Gator G-TOUR 16U CAST – 16U ATA Rolling Rack Case

Product Overview

The Gator G-TOUR 16U CAST is a 16U ATA flight rack case engineered for touring, staging, and broadcast environments where rack-mounted gear has to survive repeated transport. This rolling rack case pairs 9mm plywood construction with heavy-duty 4-inch casters, giving integrators and production crews a mobile 19" rack that protects power amps, wireless systems, and signal processing. With 17" rackable depth and tour-grade hardware, it is built for AV equipment racks that move between venues. It is a practical choice for rental houses, houses of worship, and mobile production rigs.

Product Description

The G-TOUR Series is Gator's heavy-duty line of audio rack cases, and the 16U CAST delivers 16 rack spaces of protected, transportable rack capacity. The case is constructed from 9mm plywood with a laminated PVC exterior, reinforced stackable ball corners, and a tongue-and-groove extruded aluminum valance that guides the lids on and off. Front and rear 3.2mm thick rack rails accept standard 19" rack-mount equipment and hold gear securely under road conditions. Eight recessed twist latches and four spring-loaded, rubber-grip handles make loading and access straightforward for crews working under time pressure. Four fixed 4-inch heavy-duty casters, two with locking brakes, let a loaded rack be rolled into position and held in place during setup. The gasketed lid adds water resistance for outdoor staging and transit. Typical payloads include power amplifiers, EQs, compressors, wireless microphone systems, and effects units. For smaller mobile rigs, compare the G-TOUR 10U CAST, or browse the full Gator rack and case collection for fixed-install alternatives.

Key Features

• 9mm Plywood Construction — Rugged 9mm plywood with a laminated PVC exterior stands up to repeated touring and transport.
• 3.2mm Rack Rails — Heavy-duty front and rear 3.2mm thick rack rails secure 19" rack-mount equipment under road conditions.
• 17" Rackable Depth — Provides 17" of rackable depth with the lid removed for standard audio and AV components.
• Locking Casters — Four fixed 4-inch heavy-duty casters, two with locking brakes, allow mobility and stable positioning.
• Tour-Grade Hardware — Recessed red twist latches, spring-loaded rubber-grip handles, zinc-plated hardware, and reinforced stackable ball corners.
• Gasketed Lid — Gasketed lid construction adds water resistance for outdoor staging and transit.
• ATA Rated — Meets ATA standards for the demands of air and ground touring.

Typical Applications

• Touring and staging production rigs
• House of worship audio systems
• Broadcast studio and remote production
• Rental and staging house inventory
• Auditorium and multi-purpose room AV racks

Technical Specifications

Specifications sourced from the Gator Cases manufacturer listing.

Frequently Asked Questions

What equipment fits in the G-TOUR 16U CAST?
It accepts any standard 19" rack-mount equipment across 16 rack units, with 17" of rackable depth — power amplifiers, EQs, compressors, wireless microphone systems, and effects units are common payloads.

Does it use standard 19" rack rails?
Yes. The case has front and rear 3.2mm thick rack rails sized for the standard 19" EIA rack-mount footprint, so threaded rack screws and standard rack ears mount directly.

How is gear mounted and accessed?
Equipment is mounted to the front and rear rails; the front and rear lids are removed via eight recessed twist latches for full access during installation and service.

Is it suitable for permanent AV system integration?
It is designed as a mobile transport rack rather than a fixed-install enclosure. For permanent installs, a stationary 19" rack is usually preferred, but the G-TOUR 16U CAST integrates well into mobile and touring AV systems.

Can a loaded rack be rolled and locked in place?
Yes. Four 4-inch heavy-duty casters allow a fully loaded rack to be rolled into position, and two locking casters hold it stationary during setup and operation.

What warranty applies?
It carries the Gator Cases Limited Lifetime Warranty against manufacturing defects. Moving parts such as wheels are covered for one year. The warranty excludes use in a rental capacity.

Where can I get support?
Creation Networks supports product selection and integration questions, and Gator Cases provides warranty service and field-replaceable parts through its Tampa, Florida team.
