteen 25 mm (1 in) soft dome tweeters and four 125 mm (5 in) low-frequency drivers are arranged coaxially.
• Asymmetrical vertical coverage — The pattern sends more sound toward the far area of the room for more consistent front-to-back levels.
• Switchable vertical pattern — Coverage is selectable between 45° for medium-throw and 25° for long-throw applications.
• Switchable voicing — A voicing control selects flat response for music or a midrange presence peak for speech.
• Dynamic SonicGuard protection — Low-audibility overload protection safeguards the high-frequency devices during high-output operation.
• Included mounting hardware — A swivel (pan)/tilt wall bracket ships with the speaker for accurate aiming.
• Extension compatible — The column pairs with the CBT 70JE-1 extension for added low-frequency output and pattern control.

Typical Applications

• House of worship
• Auditorium
• Multi-purpose room
• Conference room

Technical Specifications

Full electrical specifications should be confirmed against the JBL CBT 70J-1 specification sheet.

Frequently Asked Questions

How is the coverage adjusted on the CBT 70J-1? Vertical coverage is switchable between 45° and 25°, and an asymmetrical pattern directs more sound to the rear of the room for even front-to-back levels.

Can I increase low-frequency output later? Yes. The 70J-1 is designed to pair with the CBT 70JE-1 extension, which adds bass extension and lower-frequency pattern control.

What mounting hardware is included? A swivel (pan)/tilt wall bracket is supplied for accurate horizontal and vertical aiming.

Is it suitable for speech-heavy rooms? Yes. A switchable speech voicing adds a midrange presence peak that improves intelligibility in worship and presentation spaces.

What warranty and support apply? The speaker carries the standard JBL Professional warranty, and Creation Networks can assist with system design and quantities.
