Extron RCP 101 Remote Control Panel SMP Series Remote Control Panel...
Extron RCP 101 is a compact, single-gang remote control panel designed for simple, intuitive AV system control in professional installations. It features three customizable backlit buttons with laser-etched legends and an integrated volume knob for precise level adjustment. The panel provides direct control over Extron control processors via Ethernet or RS-232, enabling functions such as source selection, power on/off, volume control, and preset recall. Constructed with a durable metal faceplate and available in black or white, it integrates seamlessly into standard single-gang wall boxes or furniture for a clean, architectural appearance.
This remote panel is ideal for conference rooms, classrooms, huddle spaces, and presentation environments where users need quick, reliable access to AV system functions without complex interfaces. It supports easy configuration through Extron's Global Configurator software, allowing button functions to be tailored to specific room needs. The backlit buttons offer clear visibility in low-light conditions, while the rotary knob delivers smooth, tactile volume control. Compatible with Extron control systems, it delivers dependable performance in integrated AV setups requiring user-friendly, wall-mounted control.
Features Chart
| Feature | Benefit |
|---|---|
| Three customizable backlit buttons | Enable intuitive control of sources, presets, power, or other functions with clear visual feedback |
| Integrated rotary volume knob | Provides precise, analog-style level adjustment for audio output |
| Ethernet and RS-232 connectivity | Allows flexible integration with Extron control processors over network or serial links |
| Laser-etched button legends | Ensures durable, readable labeling that withstands frequent use |
| Backlit illumination | Offers excellent visibility in dim environments for user convenience |
| Single-gang metal faceplate | Fits standard wall boxes or furniture for seamless architectural integration |
| Black or white finish options | Allows matching to room decor for a professional, unobtrusive appearance |
| Global Configurator support | Simplifies custom programming and deployment in Extron control systems |
Specifications Table
| Specification | Details |
|---|---|
| Control Interfaces | Ethernet (10/100Base-T), RS-232 (bidirectional) |
| Buttons | Three illuminated pushbuttons with laser-etched legends |
| Volume Control | Rotary encoder knob with push-to-mute function |
| Form Factor | Single-gang wall box or furniture mount |
| Faceplate Material | Metal |
| Colors | Black or White |
| Power | Powered via PoE or external 12 VDC supply (not included) |
| Compatibility | Extron control processors (IPL Pro, IPCP Pro, NetPA, etc.) |
| Dimensions | Fits standard single-gang electrical box |
Compare Chart
| Aspect | Extron RCP 101 | Extron RCP 101M (MediaLink variant) | Extron TLP Pro 1230 (Touchpanel example) |
|---|---|---|---|
| Control Type | Buttons + rotary knob | Buttons + rotary knob | Capacitive touchscreen |
| User Interface | Physical buttons/knob | Physical buttons/knob | Graphical touch interface |
| Form Factor | Single-gang wall/furniture | Single-gang wall/furniture | Tabletop or wall-mount touchpanel |
| Customization | Configurable via software | Configurable via software | Fully graphical, highly customizable |
| Connectivity | Ethernet/RS-232 | Ethernet/RS-232 | Ethernet (IP Link control) |
| Primary Use | Simple AV system control | MediaLink system control | Advanced room control with visuals |
| Ideal For | Basic room AV control | MediaLink-equipped rooms | Complex systems with dynamic interfaces |
| Power Source | PoE or 12 VDC | PoE or 12 VDC | External power supply |
FAQ
- What functions can the RCP 101 control? It supports source selection, power on/off, volume adjustment, preset recall, and other commands configured via Extron control processors.
- How is the RCP 101 powered? It uses PoE (Power over Ethernet) or an optional 12 VDC external supply, providing flexible installation options.
- Can the buttons be customized? Yes, button functions and legends are fully programmable using Extron Global Configurator software.
- Does it require a specific control system? It is compatible with Extron control processors that support Ethernet or RS-232, such as IPL Pro and IPCP Pro series.
- Why choose the RCP 101 over a touchscreen? It offers simple, tactile control with no screen for environments needing straightforward, reliable operation without complex interfaces.
- Is it suitable for public or high-use areas? Yes, the durable metal faceplate, backlit buttons, and robust design make it reliable for frequent use in conference rooms and classrooms.
