Extron MMK 6 – Mullion Mount Kit for TLS 1035M, Aluminum

Product Overview

MMK 6 (Aluminum), part number 70-1333-38. The Extron MMK 6 is a mullion mount kit for scheduling panels, designed specifically for the TLS 1035M. It secures the panel to the vertical frame that separates a door opening from the adjacent glass wall, which is the only viable mounting surface in most glass-fronted conference rooms. The low-profile design projects less than 4 inches from the mullion and keeps the panel's side LED indication visible from both approaches. It is available in black and aluminum matte finishes to match common storefront and door frame systems.

Product Description

Glass-fronted meeting rooms create a recurring mounting problem: there is no wall next to the door. The mullion, the vertical frame member between the door opening and the fixed glass, is often the only surface available, and it is narrow. The MMK 6 is engineered for that specific condition rather than adapted to it.

The mount holds a TLS 1035M securely on the mullion with a profile that projects less than 4 inches from the frame, which keeps it within ADA-compliant protrusion limits in circulation paths. That is not a cosmetic detail; a panel that projects too far into a corridor is a code problem, not just an aesthetic one.

Appearance was designed to work from outside the room, where the panel is actually seen. The mount's proportions blend with the panel and the mullion frame rather than reading as an add-on bracket, and the side LED status lights remain fully visible on both edges of the panel so at-a-glance availability still works.

Two finishes are offered, black and aluminum matte, so the mount can be matched to the door hardware and frame system rather than standing out against it. Where the panel needs an upward viewing tilt at ADA mounting height, the optional MMK 5/6 Angle Brackets provide that adjustment. For the 8 inch Extron TLS 835M, specify the MMK 5 instead.

Key Features

• Purpose-built for the TLS 1035M — Designed specifically for the Extron TLS 1035M scheduling panel rather than adapted from a generic bracket.
• Mounts to the door mullion — Secures the panel to the vertical frame between the door opening and adjacent glass, the usual only surface in glass-fronted rooms.
• Low profile — Projects less than 4 inches from the mullion frame, keeping the installation within ADA protrusion limits in circulation paths.
• LED status stays visible — The design leaves the panel's side LED indication visible on both edges so at-a-glance availability still works.
• Two matched finishes — Available in black and aluminum matte to match common door hardware and storefront frame systems.
• Optional angle brackets — Accepts the MMK 5/6 Angle Brackets for upward display tilt at ADA-compliant mounting heights.

Typical Applications

• Conference room
• Boardroom
• Huddle room
• Commercial meeting space
• Multi-purpose room
• Government space

Technical Specifications

Specifications sourced from Extron product documentation.

Frequently Asked Questions

Which panel does the MMK 6 fit?

The Extron TLS 1035M, the 10.1 inch wall mount TouchLink scheduling panel. For the 8 inch TLS 835M, use the MMK 5 instead.

Is the mounted assembly ADA compliant?

The mount is designed as a low-profile, ADA-compliant solution projecting less than 4 inches from the mullion frame. Final compliance always depends on installed height and the specific circulation path, so verify against your local code review.

Do the panel's status LEDs stay visible?

Yes. The mount is designed so the LED lights on either side of the panel remain visible after installation, preserving at-a-glance room status from both approach directions.

What finishes are available?

Black (70-1333-32) and aluminum matte (70-1333-38). Choose to match the door frame and hardware; both are functionally identical.

Can the panel be tilted for better viewing?

Yes, with the optional MMK 5/6 Angle Brackets, sold separately in packs of five. They provide upward tilt so the panel reads correctly when mounted at ADA height.

Will it work on any door mullion?

It is designed for the vertical frame member separating a door opening from adjacent glass in typical commercial storefront systems. Confirm mullion width and depth against the mount dimensions during design, especially on non-standard frame systems.
