JBL ASB7128-WH – Dual 18-Inch Ultra Long Excursion High-Power Subwoofer (White)

Product Overview

The JBL ASB7128-WH is a high-power, lightweight front-loaded vented subwoofer enclosure housing two JBL 2269H Ultra Long Excursion 18-inch Differential Drive woofers, finished in white for architectural installation environments. Designed for ground-stacked or suspended applications in stand-alone arrays or in combination with other JBL AE Series loudspeakers, the ASB7128 delivers 4,000 watts continuous pink noise power handling and 16,000 watts peak — providing high-output, low-distortion low-frequency reinforcement for large auditoriums, houses of worship, arenas, and performing arts venues. FIR tuning matches the phase profile to JBL AE Series full-range models, ensuring coherent system integration in commercial AV installations requiring deep, controlled bass extension.

Product Description

The ASB7128 houses two of JBL's exclusive 2269H Ultra Long Excursion 18-inch woofers, featuring neodymium magnets, dual voice coils, dual gaps, JBL's Vented Gap Cooling, and ultra-robust composite cones — capable of 89 mm (3.5 inches) of peak-to-peak maximum excursion for extreme low-frequency output with extended driver life. The front-loaded vented enclosure design provides a large vent area for high output with low distortion, suited to demanding large-venue applications. A parallel/discrete switchable input mode gives system designers flexibility in wiring configuration, and FIR (Finite Impulse Response) tuning matches the subwoofer's phase profile to JBL AE Series full-range loudspeakers — ensuring phase-coherent integration when the ASB7128 is deployed alongside other AE Series components. The white finish supports installation in architecturally sensitive environments where black enclosures are visually unsuitable. The ASB7128-WH is appropriate for ground-stacked or flown deployment in stand-alone subwoofer arrays or as the low-frequency foundation of a complete JBL AE Series system.

Key Features

• Dual 2269H Ultra Long Excursion 18-Inch Woofers — Neodymium magnet, dual voice coil, dual gap transducers with 89 mm peak-to-peak excursion deliver extreme low-frequency output with extended driver life.
• 4,000W Continuous / 16,000W Peak Power Handling — High power capacity supports demanding large-venue low-frequency reinforcement applications.
• Vented Gap Cooling Technology — JBL's exclusive cooling design maintains driver performance under sustained high-power operation in commercial installations.
• FIR Phase Matching — Finite Impulse Response tuning matches the phase profile to JBL AE Series full-range models for coherent system integration.
• Parallel/Discrete Switchable Input Mode — Flexible input configuration for varied system wiring and amplifier deployment scenarios.
• Front-Loaded Vented Enclosure — Large vent area provides high output with low distortion for accurate, controlled bass reproduction.
• White Architectural Finish — White enclosure supports installation in architecturally sensitive commercial spaces where black is visually unsuitable.
• Ground-Stack or Flown Deployment — Supports both ground-stacked and suspended applications in stand-alone arrays or AE Series system configurations.

Typical Applications

• Auditorium — performing arts venues and large auditoriums requiring high-output low-frequency reinforcement integrated with AE Series full-range systems
• House of worship — large sanctuaries requiring deep, controlled bass extension for contemporary worship program audio
• All-hands room — large corporate assembly spaces requiring high-output subwoofer reinforcement for general sessions and events
• Multi-purpose room — arenas and large multipurpose venues requiring ground-stacked or flown subwoofer arrays
• Broadcast studio — large production and performance venues requiring high-power low-frequency reinforcement

Technical Specifications

Competitor Comparison

What's in the Box

• JBL ASB7128-WH dual 18-inch subwoofer (white)
• Cable chase kit (per this configuration)
• Rigging hardware and documentation

Frequently Asked Questions

Does the ASB7128-WH require external amplification?

Yes. The ASB7128 is a passive subwoofer requiring external amplification and DSP processing. JBL recommends pairing it with the appropriate amplifier and applying the supplied FIR tuning for optimal phase-coherent integration with AE Series full-range loudspeakers. Contact Creation Networks for amplifier recommendations.

What does FIR phase matching provide?

FIR (Finite Impulse Response) tuning matches the ASB7128's phase profile to JBL AE Series full-range models, ensuring coherent acoustic integration when the subwoofer is deployed in a complete AE Series system. This results in tight, accurate low-frequency transition between the subwoofer and full-range loudspeakers.

Can the ASB7128-WH be flown?

Yes. The ASB7128 supports both ground-stacked and suspended (flown) deployment. All rigging should be performed by qualified personnel following JBL's load and safety guidelines.

What warranty applies?

JBL Professional products carry a limited manufacturer warranty. Contact Creation Networks for commercial warranty coordination.
