Extron Cable Pass-Through 2 MAAP Module Half-size Flex55 Module; White
The Extron Cable Pass-Through 2 MAAP Module is a single-space Architectural Adapter Plate designed for organized cable routing in professional AV installations. It features two grommeted pass-through openings that allow smooth insertion and removal of AV, data, power, or control cables while protecting them from abrasion at the edges. This module is ideal for conference tables, lecterns, podiums, wall boxes, and other furniture-mounted or rack applications where multiple cables need discreet, pull-through access without fixed connectors.
Constructed as a mountable metal plate with black finish, the Cable Pass-Through 2 MAAP fits seamlessly into any AAP-compatible Extron mounting frame or enclosure, such as Cable Cubby series, AVEdge, TMK table mounts, SMB surface mounts, EWB wall boxes, and rack/wall interfaces. It supports clean cable management, reduces wear on cables, and maintains a professional appearance in architectural AV environments.
Features Chart
| Feature | Benefit |
|---|---|
| Single-space AAP design | Fits compactly in standard AAP positions for efficient use of space |
| Two grommeted pass-through openings | Enables smooth routing and protection for two cables |
| Grommets reduce cable abrasion | Protects cable jackets during frequent insertion and removal |
| Pull-through cable connections | Allows easy cable changes without disconnection issues |
| Mountable metal plate construction | Provides durability and secure integration in AV frames |
| Compatible with AAP systems | Installs in Cable Cubby, AVEdge, TMK, SMB, EWB, rack/wall mounts |
| Black finish | Matches standard Extron AAP hardware for uniform aesthetics |
| Dust minimization | Grommets help limit debris entry around cable openings |
Specifications Table
| Specification | Details |
|---|---|
| Module Size | Single Space |
| Module Type | Cable pass-through AAP plate |
| Openings | Two grommeted pass-through holes |
| Grommet Inner Diameter | Approximately 0.39" (9.9 mm) per opening |
| Compatibility | Select Extron interfaces, AAP AV connectivity mounting frames, Cable Cubby series, AVEdge, TMK, SMB, EWB, rack/wall mounts |
| Mounting | Insertion into single-space AAP positions |
| Materials | Metal construction with plastic grommets |
| Finish | Black (standard) |
| Applications | Cable routing in architectural AV furniture and wall setups |
Compare Chart
| Aspect | Extron Cable Pass-Through 2 MAAP | Extron Cable Organizer AAP Kit (Quad) | Extron Hole Plug and Grommet Kit |
|---|---|---|---|
| Size/Coverage | Single Space | Quad Space | N/A (accessory kit) |
| Cable Capacity | 2 cables | Up to 12 cables | Varies (size-specific grommets) |
| Grommets Included | Yes (fixed in openings) | Yes (12 grommets) | Yes (3 sizes, loose) |
| Installation | Modular AAP insertion | Modular AAP assembly | Snap-in to holes |
| Material | Metal plate + grommets | Metal plates + grommets | Plastic grommets/plugs |
| Primary Use | Basic dual cable pass-through | High-capacity structured organization | Individual hole protection |
| Customization | Low (fixed 2 openings) | High for multi-cable setups | Basic size matching |
| System Focus | AAP single-space | AAP quad-space | Cable Cubby pass-through holes |
FAQ
- What is the Cable Pass-Through 2 MAAP used for? It provides two protected grommeted openings for routing AV, data, power, or control cables through AAP-compatible enclosures.
- Which products does it fit? It installs in single-space AAP positions within Cable Cubby series, AVEdge, TMK table mounts, SMB, EWB wall boxes, and other AAP-accepting frames.
- How do the grommets help? They allow smooth cable movement while preventing edge abrasion and damage during frequent use.
- Can cables be easily changed? Yes, the pass-through design supports pull-through connections for quick insertion, removal, or swapping.
- What material and finish are used? It features a durable metal plate with plastic grommets and a standard black finish to match Extron AAP hardware.
- Is it suitable for multiple cable types? Yes, the two openings accommodate various cable diameters up to the grommet size for flexible AV connectivity.
