Extron SMP Series Remote Control Panel – MK Mount
Extron SMP Series Remote Control Panel – MK Mount is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise? Give us a call at 1-888-230-3661 or LiveChat below. Purchasing 1 or 100, there may be greater savings beyond the advertised price.
Looking for a specific Extron product or custom AV solution? Our certified experts can source any Extron device to meet your project requirements. Please contact Creation Networks for a personalized quote or to learn more about our certified Extron design, programming, installation and maintenance services for conference rooms, auditoriums, training centers, and hybrid collaboration spaces. Creation Networks offers direct technical support during the initial Extron implementation and future support of Extron products as needed.
Extron SMP Series Remote Control Panel – MK Mount
The Extron RCP 401 is a compact, wall-mountable remote control panel designed for intuitive operation of Extron control systems in professional AV environments. It features four customizable backlit soft-touch buttons and a rotary volume control knob with LED level indicators, enabling direct control of functions such as source selection, display power, volume adjustment, and mute. The panel connects via standard Ethernet to compatible Extron control processors, supporting seamless integration into network-based AV automation setups.
Powered over Ethernet (PoE), the RCP 401 eliminates the need for local power supplies and simplifies cabling. Its buttons are fully customizable using Extron Button Label Generator software, allowing tailored labels and command assignments for specific room requirements. The durable construction and one-gang form factor make it suitable for discreet wall mounting in standard junction boxes.
This remote panel is ideal for classrooms, conference rooms, boardrooms, lecture halls, and huddle spaces where users need quick, reliable access to essential AV controls without relying on touchscreens or handheld remotes, enhancing usability in Extron IPCP Pro or IPL Pro controlled systems.
Features Chart
| Feature | Benefit |
|---|---|
| Four customizable backlit soft-touch buttons | Provides intuitive control of sources, power, mute, or custom functions |
| Rotary volume control knob with LEDs | Enables smooth, precise audio level adjustments with visual feedback |
| Standard Ethernet connectivity | Integrates into existing networks for reliable system communication |
| PoE powered | Reduces installation complexity with single-cable power and data |
| Customizable button labels via software | Allows room-specific labeling and function assignment |
| One-gang compact design | Fits standard wall boxes for discreet, professional installation |
| Backlit buttons for visibility | Ensures clear operation in low-light presentation environments |
| Compatible with Extron control processors | Works seamlessly with IPCP Pro, IPL Pro, and network AV systems |
Specifications Table
| Specification | Details |
|---|---|
| Controls | 4 backlit soft-touch buttons; 1 rotary volume knob |
| Indicators | LEDs for volume level; button backlighting |
| Connectivity | 1 female RJ-45 (Ethernet/LAN/PoE) |
| Power | PoE (IEEE 802.3af Class 3) |
| Mounting | One-gang wall box (standard or EU compatible) |
| Customization | Button Label Generator software |
| Form Factor | One-gang wall-mount |
| Operating Temperature | +32 to +122 °F (0 to +50 °C) |
| Weight | Approximately 0.3 lbs (0.14 kg) |
Compare Chart
| Aspect | Extron RCP 401 | Extron NBP VC1 EU | Extron NBP 104 EU |
|---|---|---|---|
| Controls | 4 buttons + rotary volume knob | 1 button + rotary volume knob | 4 customizable buttons |
| Volume Control | Rotary knob with LED indicators | Rotary knob with 5 LEDs | Configurable via buttons |
| Button Count | 4 backlit soft-touch | 1 backlit soft-touch | 4 backlit soft-touch |
| Power Source | PoE | PoE | PoE |
| Form Factor | One-gang wall-mount | One-gang EU/Flex55 | One-gang EU/Flex55 |
| Primary Function | Combined source/volume control | Dedicated volume control | General customizable control |
| Customization | Full button labeling | Mute button customization | Full button labeling |
| Mounting Flexibility | Standard wall boxes | EU/Flex55 systems | EU/Flex55 systems |
FAQ
- What AV functions can the RCP 401 control? It manages source switching, display power on/off, volume adjustment, mute, and other custom commands configured through an Extron control processor.
- How is volume adjusted on the panel? The rotary knob provides smooth incremental control, with integrated LEDs indicating the current audio level.
- Is PoE required for operation? Yes, the panel is powered via PoE over its Ethernet connection, combining power and control data in one cable.
- Can the buttons be customized? Yes, Extron Button Label Generator software allows complete customization of button labels and assigned functions.
- What mounting options does it support? It installs in standard one-gang wall boxes, compatible with typical US and international junction boxes.
- Which Extron systems is it compatible with? It integrates with Extron IPCP Pro series, IPL Pro processors, and other Ethernet-based AV control platforms.
