Extron DTP3 T 322 D – Two Input 4K/60 DTP3 Wallplate Transmitter, Black

Product Overview

DTP3 T 322 D (Black), part number 60-2066-52. The Extron DTP3 T 322 D is a two-input DTP3 wallplate transmitter that sends USB-C video, HDMI, USB data, embedded audio, and control up to 330 feet (100 meters) over a single shielded CAT 6A cable. It combines a USB-C input and an HDMI input in a single-gang decorator-style plate, which covers both the modern laptop and the legacy or guest device without a second connection point. Video resolutions up to 4K/60 are supported at data rates to 18 Gbps. When paired with the Extron UPI 100 power inserter, the plate also delivers up to 100 watts of USB-C charging to the connected source.

Product Description

Most rooms need two input paths at the wall or lectern: USB-C for the standard corporate laptop and HDMI for everything else that walks in. Specifying two separate transmitters doubles the plate count, the cable pulls, and the rack-side receivers. The DTP3 T 322 D puts both inputs behind one single-gang decorator-style plate and one shielded CAT 6A run.

Signal handling covers HDMI 2.0b and DisplayPort 1.2 Alt Mode with HDCP 2.3, at a maximum data rate of 18 Gbps and a 600 MHz pixel clock. Resolution range runs from 640x480 to 4096x2160, including 4K/60 at 4:4:4 and ultra-wide formats such as 3440x1440, 3840x1440, and 3840x1600. The 5120x1440 ultra-wide format is supported at 60 Hz with 4:4:4 and 8-bit color.

The decorator-style form factor is the practical reason this product gets specified. It drops into standard millwork cutouts, matches the electrical devices already in the wall or table, and does not require a custom faceplate. Black and white versions are available so the plate disappears into the finish rather than announcing itself.

For rooms where the USB-C connection also has to charge the laptop, add the Extron UPI 100 power inserter, which supplies 100 watts and installs up to 330 feet from the transmitter. Rack-side, pair the transmitter with a DTP3 receiver or DTP3-equipped switching. If the connection point is a table position rather than a wall, the Extron DTP3 T 321 covers the same signal path with a local HDMI output and USB device ports.

Related products at Creation Networks: Extron DTP3 R 331 receiver.

Key Features

• Two inputs, one plate — A USB-C input and an HDMI input share a single-gang decorator-style plate, covering both modern and legacy sources.
• 330 foot extension — Sends video, audio, USB data, and control up to 330 feet (100 m) over one shielded CAT 6A cable.
• 4K/60 support — Handles resolutions up to 4096x2160 at 60 Hz with 4:4:4 chroma, at data rates to 18 Gbps.
• Ultra-wide format support — Supports 2560x1080, 3440x1440, 3840x1080, 3840x1440, 3840x1600, and 5120x1440 at 60 Hz.
• 100 watt USB-C charging — Delivers up to 100 watts to the connected source when deployed with the Extron UPI 100 power inserter.
• Decorator-style mounting — Fits standard decorator openings in walls, lecterns, and conference table millwork.
• Black and white finishes — Two color options so the plate matches surrounding devices and finishes.
• HDCP 2.3 compliant — Maintains protected content paths for corporate laptops and media sources.

Typical Applications

• Conference room
• Boardroom
• Huddle room
• Training room
• Commercial meeting space
• Multi-purpose room
• All-hands room
• Auditorium

Technical Specifications

Specifications sourced from Extron product documentation.

Frequently Asked Questions

Can both inputs be active at once?

The transmitter sends one signal down the twisted pair path at a time. It provides two physical input options at the plate so either source type can be connected; switching behavior between them follows the transmitter's configured input selection.

What cable is required?

Shielded CAT 6A, terminated to the shielded standard end to end, to reach the full 330 feet (100 meters). Unshielded cable will reduce achievable distance and can cause errors at 4K data rates.

Does the plate charge a connected laptop?

Only when paired with the Extron UPI 100 power inserter, which supplies 100 watts of USB Power Delivery and installs up to 330 feet from the transmitter. Order the UPI 100 separately if charging is required.

What is the difference between the black and white versions?

Finish only. Part number 60-2066-52 is black and 60-2066-53 is white; both are functionally identical. Choose to match the surrounding wall plates or millwork.

Will it fit a standard decorator opening?

Yes. It is a single-gang decorator-style device sized for standard openings, which simplifies coordination with the electrical contractor and the furniture vendor.

What receiver should be specified?

Any Extron DTP3 receiver or DTP3-equipped switcher or matrix. Match the receiver to the display-side output requirement and confirm both ends support the resolution and data rate your design calls for.
