Extron DP Pro DisplayPort 8K Optical Cables 150' (45.7 m) Plenum
The Extron DP Pro Plenum Series features active, hybrid optical-copper cables engineered for ultra high-speed transmission of DisplayPort 1.4 signals over extended distances. These plenum-rated cables support demanding video resolutions up to 8K/30 @ 4:4:4, along with HDR, 32 channels of audio, EDID, HDCP, and CEC, delivering uncompressed, high-fidelity performance in professional AV installations. Their ultra-thin 0.18" (4.7 mm) diameter and narrow bend radius enable easy routing through tight conduits, ceilings, and plenum air spaces while maintaining signal integrity without compromise, making them ideal for large-scale digital signage, control rooms, auditoriums, corporate boardrooms, and broadcast environments requiring long-run, high-resolution DisplayPort connectivity.
As unidirectional active cables, they draw ultra-low power directly from connected DisplayPort source devices, eliminating the need for external power supplies and simplifying deployment. The NEC CMP plenum rating ensures compliance for in-air-handling spaces, and the robust hybrid construction combines optical fiber for long-distance transmission with copper for reliable connector interfaces. Available in lengths from 25 feet (7.6 m) to 150 feet (45.7 m), these cables provide integrators with flexible, future-proof solutions for 8K-capable systems and high-bandwidth applications.
Features Chart
| Feature | Benefit |
|---|---|
| DisplayPort 1.4 Compliance | Enables support for advanced high-bandwidth features and resolutions |
| Up to 8K/30 @ 4:4:4 Resolution | Delivers ultra-high-definition video with full chroma subsampling |
| Active Hybrid Optical-Copper Design | Achieves long-distance transmission while supporting plenum rating |
| Plenum, NEC CMP-Rated Jacket | Safe for installation in air-handling spaces per building codes |
| Ultra-Thin 0.18" (4.7 mm) Diameter | Facilitates routing in confined conduits and tight installation spaces |
| Narrow Bend Radius | Allows flexible installation without signal degradation |
| Supports HDR, EDID, HDCP, CEC | Maintains full compatibility and control features in AV systems |
| Ultra-Low Power Draw | Powered by source device, no external supply needed |
Specifications Table
| Specification | Details |
|---|---|
| Connector Type | DisplayPort Male (typically gold-plated or high-quality) on both ends |
| Cable Standard | DisplayPort 1.4 compliant |
| Available Lengths | 25' (7.6 m) to 150' (45.7 m) |
| Maximum Resolution | 8K (7680x4320) @ 30 Hz @ 4:4:4; also supports 4K/60, 5K/60 |
| Data Rate | Up to 32.4 Gbps |
| Cable Diameter | 0.18" (4.7 mm) |
| Construction | Active hybrid optical-copper; plenum-rated (NEC CMP) |
| Power Consumption | Ultra-low, drawn from source device |
| Additional Support | HDR, 32-channel audio, EDID, HDCP, CEC |
| Applications | Long-run DisplayPort signal extension in plenum spaces |
Compare Chart
| Aspect | Extron DP Pro Plenum Series | Kramer Long-Range DP Cables | Crestron DisplayPort Plenum |
|---|---|---|---|
| Standard Compliance | DisplayPort 1.4 | DisplayPort 1.4 variants | DisplayPort 1.4 |
| Max Resolution | 8K/30 @ 4:4:4 | Up to 8K/30 or 4K/60 typical | Up to 4K/60 or higher |
| Plenum Rating | Yes (NEC CMP) | Some models plenum | Plenum-rated options |
| Cable Diameter | Ultra-thin 0.18" (4.7 mm) | Typically thicker | Standard plenum thickness |
| Length Range | 25' to 150' | Up to 100'+ in some series | Up to 100-200' variants |
| Active/Hybrid Design | Yes (optical-copper) | Often active copper/optical | Active optical |
| Power Requirement | Ultra-low from source | May require external power | Low or source-powered |
| Bend Radius/Installation | Narrow, flexible for tight spaces | Standard flexibility | Good but less ultra-thin |
FAQ
- What is the maximum resolution supported by the DP Pro Plenum Series? These cables support up to 8K/30 Hz @ 4:4:4, as well as lower resolutions like 4K/60 Hz and 5K/60 Hz, depending on length and source/display capabilities.
- Are these cables suitable for plenum spaces? Yes, they feature an NEC CMP-rated plenum jacket, making them compliant for installation in air-handling plenums and return air spaces.
- What lengths are available? Cables are offered from 25 feet (7.6 m) to 150 feet (45.7 m) to accommodate a wide range of long-distance AV installation needs.
- Do these cables require external power? No, they are active but draw ultra-low power directly from the connected DisplayPort source device.
- What additional signals do these cables carry besides video? They support HDR video, 32 channels of audio, EDID management, HDCP content protection, and CEC control functions.
- How does the ultra-thin design benefit installation? The 0.18" (4.7 mm) diameter and narrow bend radius allow easy pulling through conduits, tight ceilings, and confined spaces without performance loss.
