Extron DTP3 T 212 D – Two Input 4K/60 DTP3 Decorator Wallplate Transmitter, Black

Product Overview

DTP3 T 212 D (Black), part number 60-1714-52. The Extron DTP3 T 212 D is a two-input decorator-style transmitter for sending USB-C video, HDMI, audio, power, and control up to 330 feet (100 meters) over a shielded CAT 6A cable. It supports video resolutions up to 4K/60 at 4:4:4 and complies with HDCP 2.3.

Product Description

Two inputs at the wall is the practical minimum for a room that hosts both staff and guests: USB-C for the standard corporate laptop, HDMI for everything else that walks through the door. Specifying two single-input transmitters doubles the plate count and the cable pulls for no benefit.

The DTP3 T 212 D puts both on one decorator-style plate and one shielded CAT 6A run. Auto-switching means the presenter connects a cable and the transmitter selects that input without a control command, which removes the most common source of confusion at the table.

Video support reaches 4K/60 with full 4:4:4 chroma sampling, including 5K and ultra-wide formats such as 5120x1440 at 60 Hz. Signal handling is HDMI 2.0b with HDCP 2.3 at up to 18 Gbps, covering HDR, Deep Color to 12-bit, 3D, and HD lossless audio.

The analog stereo audio input is the feature that distinguishes this model. It embeds a separate analog source into the digital stream, which is useful where a program audio feed, an assistive listening output, or a local microphone needs to reach the rack on the same cable as the video. Black and white finishes are available. Where the room needs 100 watt USB-C laptop charging instead, specify the DTP3 T 322 D with a UPI 100 power inserter.

This listing is the DTP3 T 212 D configuration, part number 60-1714-52: Black. Every part number in the DTP3 T 212 D family shares the same signal architecture and enclosure; the configuration determines which processing, control, and collaboration features ship in the unit.

Creation Networks supplies the full DTP3 T 212 D range, so a design can be quoted across configurations before the specification is locked. Contact us for project pricing and current lead time.

Key Features

• Two inputs, one plate — A USB-C input and an HDMI input share a single decorator-style plate, covering both modern and legacy sources.
• 4K/60 at 4:4:4 — Supports video resolutions up to 4K/60 with full 4:4:4 chroma sampling, including 5K.
• 330 foot extension — Sends video, audio, power, and control up to 330 feet (100 m) over shielded CAT 6A.
• Auto-switching — Switches automatically between the two inputs, so a presenter simply plugs in.
• Analog stereo audio embedding — Embeds a separate analog stereo source into the digital stream for program audio or a local mic feed.
• Ultra-wide aspect ratios — Handles 21:9 and 5K formats used in extended desktop and Teams room layouts.
• Full HDMI 2.0b feature set — Data rates up to 18 Gbps, HDR, Deep Color up to 12-bit, 3D, and HD lossless audio formats.
• Black and white finishes — Two colors so the plate matches surrounding devices and finishes.

Typical Applications

• Conference room
• Boardroom
• Huddle room
• Training room
• Commercial meeting space
• Multi-purpose room
• All-hands room

Technical Specifications

Specifications sourced from Extron product documentation.

Frequently Asked Questions

How does it differ from the DTP3 T 322 D?

Both are two-input decorator-style DTP3 transmitters. The T 212 D adds analog stereo audio embedding and is the lower-cost option; the T 322 D supports up to 100 watt USB-C charging when paired with the UPI 100 power inserter. Choose on whether the room needs laptop charging or a separate analog audio input.

Does it switch inputs automatically?

Yes. Auto-switching between the USB-C and HDMI inputs means the presenter connects a cable and the transmitter selects that source without a control command.

What is analog audio embedding for?

It lets a separate analog stereo source, such as a program audio feed or a local microphone output, be embedded into the digital stream and carried to the rack on the same cable.

What cable does it need?

Shielded CAT 6A terminated to the shielded standard end to end for the full 330 feet (100 meters).

Which sources work on the USB-C input?

Any USB-C source that supports DisplayPort Alt Mode. Laptops exposing USB-C data only, without Alt Mode video, will not pass an image.

What is the difference between the two part numbers?

Finish only. 60-1714-52 is black and 60-1714-53 is white; they are functionally identical.

What receiver should be specified?

Any Extron DTP3 receiver or DTP3-equipped switcher or matrix. Match the receiver to the display-side requirement and confirm both ends support your resolution.
