INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
Roll over image to zoom in Click on image to zoom
INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device
Product Questions? Ask Our Experts!
Tel: 888.230.3661 sales@creationnetworks.net Contact us today for quantity & package discounts!

INOGENI SHARE2 Dual Video USB 3.1 Gen 1 Capture Device

INOGENI SKU: SHARE2
No reviews
Price:
$1,495.00

Description

Mix 2 HDMI/DVI cameras to USB 3.0 - SHARE2

INOGENI’s easy and versatile SHARE2 Camera Mixer provides Picture-In-Picture in one video flow. Create interactive presentations for collaborative meetings and HyFlex classrooms.

  • 2 HDMI cameras mixer into a single USB 3.0 interface
  • Engage a dynamic presentation and easily switch up to 14 mix setup videos
  • Change camera and video configuration without cutting the flow of your presentation
  • Ideal for remote education, collaborative meetings, webinars or live streaming
  • Output: Uncompressed video on USB 3.0 or MJPEG on USB 2.0
  • Audio I/O and mixer via the INOGENI Control App
  • Controllable by LAN & RS-232
  • Cost-effective solution that is reliable and simple to install and connect (no driver required)
  • Compact and robust design with its aluminium enclosure
  • Designed and manufactured in Canada

How it works

The SHARE2 Dual HDMI/DVI to USB 3.0 professional camera mixer can be controlled by an application on the host side using our LAN or RS-232 interfaces. You can also use the keypad on the top of the device to control it manually.

You can use the camera mixer feature of the SHARE2 to embed your two video sources into one single stream. This feature can be an important asset for you if your application only supports one video interface, like Teams®, Zoom®, Webex®, GoToMeeting® and all video conferencing applications.

Easy push-button to switch easily up to 14 mix setup videos

 

The SHARE2 Dual HDMI/DVI to USB 3.0 professional camera mixer offers an array of features for a smooth and seamless experience.

  • Control interface: LAN, RS-232, USB (Get the software upgrade:  Crestron Serial & IP modules)
  • Local and remote keypad: REMOTE User Guide
  • HDMI, DVI, VGA or CVBS video input connectors; VGA and CVBS are available using an adapter
  • Unbalanced, line level stereo audio support
  • Digital Fluid technology: Internal frame buffers maximize frame rate with any host
  • Hardware-based color space and sampling conversion
  • Automatic scaling and frame rate conversion
  • Customizable video processing functions
  • Supports multiple devices on the same host
  • Device configuration via the INOGENI Control App
  • Firmware upgrade available via the INOGENI Control App
  • Compatible with Barco ClickShare Conference

INOGENI SHARE 2 Dual Specs

 Input
Video Input 1 1 x HDMI

1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480
Video Input 2 1 x DVI-I (Digital + Analog)

DVI:
1080p, 720p, 1080i, 480p, 576p, 1920x1200, 1280x1024, 1280x960, 1024x768, 800x600, 640x480

VGA:
1080p, 720p, 480p, 576p, 1920x1200, 1680x1050, 1400x1050, 1600x1200, 1280x1024, 1360x768, 1280x768, 1280x800, 1024x768, 800x600, 640x480

or 1 x CVBS

480i, 576i
Frame Rates Up to 60 Hz, all formats
Color Space RGB, YCbCr, 4:4:4, and 4:2:2
Sampling Rate 165 MHz
Analog Audio Input Analog stereo, line level, 3.5 mm jack
Analog Audio Output Analog stereo, line level, 3.5 mm jack
RS232 Via RJ45 port
HDCP The device will not decrypt BD/DVD movies, satellite/cable receivers, or other encrypted sources
Mixer The Mixer feature can be controlled by the following interfaces: panel control buttons, RS-232, optional INOGENI REMOTE, or HID (Human Interface Device) via USB connection
Output
Connector 1 x USB 3.0
Color Space YCbCr (YUY2) 4:2:2 8-bit
Video Scaler Automatic hardware based
Color Space Conversion Automatic hardware based
Sampling Conversion Automatic hardware based
Frame Rate Conversion Automatic hardware based
Audio Input 2-channel LPCM 48 kHz audio from line input or embedded in HDMI
Audio Output 2-channel LPCM 48 kHz audio line level
USB Expansion 2 x extra USB 3.0 ports for expansion purposes (The devices connected will appear to the host)
USB Bandwidth No USB bandwidth limitation
General
Operating Systems No driver installation required
Windows 7 and above (32-/64-bit)
OS X 10.10 and above
Linux (kernel v2.6.38) and above
Android
Host Requirements USB 3.0 port
Minimum 4 GB RAM
Intel Core i5
Graphic card with dedicated memory
Motherboard Compatible with all motherboards
Intel, Renesas, ASMedia, and Fresco Logic
Cameras Supported Cameras and camcorders with an HDMI, DVI, VGA, or CVBS output
Software Compatibility UVC-compliant; runs with all software compatible to DirectShow, AVFoundation, and V4L2
Power 12 V, 500 mA
Operating Temperature 32 to 113°F (0 to 45°C)
Storage Temperature -40 to 221°F (-40 to 105°C)
Relative Humidity 0 to 90% non-condensing
Dimensions 7.3 x 4.4 x 1.2" (18.5 x 11.2 x 3 cm)
Weight 1 lb (466 g)
Packaging Info
Package Weight 2.7 lb
Box Dimensions (LxWxH) 8.85 x 6.95 x 3.6"
