Extron UCS 303 Three Input 4K/60 Collaboration and Presentation Switcher

Product Description

The Extron UCS 303 Three Input 4K/60 Collaboration and Presentation Switcher is a three-input, one-output collaboration switcher that combines AV source switching with USB peripheral switching for unified communications and BYOM (Bring Your Own Meeting) spaces. Its inputs support HDMI with USB, DisplayPort with USB, and USB-C, while the HDMI output drives displays at resolutions up to 4K/60. The USB-C input carries video, audio, USB data, and up to 60 watts of power over a single cable, simplifying laptop connectivity in commercial meeting rooms.

As a 4K collaboration and presentation switcher, the UCS 303 routes up to five USB room peripherals — such as cameras and microphones — to the active source, making it well suited to Microsoft Teams and Zoom meetings. Two USB ports operate at rates up to USB 10Gbps with 5V, 900 mA power, and three ports operate at High Speed (USB 2.0) with 5V, 500 mA power. USB breakaway switching lets video and audio route to the display independently of the USB data bus, so a dedicated room computer can retain the cameras and microphones while other inputs present content.

Auto-input switching and Show Me cable support make the UCS 303 ideal for BYOM and presentation rooms without a dedicated control system, automatically prioritizing connected laptops and reverting to a room computer when a laptop disconnects. The compact 1U, half-rack metal enclosure mounts under a table, in furniture, or in a rack. For single-stream rooms that need a smaller switcher, consider the Extron UCS SW 313 3x1 4K/60 collaboration switcher, or browse the full Extron collection at Creation Networks.

Key Features

• Three-Input Collaboration Switching — The UCS 303 switches three AV sources — HDMI with USB, DisplayPort with USB, and USB-C — to a single HDMI output for the room display.
• 4K/60 Video Support — The switcher supports computer and video resolutions up to 4096x2160 at 60 Hz with 4:4:4 chroma sampling and a maximum data rate of 18 Gbps.
• Integrated USB Peripheral Switching — Up to five USB room devices route to the active source, with two ports at USB 10Gbps and three at High Speed USB 2.0 for cameras and microphones.
• Single-Cable USB-C Connectivity — The USB-C input carries video, audio, USB data, and up to 60 watts of USB Power Delivery over one cable to charge and connect a laptop.
• USB Breakaway Switching — Video and audio can be switched to the display independently of the USB data bus, keeping peripherals connected to a dedicated computer when needed.
• Auto-Input Switching — The switcher automatically selects an active input by priority, ideal for BYOM rooms that operate without a control system.
• HDCP 2.3 Compliance — The UCS 303 is HDCP 2.3 compliant and supports HDR formats including HDR10, HDR10+, and Dolby Vision while maintaining interoperability with earlier HDCP versions.
• EDID Minder and Display Control — EDID Minder manages EDID communication automatically, and the unit offers RS-232 and CEC display control plus Ethernet monitoring and control.
• Show Me Cable Compatibility — Show Me cables allow users to share content with a single button press, eliminating the need for a separate control panel in simple rooms.
• Compact Internal-Power Enclosure — A 1U, half-rack metal enclosure with an internal Extron Everlast power supply mounts discreetly under a table, in furniture, or in a rack.

Technical Specifications

Frequently Asked Questions

What sources and meeting platforms does the UCS 303 support?

The UCS 303 accepts HDMI, DisplayPort, and USB-C sources and routes USB cameras and microphones to the active laptop or computer, making it compatible with Microsoft Teams, Zoom, and other unified communications platforms in BYOM rooms.

Can the UCS 303 operate without a control system?

Yes. Auto-input switching and Show Me cable support let users share content and connect peripherals with minimal hardware interaction, so the switcher works well in presentation and BYOM spaces that do not have a dedicated control system or touch panel.

How does USB breakaway switching work on the UCS 303?

USB breakaway switching allows video and audio to route to the display independently of the USB data bus. This lets a dedicated room computer keep the cameras and microphones connected while other inputs present content to the display.

How is the UCS 303 installed and mounted?

The UCS 303 ships in a compact 1U, half-rack metal enclosure with an internal power supply. It can be mounted under a table, concealed in furniture or behind a flat-panel display, or installed in an equipment rack with an optional 1U rack shelf.

How does the UCS 303 compare to the UCS SW 313?

Both are Extron 4K/60 collaboration and presentation switchers. The UCS 303 offers three inputs with USB-C power delivery and five USB peripheral ports, while the UCS SW 313 3x1 switcher is a streamlined alternative for rooms with simpler switching requirements.

What warranty and support are included?

The UCS 303 carries a 3-year parts and labor warranty, and the internal Extron Everlast power supply is covered for 7 years. Creation Networks provides AV system integration guidance and post-sales support; see the Extron collection for compatible accessories.
