Extron DXP 44 HD 4K PLUS 4x4 4K/60 HDMI with 2 Audio Outputs

Product Description

The Extron DXP 44 HD 4K PLUS is a 4x4 HDMI matrix switcher that routes computer and video signals at resolutions up to 4K/60 with 4:4:4 chroma sampling. It independently routes any of four HDMI sources to any of four HDMI displays, making it a compact fit for conference rooms, divisible meeting spaces, briefing rooms, lecture halls, and control rooms that distribute multiple 4K sources to multiple displays. Supporting HDMI 2.0 with data rates up to 18 Gbps, the switcher passes HDR, Deep Color up to 12-bit, 3D, HD lossless audio formats, and CEC, and is HDCP 2.3 compliant for protected content.

This 4x4 4K/60 HDMI matrix switcher includes two audio output groups with built-in de-embedders that extract HDMI audio to discrete S/PDIF and analog stereo outputs, removing the need for external HDMI audio extraction boxes when integrating a local sound system. Automatic input cable equalization and output reclocking preserve signal integrity, equalizing 4K/60 signals to 35 feet (10.7 meters) with Extron HDMI Pro cables. The switcher installs in a 1U, full-rack-width metal enclosure and is operated over RS-232, Ethernet, or the front panel.

For larger I/O sizes in the same series, compare the Extron DXP 84 HD 4K PLUS (8x4) and the Extron DXP 88 HD 4K PLUS (8x8), or browse the full Extron collection at Creation Networks.

Key Features

• 4x4 HDMI matrix routing — Routes any of four HDMI sources to any of four HDMI outputs independently for flexible source-to-display distribution.
• 4K/60 at 4:4:4 support — Handles computer and video resolutions up to 4096x2160 at 60 Hz with full 4:4:4 chroma sampling.
• HDMI 2.0 with 18 Gbps data rate — Supports HDR, Deep Color up to 12-bit, 3D, HD lossless audio formats, and CEC control.
• HDCP 2.3 compliant — Ensures display of content-protected media and interoperability with other HDCP-compliant devices.
• Audio de-embedding — Extracts embedded HDMI audio to two S/PDIF and two analog stereo output groups, eliminating external audio extraction hardware.
• SpeedSwitch Technology — Delivers fast, reliable switching of HDCP-encrypted content.
• EDID Minder and Key Minder — Automatically manages EDID communication and maintains HDCP authentication for quick, reliable switching.
• Automatic cable equalization and reclocking — Conditions incoming HDMI signals and restores output timing, equalizing 4K/60 to 35 ft (10.7 m) with Extron HDMI Pro cables.
• RS-232 and Ethernet control — Integrates into control systems via SIS commands and supports monitoring and control over a LAN, WAN, or the Internet.
• Global presets and rooming — Stores frequently used I/O configurations and groups outputs into rooms for streamlined operation.
• 1U rack-mount metal enclosure — Full-rack-width chassis with included mounting brackets for standard equipment racks.
• Extron Everlast power supply — Internal universal 100-240 VAC supply covered by a 7-year parts and labor warranty.

Technical Specifications

Frequently Asked Questions

Does the DXP 44 HD 4K PLUS support full 4K/60 4:4:4?
Yes. It supports computer and video resolutions up to 4096x2160 at 60 Hz with 4:4:4 chroma sampling at the full 18 Gbps HDMI 2.0 data rate.

How many sources and displays does it handle?
It is a 4x4 matrix switcher, routing any of four HDMI sources to any of four HDMI outputs independently.

Can it extract audio from an HDMI source?
Yes. Built-in de-embedders extract embedded HDMI audio to two S/PDIF outputs and two analog stereo outputs for connection to a local audio system without external extractors.

How is the unit installed and controlled?
It mounts in a 1U, full-rack-width enclosure using the included brackets and is controlled by the front panel, RS-232 (SIS commands), or Ethernet for LAN/WAN monitoring and control.

What warranty is included?
The DXP 44 HD 4K PLUS carries a 3-year parts and labor warranty, and the Extron Everlast power supply is covered for 7 years parts and labor.
