INOGENI VGA2USB3 VGA to USB 3.0 Video Capture Card
INOGENI VGA2USB3 VGA to USB 3.0 Video Capture Card is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
INOGENI VGA2USB3 VGA to USB 3.0 Video Capture Card
Product Overview
The INOGENI VGA2USB3 is a VGA to USB 3.0 video capture card that enables legacy VGA, Component (analog), and CVBS video sources to be captured over USB 3.0 for use with conferencing, recording, and streaming applications. It accepts SD and HDTV video formats up to 1920x1200 at 60 fps and presents the signal as a UVC-compliant USB device on any Windows, macOS, or Linux system without driver installation. The VGA2USB3 is the correct solution for organizations that need to integrate VGA-output equipment — document cameras, older PTZ cameras, or presentation systems — into modern soft codec workflows where only USB camera inputs are available. Note: the VGA2USB3 has been discontinued by INOGENI; remaining stock is available while supplies last.
Product Description
The INOGENI VGA2USB3 VGA to USB 3.0 capture card converts uncompressed VGA, Component (analog), and CVBS video with stereo analog audio into a USB 3.0 stream, delivering the signal as a standard USB camera to any connected computer. It supports a wide range of resolutions including 1080p, 720p, 480p, 576p, 1920x1200, 1600x1200, 1280x1024, 1280x960, 1024x768, 800x600, and 640x480, as well as NTSC and PAL formats, at up to 60 fps. All SD and HD signals are converted to 4:2:2 8-bit color space over USB 3.0. The line-level stereo analog audio input is output as two-channel LPCM. Digital Fluid technology internally buffers frames to maximize frame rate consistency across varying PC configurations, while hardware-based color space and sampling conversion, automatic scaling, frame rate conversion, and customizable image controls (brightness, contrast, saturation, hue) are handled on-device. The VGA2USB3 is UVC-compliant and DirectShow compatible, requiring no driver installation. It supports multiple units on the same PC simultaneously, making it suitable for multi-source capture setups. Compatible with document cameras from Epson, AVer, and Elmo, as well as VGA-output PTZ cameras and presentation systems. TAA-compliant and designed and manufactured in Canada.
Key Features
- VGA / Component / CVBS to USB 3.0 Capture — Converts analog video sources to USB 3.0 for use with soft codec and recording applications.
- Wide Resolution Support — Supports resolutions from 640x480 up to 1920x1200 at up to 60 fps, including NTSC and PAL.
- Stereo Analog Audio Input — Line-level stereo analog audio captured and delivered as two-channel LPCM over USB.
- No Driver Required — UVC and DirectShow compliant; plug-and-play on Windows, macOS, and Linux.
- 4:2:2 8-Bit Color Space — All SD and HD signals converted to 4:2:2 8-bit for accurate USB delivery.
- Digital Fluid Technology — Internal frame buffers maximize frame rate stability across any PC configuration.
- Image Controls — Adjustable brightness, contrast, saturation, and hue settings.
- Multi-Device Support — Multiple VGA2USB3 units supported on the same PC simultaneously.
- TAA-Compliant — Suitable for government procurement environments.
Typical Applications
- Conference room
- Training room
- Multi-purpose room
- Government space
- Commercial meeting space
Technical Specifications
| Specification | Value |
|---|---|
| Video Input | VGA; Component (analog); CVBS |
| Audio Input | Line-level stereo analog (3.5mm) |
| Video Output | USB 3.0 (UVC / DirectShow) |
| Audio Output | Two-channel LPCM over USB |
| Supported Resolutions | 1080p, 720p, 480p, 576p, 1920x1200, 1600x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480, NTSC, PAL — up to 60 fps |
| Maximum Resolution | 1920x1200 at 60 fps |
| Color Space Output | 4:2:2 8-bit over USB 3.0 |
| Image Controls | Brightness, contrast, saturation, hue |
| Driver Requirement | None — plug and play (UVC / DirectShow compliant) |
| OS Compatibility | Windows, macOS, Linux |
| Multi-Device Support | Yes — multiple units per PC |
| Enclosure | Compact, rugged aluminium |
| Compliance | TAA-compliant |
| Country of Manufacture | Canada |
| Product Status | Discontinued — available while stock lasts |
| SKU | VGA2USB3 |
Frequently Asked Questions
Q: What video inputs does the VGA2USB3 support?
A: The VGA2USB3 supports VGA, Component (analog), and CVBS (composite) video inputs, along with a line-level stereo analog audio input.
Q: What is the maximum resolution the VGA2USB3 can capture?
A: The VGA2USB3 supports resolutions up to 1920x1200 at 60 fps, as well as 1080p, 720p, 1600x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480, NTSC, and PAL formats.
Q: Does the VGA2USB3 require driver installation?
A: No. The VGA2USB3 is UVC-compliant and DirectShow compatible. It is recognized as a standard USB camera on Windows, macOS, and Linux without any driver installation, and works with conferencing and recording applications that accept USB camera input.
Q: Is the VGA2USB3 still in production?
A: The VGA2USB3 has been discontinued by INOGENI. Creation Networks offers remaining inventory while stock is available. For new installations requiring VGA capture, contact our team to discuss current alternatives.
Q: Can the VGA2USB3 be used with document cameras?
A: Yes. The VGA2USB3 is compatible with VGA-output document cameras from Epson, AVer, Elmo, and other manufacturers, making it suitable for training rooms and conference spaces where a document camera must feed a soft codec platform.
Q: Does the VGA2USB3 support audio capture?
A: Yes. The VGA2USB3 accepts a line-level stereo analog audio input and delivers it as two-channel LPCM over USB alongside the video stream.
Q: Is the VGA2USB3 TAA-compliant?
A: Yes. The VGA2USB3 is TAA-compliant and designed and manufactured in Canada.
