Extron AXI 016 Analog Stereo Audio Interface
The Extron AXI 016 is a compact analog stereo audio interface designed to convert unbalanced stereo audio from consumer sources to balanced stereo audio for professional AV systems. It accepts stereo audio on dual RCA connectors and outputs balanced stereo audio on captive screw terminals, providing clean signal conversion with excellent noise rejection and level matching. This interface is ideal for integrating devices with RCA outputs—such as media players, laptops, DVD/Blu-ray players, or consumer electronics—into balanced audio chains with amplifiers, DSPs, mixers, or matrix switchers in classrooms, conference rooms, boardrooms, training facilities, and control environments.
Featuring adjustable gain control (±12 dB) for precise level matching, high-quality transformers for galvanic isolation and ground lift to eliminate hum, and a rugged metal enclosure, the AXI 016 ensures reliable, low-noise performance in mixed consumer-professional AV setups. Its small form factor allows easy mounting under tables, in racks, or behind equipment, while captive screw terminals provide secure, vibration-resistant connections for permanent installations.
Features Chart
| Feature | Benefit |
|---|---|
| Unbalanced RCA to Balanced Captive Screw | Converts consumer RCA stereo to professional balanced audio |
| Adjustable Gain Control (±12 dB) | Allows precise level matching between source and destination |
| Transformer Isolation | Provides galvanic isolation and ground lift to eliminate hum/noise |
| High-Quality Stereo Audio Conversion | Maintains signal integrity with low distortion and wide frequency response |
| Captive Screw Output Terminals | Secure, tool-free termination for reliable balanced connections |
| Compact Metal Enclosure | Durable and space-efficient for rack, under-table, or surface mounting |
| Plug-and-Play Operation | No external power required (passive design) |
| Professional AV Compatibility | Bridges consumer sources to pro audio chains in presentation systems |
Specifications Table
| Specification | Details |
|---|---|
| Input Connectors | Two RCA female (unbalanced stereo) |
| Output Connectors | 3.5 mm captive screw (balanced stereo) |
| Gain Adjustment | ±12 dB (via rear-panel trim pot) |
| Frequency Response | 20 Hz to 20 kHz, ±0.5 dB |
| THD + Noise | <0.01% @ 1 kHz, nominal level |
| Crosstalk | <-80 dB @ 1 kHz |
| Power Requirement | None (passive) |
| Mounting | Compact enclosure with mounting options |
| Applications | Consumer-to-pro audio interfacing in AV systems |
| Compatibility | Unbalanced RCA sources; balanced audio destinations |
Compare Chart
| Aspect | Extron AXI 016 | Extron AXI 44 | Kramer 900xl Audio Interface |
|---|---|---|---|
| Conversion Type | Unbalanced RCA to balanced | 4-channel unbalanced to balanced | Unbalanced to balanced |
| Gain Adjustment | ±12 dB | ±12 dB per channel | Fixed or adjustable |
| Isolation | Transformer-based | Transformer-based | Transformer or active |
| Inputs/Outputs | 2 RCA in / 1 balanced out | 4 RCA in / 4 balanced out | Varies (typically 1 or 2 ch) |
| Power | Passive | Passive | Passive or active |
| Primary Use | Simple stereo consumer-to-pro | Multi-channel interfacing | General audio conversion |
| Form Factor | Compact | Compact | Compact |
| Extron Optimization | Yes | Yes | No |
FAQ
- What is the main purpose of the AXI 016? It converts unbalanced stereo audio from RCA sources to balanced stereo audio for professional AV systems.
- Does it require power? No, the AXI 016 is fully passive and requires no external power supply.
- How is gain adjusted? A rear-panel trim pot provides ±12 dB gain adjustment to match input and output levels precisely.
- What type of isolation does it use? Transformer isolation provides galvanic isolation and ground lift to eliminate hum and ground loop noise.
- What connectors are used? Inputs are dual RCA female (unbalanced), and output is a 3.5 mm captive screw terminal (balanced).
- Can it be used in rack installations? Yes, its compact size and mounting options make it suitable for rack, under-table, or surface mounting in AV systems.
