Extron XTP DTP 24 Punch Down Jack - Shielded RJ-45 AAP Mini Module Package of 10
Extron XTP DTP 24 Punch Down Jack - Shielded RJ-45 AAP Mini Module Package of 10 is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Looking for a specific Extron product or custom AV solution? Our certified experts can source any Extron device to meet your project requirements. Please contact Creation Networks for a personalized quote or to learn more about our certified Extron design, programming, installation and maintenance services for conference rooms, auditoriums, training centers, and hybrid collaboration spaces. Creation Networks offers direct technical support during the initial Extron implementation and future support of Extron products as needed.
Extron XTP DTP 24 Punch Down Jack - Shielded RJ-45 AAP Mini Module ...
Extron XTP DTP 24 Punch Down Jack is a single-space MAAP Mini AV Connectivity Module featuring one shielded RJ-45 punch down jack optimized for Extron XTP DTP 24 Shielded Twisted Pair Cable. This passive installation module enables secure, permanent termination of CAT 6A shielded cable for high-bandwidth signal distribution in professional AV systems. The mountable metal plate construction provides robust, durable integration into architectural environments, maintaining signal integrity without active electronics or power requirements.
This jack is ideal for conference rooms, classrooms, control rooms, lecterns, table boxes, and wall-mounted applications requiring fixed termination points for shielded twisted pair runs carrying 4K/8K video, embedded audio, RS-232/IR control, and Ethernet in XTP or DTP systems. It supports clean, behind-the-scenes wiring in Extron MAAP-compatible frames, select interfaces, and enclosures, delivering reliable, interference-resistant performance in modular AV setups.
Features Chart
| Feature | Benefit |
|---|---|
| Single-space MAAP Mini form factor | Compact integration into Extron interfaces, MAAP frames, and compatible enclosures |
| Shielded RJ-45 punch down jack | Allows permanent, secure termination of Extron XTP DTP 24 shielded twisted pair cable |
| CAT 6A compatible | Supports high-bandwidth transmission for 4K/60 4:4:4 video, audio, control, and data |
| Shielded cable optimization | Reduces EMI/RFI and crosstalk for reliable long-distance AV signals |
| Mountable metal plate | Ensures professional durability, secure mounting, and vibration resistance |
| Pass-through termination | Maintains full signal integrity with no latency, power needs, or active processing |
| MAAP Mini series compatibility | Fits seamlessly into Extron's compact architectural connectivity ecosystem |
| Tool-based punch down | Provides fast, reliable field termination with standard punch down tools |
Specifications Table
| Specification | Details |
|---|---|
| Connector Type | One shielded RJ-45 punch down jack |
| Cable Compatibility | Extron XTP DTP 24 Shielded Twisted Pair Cable |
| Cable Category | CAT 6A |
| Form Factor | Single Space MAAP Mini module |
| Mounting | Mountable metal plate |
| Type | Installation / Punch down |
| Compatibility | Select Extron interfaces, MAAP AV connectivity mounting frames, MAAP-compatible products |
| Signal Type | High-speed shielded twisted pair termination (optimized for XTP/DTP systems) |
| Size | Single Space |
Compare Chart
| Aspect | Extron XTP DTP 24 Punch Down Jack | Extron MAAP1XTPFTP24PDJ | Extron XTP DTP 22 RJ-45 Coupler |
|---|---|---|---|
| Connector Type | Shielded RJ-45 punch down | XTP DTP 24 RJ-45 punch down | Shielded RJ-45 coupler |
| Cable Compatibility | XTP DTP 24 shielded | XTP DTP 22/24 shielded | XTP DTP 22 shielded |
| Form Factor | Single Space MAAP Mini | Single Space MAAP Mini | Single Space AAP |
| Mounting System | MAAP frames/enclosures | MAAP frames/enclosures | AAP frames/enclosures |
| Termination Method | Punch down (permanent) | Punch down (permanent) | Barrel coupler (extension) |
| Primary Use | Fixed shielded cable termination | Fixed shielded cable termination | In-line shielded extension |
| Ideal For | Permanent wired drops in XTP/DTP | Similar fixed terminations | Extend existing shielded runs |
FAQ
- What cable is this jack designed for? It is specifically for Extron XTP DTP 24 Shielded Twisted Pair Cable, optimized for high-bandwidth AV signal termination.
- Which mounting systems are compatible? It fits select Extron interfaces, MAAP AV connectivity mounting frames, wall boxes, table boxes, and other products accepting MAAP Mini modules.
- Why use a punch down jack? Punch down provides permanent, secure termination for fixed cable runs, reducing the risk of disconnection compared to couplers.
- Does it require power or active components? No, it is a fully passive installation module with no electronics or power needs.
- Can it support 4K video over long distances? Yes, when properly terminated on XTP DTP 24 cable, it maintains CAT 6A performance for uncompressed 4K/60 signals up to system limits.
- Is it suitable for professional AV terminations? Yes, the shielded design, metal plate, and Extron optimization ensure durable, high-performance connectivity in conference rooms, classrooms, and architectural installations.
