James Loudspeaker SA68 - 3-Way Full Range, Inceiling Small Aperture

Product Overview

The James Loudspeaker SA68 is a 3-way full-range Small Aperture in-ceiling speaker engineered for high-end commercial AV installation where architectural discretion matters as much as audio performance. Its narrow ceiling cutout suits boardrooms, conference rooms, and premium commercial meeting spaces that demand even, full-bandwidth coverage from a nearly invisible source. The aircraft-grade aluminum enclosure and carbon fiber driver complement integration into demanding architectural and commercial deployment environments.

Product Description

The SA68 belongs to the James Loudspeaker Small Aperture Series, a line built around the idea that a high-performance loudspeaker can deliver full-range output through a minimal ceiling opening. A 6.5" carbon fiber woofer, a 2.0" midrange, and a dedicated tweeter form a true 3-way system, reproducing a frequency response of 45Hz to 25kHz so the speaker covers deep bass through extended highs without a separate subwoofer in many rooms. The result is an in-ceiling speaker that delivers the kind of bandwidth typically associated with much larger apertures, making it well suited to conference rooms, boardrooms, and other commercial integration projects where ceiling real estate and sightlines are tightly controlled.

Housed in an aircraft-grade aluminum enclosure and available in Brilliant White or a range of standard colors, the SA68 is designed to disappear into the ceiling plane while supporting consistent coverage across the listening area. For pre-construction projects, pair the speaker with the matching SA68 enclosure section, and for service or upgrade work the SA68 module installs into existing apertures. Integrators specifying full small-aperture systems can review the complete range on the James Loudspeaker collection to match models across rooms of different sizes.

Key Features

• 3-Way Full-Range Design — A dedicated woofer, midrange, and tweeter reproduce the full audio band so the SA68 can serve as a complete in-ceiling source in many commercial rooms.
• Small Aperture Format — The narrow ceiling opening preserves clean architectural sightlines, which is critical in boardrooms and design-led commercial meeting spaces.
• Extended Frequency Response — A 45Hz to 25kHz response delivers deep low end and airy highs, reducing the need for additional drivers in typical conference-room deployments.
• 6.5" Carbon Fiber Woofer — The stiff, lightweight carbon fiber cone supports controlled low-frequency output and accurate midbass for speech and program material.
• Aircraft-Grade Aluminum Enclosure — The machined aluminum housing provides a rigid, acoustically inert platform that supports consistent performance in ceiling installations.
• Finish Flexibility — Brilliant White and additional standard color options allow the speaker to match a range of ceiling treatments and interior designs.
• Pre-Construction and Retrofit Paths — Matching enclosure and module options support both new-construction integration and service or upgrade work in existing ceilings.

Typical Applications

• Boardrooms
• Conference rooms
• Huddle rooms
• Commercial meeting spaces
• Multi-purpose rooms
• Training rooms
• All-hands rooms

Technical Specifications

Frequently Asked Questions

Is the SA68 a complete loudspeaker or does it require a separate enclosure?
The SA68 is a complete 3-way full-range speaker. For new construction, the matching SA68 pre-construction enclosure section can be installed ahead of finish work to simplify integration.

What size rooms is the SA68 suited for?
Its full-range 3-way design and 45Hz to 25kHz response make it well suited to boardrooms, conference rooms, and similar commercial meeting spaces where a discreet ceiling source must cover the room evenly.

How does the small aperture affect installation?
The narrow ceiling opening preserves architectural sightlines, but the speaker still requires adequate plenum depth; confirm ceiling cavity clearance during the design phase of your commercial deployment.

Can the SA68 integrate with a commercial AV control and amplification system?
Yes. As a passive loudspeaker it integrates with standard commercial amplifiers and DSP-based AV systems; match amplifier power and impedance to your system design.

What finishes are available for the SA68?
The speaker ships in Brilliant White and is available in a range of standard colors to match ceiling and interior finishes.

How do I confirm warranty and get installation support?
For warranty terms, specification support, and project assistance, contact Creation Networks through the James Loudspeaker collection.
