Netgear GS116EPP-100NAS

Product Overview

The NETGEAR GS116EPP is a 16-port Gigabit PoE+ smart-managed switch with a 231W power budget and one dedicated SFP fiber uplink. Fifteen ports deliver PoE+ up to 30W each to power AV access points, IP cameras, and VoIP phones over a single cable. It adds VLAN segmentation, QoS, IGMP snooping, PoE scheduling, and link aggregation through a browser-based GUI. The fanless metal chassis runs silently and mounts on a desk, wall, or with available accessories for AV racks.

Product Description

The GS116EPP 16-port Gigabit PoE+ smart-managed switch is built for commercial AV deployments that need both managed control and high PoE capacity in one unit. A 231W total PoE budget across fifteen 802.3at ports drives multiple ceiling access points, PTZ and fixed IP cameras, and PoE phones, while advanced per-port PoE controls and PoE scheduling let integrators power-cycle endpoints and conserve energy on a timetable. Uninterrupted PoE keeps powered devices online even during firmware updates or a switch reboot, which matters for always-on surveillance and paging.

Management is handled through an easy-to-use web GUI that supports port-based and 802.1Q VLANs, 802.1p and DSCP QoS, IGMP snooping, and LACP link aggregation, so AV control, video, and data stay segmented and prioritized. A dedicated SFP port provides a fiber uplink for longer runs between rooms or floors, and the 32 Gbps non-blocking fabric keeps multicast video moving cleanly. The fanless 286 x 102 x 27 mm metal case stays silent for occupied spaces. To compare other PoE and managed switches, browse the full NETGEAR switch collection at Creation Networks. The GS116EPP carries a NETGEAR 5-year hardware warranty.

Key Features

• Fifteen PoE+ Ports — Fifteen 802.3at ports deliver up to 30W each to power access points, IP cameras, and VoIP phones.
• 231W PoE Budget — A 231W total power budget supports dense PoE deployments from a single managed switch.
• Dedicated SFP Uplink — One SFP fiber port enables longer uplinks between rooms or floors using available 1G transceivers.
• VLAN and QoS — Port-based and 802.1Q VLANs plus 802.1p and DSCP QoS segment and prioritize AV control, video, and data.
• PoE Scheduling and Controls — Advanced per-port PoE controls and scheduling let you power-cycle endpoints and save energy on a timetable.
• Uninterrupted PoE — Powered devices stay online during firmware updates and switch reboots for always-on AV endpoints.
• Link Aggregation — Static LAG and LACP allow port bonding for greater uplink bandwidth or redundancy.
• Fanless Silent Chassis — Zero acoustic noise makes the switch suitable for boardrooms and other occupied spaces.
• 5-Year Warranty — Backed by a NETGEAR 5-year hardware warranty with registration.

Typical Applications

• Conference Room — Powers ceiling access points, video bars, and IP phones while segmenting AV traffic with VLANs.
• Boardroom — Provides managed, prioritized connectivity for high-resolution displays, cameras, and conferencing endpoints.
• Training Room — Drives multiple PoE cameras and access points for hybrid instruction and recording.
• House of Worship — Supplies PoE to cameras, speakers, and APs for streaming and reinforcement, with uninterrupted PoE for live services.
• Government Space — Delivers segmented, QoS-managed networking for surveillance and secure AV systems.
• Commercial Meeting Space — Centralizes power and managed switching for flexible, multi-room AV setups.

Technical Specifications

Specifications sourced from the NETGEAR datasheet.

Frequently Asked Questions

Is the GS116EPP compatible with my existing PoE devices?
Yes. The fifteen PoE+ ports follow the IEEE 802.3af and 802.3at standards, so they power standards-compliant access points, IP cameras, and VoIP phones at up to 30W per port within the 231W budget.

How difficult is it to install and configure?
The switch is desktop or wall-mountable and managed through a browser-based GUI. Basic VLAN, QoS, and PoE settings are straightforward to configure, and the switch operates with default settings out of the box if you prefer plug-and-play.

Can I use it with AV-over-IP and conferencing systems?
Yes. Port-based and 802.1Q VLANs, 802.1p and DSCP QoS, and IGMP snooping let you segment and prioritize AV control, multicast video, and conferencing traffic on the same switch.

What does the SFP port do?
The dedicated SFP port accepts a 1G fiber transceiver (sold separately) for uplinks over longer distances between rooms or floors where copper cabling is impractical.

Does PoE stay on during a firmware update?
Yes. Uninterrupted PoE keeps powered devices such as cameras and phones online even while the switch updates firmware or performs a software reboot.

What warranty and support are included?
The GS116EPP comes with a NETGEAR 5-year hardware warranty and 90 days of free technical support with product registration, with extended ProSUPPORT service plans available.
