Extron MIX 301 Three-Input Stereo Audio Mixer
The Extron MIX 301 is a compact three-input stereo audio mixer designed for professional AV presentation systems requiring simple source mixing. It accepts three unbalanced stereo audio inputs on dual RCA connectors and provides a single balanced or unbalanced stereo output on captive screw terminals, with independent level controls for each input. This mixer is ideal for combining multiple line-level sources—such as laptops, media players, microphones with preamps, or consumer devices—into a unified audio feed for amplifiers, DSPs, or presentation switchers in classrooms, conference rooms, boardrooms, training facilities, and control environments.
The MIX 301 features adjustable gain per input (±12 dB), low-noise preamplifiers, and a master output level control for precise mixing balance. Its small form factor allows easy mounting under tables, in racks, or behind equipment, while captive screw output terminals ensure secure, vibration-resistant connections in permanent installations. The passive design requires no external power, delivering reliable, straightforward audio mixing without added complexity.
Features Chart
| Feature | Benefit |
|---|---|
| Three Unbalanced Stereo Inputs | Mixes multiple line-level sources (RCA) into one output |
| Balanced/Unbalanced Stereo Output | Flexible connection to professional or consumer audio equipment |
| Independent Input Level Controls | Allows precise adjustment of each source level (±12 dB) |
| Master Output Level Control | Fine-tunes overall mix volume |
| Low-Noise Preamplifiers | Maintains clean audio with minimal distortion |
| Captive Screw Output Terminals | Secure, tool-free termination for reliable connections |
| Compact Metal Enclosure | Durable and space-efficient for rack, under-table, or surface mounting |
| Passive Design | No external power supply required |
Specifications Table
| Specification | Details |
|---|---|
| Inputs | 3 stereo (unbalanced) on dual RCA connectors |
| Output | 1 stereo (balanced/unbalanced) on 3.5 mm captive screw |
| Gain Adjustment | ±12 dB per input; master output level control |
| Frequency Response | 20 Hz to 20 kHz, ±0.5 dB |
| THD + Noise | <0.01% @ 1 kHz, nominal level |
| Crosstalk | <-80 dB @ 1 kHz |
| Power Requirement | None (passive) |
| Mounting | Compact enclosure with mounting options |
| Applications | Audio mixing in AV presentation systems |
| Compatibility | Unbalanced stereo sources; balanced/unbalanced destinations |
Compare Chart
| Aspect | Extron MIX 301 | Extron AXI 44 AT | Kramer 4-Channel Mixer |
|---|---|---|---|
| Inputs | 3 stereo (RCA) | 4 stereo (RCA) | Varies (typically 4 ch) |
| Outputs | 1 stereo (captive screw) | 4 balanced stereo | 1 or multiple |
| Gain Adjustment | ±12 dB per input + master | ±12 dB per channel | Fixed or adjustable |
| Isolation | None | Transformer per channel | Varies |
| Power | Passive | Passive | Passive or active |
| Primary Use | Simple three-source mixing | Multi-channel conversion | General audio mixing |
| Form Factor | Compact | Compact | Compact |
| Extron Optimization | Yes | Yes | No |
FAQ
- What is the main purpose of the MIX 301? It mixes three unbalanced stereo audio sources into a single balanced or unbalanced stereo output for AV presentation systems.
- Does it support balanced audio output? Yes, the output is configurable for balanced or unbalanced stereo line-level signals.
- How is input level adjusted? Each of the three inputs has an independent ±12 dB gain control, plus a master output level control for overall mix adjustment.
- Is external power required? No, the MIX 301 is fully passive and requires no power supply.
- What connectors are used? Inputs are dual RCA (unbalanced stereo for each of three sources), and output is a 3.5 mm captive screw terminal (balanced/unbalanced stereo).
- Can it be used in rack installations? Yes, its compact size and mounting options make it suitable for rack, under-table, or surface mounting in AV systems.
