Product Overview
The Extron DTP2 CrossPoint 82 IPCP Q SA is an 8x2 4K/60 presentation matrix switcher with integrated DTP2 signal extension, Vector 4K scaling, ProDSP with AEC, a 2x50W stereo Class D amplifier, and the IPCP Pro 355MQ xi quad-core control processor — in a compact 2U rack-mount enclosure. Eight inputs (4 HDMI, 2 DisplayPort, 2 DTP2) route to one non-scaled HDMI output and one scaled DTP2 output with extension to 330 feet over shielded CAT 6A. Available at Creation Networks.
Product Description
The DTP2 CrossPoint 82 IPCP Q SA consolidates 8x2 4K/60 matrix switching, DTP2 signal extension, ProDSP conferencing audio, stereo amplification, and complete AV system control into a single compact 2U rack unit. The 8x2 matrix routes four HDMI, two DisplayPort, and two DTP2 inputs to one non-scaled HDMI output and one Vector 4K-scaled DTP2 output at 4K/60 with 4:4:4 chroma sampling. ProDSP delivers 32/64-bit floating point DSP with four-channel AEC, eight-group automixer, and four mic/line inputs with 48V phantom power. The integrated 2x50W stereo Class D SA amplifier drives direct-connect low-impedance speaker loads. The IPCP Pro 355MQ xi quad-core control processor provides 2 GB RAM, 8 GB Flash, a three-port isolated AV LAN switch, three serial ports, four digital I/O, and four relays. Available at Creation Networks.
Key Features
- 8x2 4K/60 Matrix Switcher — Routes four HDMI, two DisplayPort, and two DTP2 inputs to one non-scaled HDMI and one scaled DTP2 output at 4K/60 with 4:4:4 chroma sampling in a 2U rack unit.
- DisplayPort 1.2 and HDMI 2.0 Inputs — Accepts 4K/60 signals from DisplayPort-equipped computers and HDMI 2.0 sources natively.
- DTP2 Signal Extension to 330 Feet over CAT 6A — Extends 4K/60 video, audio, and RS-232 up to 330 feet over shielded CAT 6A to DTP2 endpoints and HDBaseT displays.
- Vector 4K Scaling on DTP2 Output — 30-bit precision scaling at 4:4:4 chroma sampling; 640x480 through 4K/60.
- Integrated 2x50W Stereo Class D Amplifier — 50W rms per channel at 4 ohms or 25W rms per channel at 8 ohms with Extron CDRS ripple suppression.
- IPCP Pro 355MQ xi Quad-Core Control Processor — 2 GB RAM, 8 GB Flash, three-port isolated AV LAN switch, three serial ports, four digital I/O, four relays.
- ProDSP 32/64-Bit Floating Point Audio — Four-channel AEC, eight-group automixer, 24-bit/48 kHz conversion, EQ, delay, and feedback suppression.
- EDID Minder, Key Minder, SpeedSwitch — Reliable HDCP handling and fast switching for protected content.
- Compact 2U Enclosure — Replaces matrix switcher, DSP, stereo amplifier, and control processor in 2U of rack space.
- Extron Everlast Internal Power Supply — Universal power; 7-year warranty.
Technical Specifications
| DTP2 CrossPoint 82 IPCP Q SA — Technical Specifications (SKU 60-1812-92) | |
|---|---|
| Video | |
| Routing | 8 x 2 matrix |
| Resolution | 4K/60 at 4:4:4 chroma sampling |
| Standards | HDMI 2.0, DisplayPort 1.2, HDCP 2.2, CEA-861 |
| Video Inputs | |
| Number/type | 4 HDMI; 2 DisplayPort; 2 DTP2 (DTP2 or XTP configurable) |
| Video Outputs | |
| HDMI output | 1 HDMI (non-scaled pass-through) |
| DTP2 scaled output | 1 DTP2 or HDBaseT (configurable) with mirrored HDMI |
| Scaled resolutions | 640x480 through 4K/60 at 4:4:4 |
| DTP2 Extension | |
| Distance | Up to 330 ft (100 m) over shielded CAT 6A |
| Audio | |
| Routing | 8 x 2 stereo switching matrix; 4 x 4 mic mixing matrix |
| DSP | ProDSP 32/64-bit floating point; 4-channel AEC; 8-group automixer |
| Digital conversion | 24-bit, 48 kHz |
| Mic/line inputs | 4 mono balanced/unbalanced with 48V phantom power |
| Control Processor | |
| Processor | IPCP Pro 355MQ xi quad-core; 2 GB RAM, 8 GB Flash |
| AV LAN switch | 3-port isolated; 10/100/1000Base-T |
| Serial ports | 1x RS-232/422/485; 2x RS-232 |
| Digital I/O / Relays | 4 digital I/O; 4 relays (24 VDC 1A) |
| Amplifier | |
| Type | Class D stereo with CDRS |
| Output power | 50W rms/ch @ 4 ohms; 25W rms/ch @ 8 ohms; 1 kHz, 0.1% THD |
| Min load | 4 ohms |
| General | |
| Power supply | Internal Extron Everlast; 100–240 VAC, 50–60 Hz |
| Enclosure | 2U, full rack; 3.5" H x 17.5" W x 10.5" D; 8.0 lbs (3.6 kg) |
| Regulatory | CE, FCC Class A, c-UL, UL, KC; RoHS/WEEE compliant |
| Product warranty | 3 years parts and labor; Everlast PSU 7 years |
Typical Application
The DTP2 CrossPoint 82 IPCP Q SA is deployed in compact conference rooms and training spaces where 4K/60 matrix switching, DTP2 signal extension, DSP with AEC, stereo speaker amplification, and programmable AV control are required in a 2U rack unit.
