Extron ATB 100 Analog Stereo Audio Breakout Adapter
The Extron ATB 100 is a compact breakout adapter that converts a single 3.5 mm stereo mini jack to two color-coded RCA connectors (red/right, white/left) for analog audio signals. This passive adapter enables easy interconnection between devices with 3.5 mm stereo outputs—such as laptops, media players, tablets, or portable sources—and equipment featuring RCA stereo audio inputs, including mixers, amplifiers, AV switchers, or presentation systems. It is well-suited for professional AV installations in classrooms, conference rooms, boardrooms, training facilities, and control environments requiring simple, reliable unbalanced line-level stereo audio bridging without additional converters or power.
The adapter features a 3.5 mm stereo male plug on one end and two molded, color-coded female RCA connectors on the other, ensuring quick channel identification and secure connections. Its short length minimizes excess cable in rack, desktop, or under-table setups while providing dependable signal transmission in mixed-format AV systems.
Features Chart
| Feature | Benefit |
|---|---|
| 3.5 mm Stereo Male to Dual RCA Female | Converts common 3.5 mm stereo output to standard RCA inputs |
| Color-Coded RCA Connectors (Red/White) | Simplifies left/right channel identification and reduces wiring errors |
| Compact Short Length | Reduces clutter in tight rack or desktop AV installations |
| High-Quality Analog Audio Adapter | Ensures reliable line-level stereo audio transmission |
| Molded Connectors | Provides strain relief and durable, secure connections |
| Unbalanced Stereo Audio Support | Compatible with consumer and pro presentation audio equipment |
| Plug-and-Play Design | No configuration or power supply needed for quick setup |
| Professional AV Compatibility | Bridges portable sources to AV systems with RCA audio inputs |
Specifications Table
| Specification | Details |
|---|---|
| Connector A | 3.5 mm stereo mini male plug |
| Connector B | Two RCA female connectors (color-coded red/white) |
| Cable Length | Short adapter (typically 6-12 inches) |
| Cable Type | Stereo audio adapter (unbalanced) |
| Signal Type | Line-level stereo audio |
| Applications | Audio interconnection from 3.5 mm sources to RCA inputs |
| Compatibility | Devices with 3.5 mm stereo output; RCA audio inputs |
| Power Requirement | None (passive) |
Compare Chart
| Aspect | Extron ATB 100 | Extron MSR 6 (RCA Female) | Kramer C-35/2RCA Cable |
|---|---|---|---|
| Connector Configuration | 3.5 mm Male to (2) RCA Female | 3.5 mm Male to (2) RCA Female | 3.5 mm Male to (2) RCA Male |
| Length | Short adapter | 6" (15 cm) | Varies, often 6-12" |
| Signal Direction | 3.5 mm source to RCA input | 3.5 mm source to RCA input | 3.5 mm source to RCA input |
| Color-Coded Connectors | Yes (red/white RCA) | Yes (red/white RCA) | Often red/white |
| Build Quality | High-quality Extron | High-quality Extron | Professional |
| Primary Use | Compact audio adaptation | Short desktop/rack use | General consumer/pro bridging |
| Installation Ease | Plug-and-play | Plug-and-play | Plug-and-play |
FAQ
- What is the main purpose of the ATB 100 adapter? It adapts a 3.5 mm stereo male output to dual RCA female inputs for connecting stereo audio sources to RCA-equipped devices.
- Are the RCA connectors color-coded? Yes, they are color-coded red (right channel) and white (left channel) for easy and error-free wiring.
- Does this adapter support balanced audio? No, it is designed for unbalanced line-level stereo audio signals common in consumer and presentation equipment.
- Is external power required? No, it is a passive adapter with no power needs.
- What equipment is typically compatible? It works with any device featuring a 3.5 mm stereo output (like laptops or media players) and RCA audio inputs (like amplifiers or switchers).
- How long is the adapter cable? It is a short adapter (typically 6-12 inches), ideal for compact, clean connections in tight AV setups.
