Extron ASA 204 Four-Input Analog Stereo Audio Input
Extron ASA 204 Four-Input Analog Stereo Audio Input is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or just need expert advise? Give us a call at 1-888-230-3661 or LiveChat below. Purchasing 1 or 100, there may be greater savings beyond the advertised price.
Looking for a specific Extron product or custom AV solution? Our certified experts can source any Extron device to meet your project requirements. Please contact Creation Networks for a personalized quote or to learn more about our certified Extron design, programming, installation and maintenance services for conference rooms, auditoriums, training centers, and hybrid collaboration spaces. Creation Networks offers direct technical support during the initial Extron implementation and future support of Extron products as needed.
Extron ASA 204 Four-Input Analog Stereo Audio Input
The Extron ASA 204 is a compact, four-input, one-output analog stereo audio switcher designed for reliable source selection of balanced or unbalanced line-level stereo audio signals in professional AV systems. It accepts four stereo audio sources on captive screw connectors and provides clean, low-noise switching with excellent signal integrity to a single output destination such as an amplifier, DSP, recorder, or presentation system. The switcher is ideal for applications requiring multi-source audio routing in classrooms, conference rooms, boardrooms, training facilities, control systems, or small-scale mixing setups where four stereo audio sources need to be selectively routed without complex processing.
Featuring a rugged metal enclosure, front-panel push-button switching with LED indicators for active input selection, and RS-232 serial control for integration with AV controllers or automation systems, the ASA 204 delivers dependable performance with minimal setup. Its small form factor allows easy mounting under tables, in racks, or behind equipment, while the captive screw terminals ensure secure, vibration-resistant connections in permanent installations.
Features Chart
| Feature | Benefit |
|---|---|
| Four-Input, One-Output Stereo Audio Switching | Select among four line-level stereo sources with seamless routing |
| Captive Screw Audio Connectors | Secure, tool-free termination for reliable balanced/unbalanced connections |
| Front-Panel Push-Button Control | Manual selection with LED indicators for visual confirmation |
| RS-232 Serial Control | Enables integration with AV controllers, touchpanels, or automation |
| Low-Noise, High-Integrity Signal Path | Maintains audio quality with minimal distortion or crosstalk |
| Compact Metal Enclosure | Durable and space-efficient for rack, under-table, or surface mounting |
| Balanced/Unbalanced Compatibility | Supports a wide range of professional and consumer audio sources |
| Plug-and-Play Operation | No configuration or external power adapter required |
Specifications Table
| Specification | Details |
|---|---|
| Audio Inputs | 4 stereo (balanced/unbalanced) on 3.5 mm captive screw |
| Audio Output | 1 stereo (balanced/unbalanced) on 3.5 mm captive screw |
| Control Interfaces | Front-panel push buttons, RS-232 (bidirectional) |
| Gain | Unity (0 dB) |
| Frequency Response | 20 Hz to 20 kHz, ±0.05 dB |
| THD + Noise | <0.01% @ 1 kHz, nominal level |
| Crosstalk | <-80 dB @ 1 kHz |
| Power Requirement | External 12 VDC power supply (included) |
| Mounting | Compact enclosure with mounting options |
| Applications | Stereo audio source selection in AV presentation systems |
| Compatibility | Line-level stereo audio sources and destinations |
Compare Chart
| Aspect | Extron ASA 204 | Extron ASA 131 | Kramer VS-44A Switcher |
|---|---|---|---|
| Inputs/Outputs | 4 stereo in / 1 stereo out | 3 stereo in / 1 stereo out | 4 stereo in / 1 stereo out |
| Control | Manual push buttons + RS-232 | Manual push buttons + RS-232 | RS-232/IR |
| Audio Type | Balanced/unbalanced | Balanced/unbalanced | Balanced/unbalanced |
| Form Factor | Compact | Compact | Compact |
| Primary Use | Four-source audio selection | Three-source audio selection | Multi-source selection |
| Serial Control | Yes | Yes | Yes |
| Power | External 12 VDC | External 12 VDC | External power supply |
| Extron Optimization | Yes | Yes | No |
FAQ
- What is the main purpose of the ASA 204? It provides simple four-source selection for stereo audio signals in professional AV setups.
- Does it support balanced audio? Yes, the ASA 204 accepts and outputs balanced or unbalanced stereo line-level audio signals.
- How is the switcher controlled? It features front-panel push buttons with LED indicators for manual operation and RS-232 serial control for integration with AV controllers.
- What connectors are used? Stereo audio inputs and output are on 3.5 mm captive screw connectors for secure, reliable termination.
- Is external power required? Yes, it includes an external 12 VDC power supply for operation.
- Can it be used in rack installations? Yes, its compact size and mounting options make it suitable for rack, under-table, or surface mounting in AV systems.
