Extron NetPA 1001-1AT 100 W Network Power Amplifier - Dante/AES67
The Extron NetPA 1001-1AT is a single-channel 100 watt networked power amplifier designed for professional distributed audio systems using Dante or AES67 networked audio. It accepts a single Dante/AES67 digital audio channel over standard Ethernet infrastructure and delivers 100 watts of clean, high-fidelity power to low-impedance loudspeakers (4/8 ohms) or 70/100 V distributed audio systems. This makes it ideal for applications requiring high-quality background music, paging, or zoned audio reinforcement in classrooms, conference rooms, auditoriums, open offices, retail spaces, and large venues.
The amplifier supports Dante Domain Manager and AES67 for interoperability with Dante-enabled devices, features Extron's ProDSP processing with EQ, dynamics, delay, and filtering, and includes front-panel controls, status LEDs, and Ethernet connectivity for remote configuration and monitoring via Extron DSP Configurator software. Its compact 1U, half-rack width enclosure with integrated mounting options suits rack installations, while the fanless design ensures quiet operation in noise-sensitive environments.
Features Chart
| Feature | Benefit |
|---|---|
| Single Dante/AES67 Input Channel | Receives high-quality networked audio over standard Ethernet |
| 100 W Output Power | Drives low-impedance (4/8 ohm) or 70/100 V loudspeakers effectively |
| ProDSP Audio Processing | EQ, dynamics, delay, filtering, and mixing for optimized sound quality |
| Dante Domain Manager & AES67 Support | Enables advanced network management and interoperability |
| DSP Configurator Software | Intuitive drag-and-drop setup, real-time monitoring, and preset management |
| Fanless, Compact 1U Half-Rack Design | Quiet operation and space-efficient rack or surface mounting |
| Front-Panel Controls & Status LEDs | Quick on-site adjustments and visual system status verification |
| Ethernet Remote Control | Allows configuration, monitoring, and firmware updates over the network |
Specifications Table
| Specification | Details |
|---|---|
| Input | 1 Dante/AES67 channel over Ethernet RJ-45 |
| Output | 100 W @ 4/8 ohms or 70/100 V distributed |
| DSP Processing | EQ, dynamics, delay, filtering, mixing, gain control |
| Network Audio | Dante / AES67 compliant |
| Power Output | 100 W continuous pink noise (4/8 ohm); 70/100 V taps |
| Frequency Response | 20 Hz to 20 kHz, ±0.5 dB |
| THD + Noise | <0.05% @ 1 kHz, rated power |
| Control Interfaces | Ethernet, front-panel controls, DSP Configurator |
| Power Supply | Internal universal power supply |
| Mounting | 1U, half-rack width with mounting kit |
| Applications | Networked distributed audio reinforcement |
| Compatibility | Dante/AES67 devices; Extron DSP Configurator |
Compare Chart
| Aspect | Extron NetPA 1001-1AT | Extron NetPA 502 | QSC CXD-Q 4-Channel |
|---|---|---|---|
| Channels/Power | 1 channel / 100 W | 2 channel / 50 W per ch | 4 channel / varies |
| Network Audio | Dante / AES67 | Dante / AES67 | Q-LAN / Dante |
| DSP Processing | ProDSP (EQ/dynamics/delay) | ProDSP | Advanced DSP |
| Output Options | 4/8 ohm & 70/100 V | 4/8 ohm & 70/100 V | 2/4/8 ohm & 70/100 V |
| Form Factor | 1U half-rack | 1U half-rack | 2U rack-mount |
| Fanless Operation | Yes | Yes | No |
| Primary Use | Single-zone high-power audio | Dual-zone distributed | Multi-zone high-power |
| Extron Optimization | Yes | Yes | No |
FAQ
- What is the main purpose of the NetPA 1001-1AT? It amplifies a single Dante/AES67 networked audio channel to drive 100 watts into 4/8 ohm speakers or 70/100 V distributed systems.
- Does it include DSP processing? Yes, it features Extron ProDSP with EQ, dynamics, delay, filtering, and mixing configurable via DSP Configurator software.
- What output options are available? It supports low-impedance 4/8 ohm loads and 70/100 V distributed audio systems for flexible loudspeaker configurations.
- Is it fanless? Yes, the fanless design ensures silent operation in noise-sensitive environments like classrooms or conference rooms.
- How is it powered and controlled? It uses an internal universal power supply and is controlled via Ethernet for remote setup, monitoring, and firmware updates.
- What network protocols does it support? It is Dante-compatible and AES67 compliant, with support for Dante Domain Manager for advanced network management.
