Extron PCC 118-500 8-Input 4K Presentation Control Center White
Extron PCC 118-500 8-Input 4K Presentation Control Center White is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise? Give us a call at 1-888-230-3661 or LiveChat below. Purchasing 1 or 100, there may be greater savings beyond the advertised price.
Extron PCC 118-500 8-Input 4K Presentation Control Center White
Extron PCC 118-500 is a compact 1U, half-rack width presentation control center engineered for small to medium conference rooms, classrooms, and huddle spaces requiring 4K signal handling. It offers eight AV inputs (four HDMI, two VGA with audio, one USB-C, one DisplayPort) with automatic input switching, integrated 4K scaling, seamless transitions, and EDID management. The unit supports HDMI 2.0, HDCP 2.3, stereo audio embedding/de-embedding, RS-232/IR control ports, Ethernet for network integration, and configurable contact closure inputs for automation. Built in a durable metal enclosure, it provides reliable, high-performance AV switching and signal processing.
This control center is ideal for fixed installations demanding 4K source compatibility and simple operation without large rack space. It handles HDMI, VGA, USB-C, and DisplayPort sources with auto-detection, auto-switching, and output scaling to match connected displays up to 4K/60 4:4:4. Front-panel controls and backlit buttons allow local operation, while Ethernet/RS-232 enables remote management via Extron control processors or third-party systems.
Features Chart
| Feature | Benefit |
|---|---|
| Eight 4K-capable AV inputs | Supports HDMI (4), VGA with audio (2), USB-C (1), DisplayPort (1) for diverse source compatibility |
| Auto-input switching | Automatically selects and switches to the active source for seamless presentations |
| Integrated 4K scaling | Outputs up to 4K/60 4:4:4 with high-quality image processing and aspect ratio control |
| Audio embedding/de-embedding | Routes stereo audio from digital/analog sources with flexible output options |
| EDID and HDCP management | Ensures reliable source-display compatibility and protected content handling |
| Ethernet/RS-232/IR control | Enables network, serial, or infrared integration with control systems |
| Contact closure inputs | Supports room sensors, switches, or external triggers for automated functions |
| Compact 1U half-rack enclosure | Saves valuable rack or furniture space while maintaining professional durability |
Specifications Table
| Specification | Details |
|---|---|
| Inputs | 4 × HDMI 2.0, 2 × VGA (with stereo audio), 1 × USB-C, 1 × DisplayPort |
| Outputs | 1 × HDMI 2.0 (scaled) |
| Maximum Resolution | 4096×2160 @ 60 Hz 4:4:4 (4K/60) |
| Scaling | Integrated up/down scaling with aspect ratio control |
| Audio Support | Stereo embedding/de-embedding, balanced/unbalanced routing |
| Control Interfaces | Ethernet (10/100/1000Base-T), RS-232, IR, contact closure (4) |
| Power | Internal universal power supply (100-240 VAC, 50/60 Hz) |
| Enclosure | Metal, 1U half-rack width |
| Mounting | Rack-mount ears included, tabletop or under-table options |
Compare Chart
| Aspect | Extron PCC 118-500 | Extron PCC 118-20 | Extron IN1808 xi |
|---|---|---|---|
| Input Count | 8 (HDMI/VGA/USB-C/DP) | 8 (HDMI/VGA/USB-C/DP) | 8 (HDMI/DisplayPort) |
| Maximum Resolution | 4K/60 4:4:4 | 1920x1200 / 1080p | 4K/60 4:4:4 |
| Scaling | Integrated 4K scaling | Integrated HD scaling | Advanced 4K scaling |
| Form Factor | 1U half-rack | 1U half-rack | 1U full-rack |
| Audio Handling | Stereo embed/de-embed | Stereo embed/de-embed | Multi-channel embed/de-embed |
| Control Ports | Ethernet/RS-232/IR/Contacts | Ethernet/RS-232/IR/Contacts | Ethernet/RS-232/IR/USB/Contacts |
| Primary Use | 4K room switching/scaling | HD room switching/scaling | Advanced 4K presentation |
| Ideal For | 4K small-medium rooms | HD small-medium rooms | Larger or high-end rooms |
FAQ
- What input types does the PCC 118-500 support? It accepts four HDMI 2.0, two VGA (with audio), one USB-C, and one DisplayPort, covering a wide range of modern and legacy presentation sources.
- Does it handle 4K content natively? Yes, with integrated scaling to 4K/60 4:4:4, HDMI 2.0 support, and HDCP 2.3 compliance for protected 4K sources.
- How is audio processed? It embeds stereo audio from digital inputs and de-embeds to analog outputs, with routing flexibility for AV systems.
- Can it be controlled remotely? Yes, via Ethernet for network integration, RS-232 for serial control, or IR for direct line-of-sight operation.
- Is it suitable for rack or furniture mounting? Yes, the 1U half-rack width includes rack ears and supports tabletop, under-table, or furniture mounting.
- What environments is it best suited for? It excels in small to medium conference rooms, classrooms, and huddle spaces needing 4K-capable switching, scaling, and control in a compact footprint.
