Extron AAP 2CCSWLED2ST - Architectural Adapter Plate with Dual Cat6, Control, and LED Indicators
Extron AAP 2CCSWLED2ST - Architectural Adapter Plate with Dual Cat6, Control, and LED Indicators is backordered and will ship as soon as it is back in stock.
Shipping Availability*
Shipping Availability*
Free Ground Shipping on Most Orders Over $250.00
Looking for the best price or expert advice? Give us a call at 1-888-230-3661 or use the Live Chat below. Buying 1 or 100, you may qualify for greater savings beyond the advertised price.
Looking for a specific Extron product or custom AV solution? Our certified experts can source any Extron device to meet your project requirements. Please contact Creation Networks for a personalized quote or to learn more about our certified Extron design, programming, installation and maintenance services for conference rooms, auditoriums, training centers, and hybrid collaboration spaces. Creation Networks offers direct technical support during the initial Extron implementation and future support of Extron products as needed.
Extron AAP 2CCSWLED2ST - Architectural Adapter Plate with Dual Cat6...
The Extron AAP 2CCSWLED2ST is a customizable architectural adapter plate (AAP) designed for Extron AAP enclosures, wall boxes, table boxes, and furniture-mount solutions. It provides a professional, flush-mounted interface for AV connectivity, featuring dual RJ-45 Cat6 pass-through ports (for network or HDBaseT/DTP extension), dual contact closure switches (for control or trigger functions), and LED indicators for status feedback (e.g., power, signal, or custom).
Ideal for conference tables, lecterns, podiums, wall plates, or furniture installations in boardrooms, classrooms, lecture halls, huddle spaces, and corporate meeting rooms requiring clean, integrated network, control, and status connectivity with cable management and strain relief. The plate supports Extron's modular AAP system for easy field changes, labeling, and compatibility with Extron DTP or DTP3 extenders when used with appropriate receivers.
Features Chart
| Feature | Benefit |
|---|---|
| Dual RJ-45 Cat6 Pass-Through | Supports network, HDBaseT, or DTP signal extension |
| Dual Contact Closure Switches | Enables local control, triggering, or automation functions |
| LED Indicators | Visual feedback for power, signal presence, or custom status |
| Architectural Flush-Mount Design | Clean, professional appearance in tables, walls, or furniture |
| Modular AAP Compatibility | Fits standard Extron AAP enclosures and boxes for flexible installations |
| Cable Strain Relief | Secure connectors with built-in management to prevent pull-out damage |
| Labeling Area | Space for custom port labels for user-friendly operation |
| Durable Construction | High-quality metal/plastic build for long-term commercial use |
Specifications Table
| Specification | Details |
|---|---|
| Model | Extron AAP 2CCSWLED2ST |
| Connector Types | 2 × RJ-45 (Cat6), 2 × contact closure switches, LED indicators |
| Mounting Type | Architectural adapter plate (AAP series) |
| Enclosure Compatibility | Extron AAP enclosures, wall boxes, table boxes |
| Material | Metal/plastic (durable finish) |
| Finish | Black or custom (typically black) |
| Dimensions | Standard AAP size (fits 2-gang AAP frames) |
| Weight | Approx. 0.3–0.5 kg |
| Operating Temperature | 0°C to +50°C |
Compare Chart
| Aspect | Extron AAP 2CCSWLED2ST | Extron AAP 2MJSC (HDMI/Analog) | Generic AV Wall Plate/Adapter |
|---|---|---|---|
| Compatibility | Extron AAP enclosures | Extron AAP enclosures | Universal AV connectors |
| Connectors | Dual Cat6 + switches + LEDs | Dual HDMI + stereo mini-jack | Varies (HDMI, VGA, etc.) |
| Mounting Type | Flush table/wall/furniture AAP | Flush table/wall/furniture AAP | Wall/table plate |
| Primary Use | Network/control/status connectivity | HDMI + analog audio | Basic AV pass-through |
| Finish/Match | Black/custom | Black/custom | Varies |
| Best For | AV tables with network & control | Modern HDMI presentations | Simple AV wall plates |
FAQ
- What does the AAP 2CCSWLED2ST do? It serves as a flush-mounted adapter plate with dual Cat6 ports, contact closure switches, and LED indicators for clean network, control, and status connectivity in conference tables, lecterns, or wall boxes.
- Is it customizable? Yes — Extron AAP plates are often built to order with specific connector combinations; this model focuses on dual Cat6, switches, and LEDs.
- How is it installed? It mounts into an Extron AAP enclosure or compatible wall/table box using included hardware; professional AV installation recommended for cable management.
- What are the switches used for? Contact closure switches can trigger presets, mute functions, source selection, or other automation in AV control systems.
- Is it suitable for outdoor use? No — indoor use only; for outdoor or exposed applications, use weatherproof enclosures.
