Extron AAP OHDMIF1F10P HDMI Optical Pass-Through Plate White
The Extron AAP OHDMIF1F10P is a single-space Architectural Adapter Plate featuring one HDMI female-to-female optical hybrid feed-through connector with integrated 10-pin captive screw terminal block. It supports direct pass-through of HDMI signals over optical fiber (for extended distances) or copper cable, with the captive screw terminals providing secure connections for power, control, or low-voltage signals. This plate is ideal for conference tables, lecterns, podiums, wall boxes, and furniture installations requiring long-distance HDMI routing combined with reliable terminal-based connectivity without external converters.
Constructed from durable metal with a black finish, the AAP OHDMIF1F10P mounts seamlessly into Extron AAP-compatible frames and enclosures such as Cable Cubby series, AVEdge, TMK table mounts, SMB surface mounts, EWB wall boxes, and rack/wall applications. It supports high-resolution video/audio transmission with clean cable management and a professional appearance in architectural AV environments.
Features Chart
| Feature | Benefit |
|---|---|
| Single-space AAP design | Fits compactly in standard AAP positions for efficient space use |
| HDMI female-to-female optical hybrid connector | Enables pass-through of HDMI signals over optical fiber or copper cable |
| Integrated 10-pin captive screw terminal block | Provides secure, vibration-resistant connections for power, control, or low-voltage signals |
| Optical hybrid capability | Supports extended HDMI transmission distances without signal degradation |
| Feed-through configuration | Allows plug-and-play HDMI routing without active processing |
| Captive screw termination | Ensures stable, reliable wired connections |
| Durable metal plate construction | Guarantees long-term reliability in high-traffic installations |
| Black finish | Matches standard Extron AAP hardware for uniform aesthetics |
Specifications Table
| Specification | Details |
|---|---|
| Module Size | Single Space |
| Module Type | HDMI optical hybrid F/F + 10-pin captive screw pass-through AAP plate |
| Connectors | 1 x HDMI female-to-female optical hybrid; 1 x 10-pin captive screw terminal block |
| HDMI Support | Up to 4K/60 4:2:0 (optical), 1080p/60 (copper), embedded audio |
| Terminal Block | 10-pin for power/control/low-voltage signals |
| Compatibility | Select Extron interfaces, AAP AV connectivity mounting frames, Cable Cubby series, AVEdge, TMK, SMB, EWB, rack/wall mounts |
| Mounting | Insertion into single-space AAP positions |
| Materials | Metal construction |
| Finish | Black (standard) |
| Applications | Long-distance HDMI + terminal pass-through in architectural AV setups |
Compare Chart
| Aspect | Extron AAP OHDMIF1F10P | Extron AAP 1 HD F + 1 MJCS | Extron MAAP 1 DF + 1 DF + 1 10 |
|---|---|---|---|
| Size/Coverage | Single Space | Single Space | Triple Space |
| Connectors | HDMI optical hybrid F/F + 10-pin captive screw | HDMI F/F + 3.5 mm captive screw | 2 DB-9 F/F + 10-pin captive screw |
| Signal Types | HDMI (optical/copper) + custom terminals | HDMI video/audio + analog audio | Serial RS-232/422/485 + terminals |
| Distance Support | Extended via optical fiber | Standard HDMI | Standard serial |
| Installation | Modular AAP insertion | Modular AAP insertion | Modular AAP insertion |
| Material | Metal | Metal | Metal |
| Finish Options | Black (standard) | Black (standard) | Black (standard) |
| Primary Use | Long-distance HDMI + terminal pass-through | HDMI + secure audio pass-through | Serial control + terminal pass-through |
FAQ
- What is the AAP OHDMIF1F10P used for? It provides HDMI pass-through (optical or copper) and a 10-pin captive screw block for custom signals in a single AAP space.
- Which Extron products is it compatible with? It fits single-space positions in AAP-compatible frames and enclosures, including Cable Cubby series, AVEdge, TMK table mounts, and wall/rack solutions.
- What advantage does the optical hybrid provide? It supports longer HDMI transmission distances using optical fiber while remaining backward-compatible with copper HDMI cables.
- How is installation performed? The metal plate inserts modularly into single-space AAP positions, typically without specialized tools.
- What material and finish are used? It features durable metal construction with a standard black finish to match Extron AAP hardware aesthetics.
- Can it be used for future modifications? Yes, the design allows easy removal and replacement with other AAP modules or configurations as AV connectivity needs evolve.
