Extron IN9351 - 4K/60 HDMI to HDBaseT Presentation Switcher White
The Extron IN9351 is a compact presentation switcher that routes HDMI sources to an HDBaseT twisted pair output, supporting 4K/60 4:4:4 video with embedded audio over distances up to 70 m (230 ft) on shielded CATx cable when paired with compatible HDBaseT receivers. It features EDID management, HDCP 2.3 compliance, audio de-embedding, bidirectional RS-232/IR passthrough for display control, and flexible control options (front panel, RS-232, Ethernet/IP) for professional AV switching in conference rooms, classrooms, lecture halls, boardrooms, and corporate presentation environments.
The switcher integrates with Extron HDBaseT receivers for extended-reach HDMI distribution, supports seamless switching, and mounts in a compact enclosure with rack ears included for flexible installation.
Features Chart
| Feature | Benefit |
|---|---|
| HDMI Input / HDBaseT Output | Routes HDMI sources to extended-reach displays/projectors |
| 4K/60 4:4:4 Signal Support | Handles high-resolution video with full color depth over long distances |
| HDBaseT Extension | Up to 70 m (230 ft) on shielded CATx cable with compatible receivers |
| EDID Management | Ensures compatibility and optimal resolution from sources |
| HDCP 2.3 Compliance | Supports protected content from modern devices |
| Audio De-embedding | Extracts embedded HDMI audio for separate processing or distribution |
| RS-232 / Ethernet Control | Integration with AV control systems (Crestron, AMX, Extron Global Configurator) |
| Front-Panel & Remote Operation | Easy source selection via buttons or IP/RS-232 commands |
Specifications Table
| Specification | Details |
|---|---|
| Model | Extron IN9351 |
| Power Source | Internal universal power supply (100–240 V AC) |
| Video Input | 1 × HDMI (Type A) |
| Video Output | 1 × HDBaseT twisted pair (RJ-45) |
| Maximum Resolution | 4096×2160 @ 60 Hz 4:4:4 (4K/60 HDR10, Deep Color) |
| Transmission Distance | 70 m (230 ft) on shielded CATx cable |
| HDCP Support | HDCP 2.3 |
| Audio Formats | HDMI embedded (de-embedding available) |
| Control Interfaces | Front panel buttons, RS-232, Ethernet (RJ-45) |
| Mounting | Compact enclosure (desktop/wall/rack with optional kit) |
| Dimensions | Approx. 221 mm (W) × 43 mm (H) × 210 mm (D) |
| Weight | Approx. 1.5 kg |
| Finish | Black |
| Operating Temperature | 0°C to +50°C |
Compare Chart
| Aspect | Extron IN9351 | Extron DTP CrossPoint Series | Typical Competitor HDBaseT Switcher (e.g., Atlona AT-UHD-EX-100CE) |
|---|---|---|---|
| Inputs/Outputs | 1 HDMI in / 1 HDBaseT out | Multiple HDMI in / DTP out | 1 HDMI in / 1 HDBaseT out |
| Max Distance | 70 m on CATx | 70–100 m on CATx | 70–100 m on CATx |
| Rack Size | Compact (half-rack option) | 1U half/full rack | Compact or 1U |
| Audio De-embedding | Yes | Yes | Yes |
| Primary Use | Simple long-reach HDMI extension | Multi-source HDMI switching | Point-to-point HDBaseT extension |
| Best For | Single-source presentation | Multi-source conference setups | Basic long-distance HDMI |
FAQ
- What is the IN9351 best used for? Extending a single HDMI source (e.g., laptop, media player) to a distant display/projector over CATx cable in conference rooms, classrooms, or small presentation systems.
- Does it support 4K video? Yes — full 4K/60 4:4:4 pass-through with HDR10 and HDCP 2.3 compliance for modern sources and displays.
- How far can signals be transmitted? Up to 70 m (230 ft) on shielded CATx cable when paired with a compatible Extron HDBaseT receiver.
- Is audio de-embedding supported? Yes — embedded HDMI audio can be extracted and routed separately if needed.
- How is it controlled? Front-panel buttons for basic operation, plus RS-232, Ethernet (IP control), or IR remote for integration with AV control systems.
- Is it rack-mountable? Yes — compact enclosure with optional rack ears for mounting in standard 19-inch racks (half-rack width).
