Extron AAP 135 SMJSC Pass-Through Plate Black
The Extron AAP 135 SMJSC is a triple-space Architectural Adapter Plate combining one 3.5 mm stereo mini jack with captive screw terminals and one S-video female-to-female pass-through connector. It enables secure, reliable routing of unbalanced stereo audio via captive screw connections and direct S-video signal pass-through in AV connectivity setups. This plate is ideal for conference tables, lecterns, podiums, wall boxes, and furniture-mounted installations requiring combined analog audio input/output and legacy S-video routing without external adapters.
Constructed from durable metal with a black finish, the AAP 135 SMJSC mounts seamlessly into Extron AAP-compatible frames and enclosures such as Cable Cubby series, AVEdge, TMK table mounts, SMB surface mounts, EWB wall boxes, and rack/wall applications. It supports clean cable management, reduces clutter, and maintains a professional appearance in architectural AV environments.
Features Chart
| Feature | Benefit |
|---|---|
| Triple-space AAP design | Provides sufficient space for combined audio and video connectivity |
| One 3.5 mm stereo mini jack with captive screw terminals | Enables secure, vibration-resistant unbalanced audio input/output |
| One S-video female-to-female connector | Allows direct pass-through of S-video signals |
| Captive screw audio termination | Ensures stable, reliable analog audio connections |
| Durable metal plate construction | Guarantees long-term reliability in high-traffic installations |
| Black finish | Matches standard Extron AAP hardware for uniform aesthetics |
| Compatible with AAP systems | Installs in Cable Cubby, AVEdge, TMK, SMB, EWB, rack/wall mounts |
| Easy modular installation | Supports straightforward insertion for rapid setup and changes |
Specifications Table
| Specification | Details |
|---|---|
| Module Size | Triple Space |
| Module Type | 3.5 mm stereo mini jack with captive screw + S-video pass-through AAP plate |
| Connectors | 1 x 3.5 mm stereo mini jack with captive screw terminals; 1 x S-video female-to-female |
| Audio | Unbalanced stereo analog pass-through via captive screw |
| Video | S-video pass-through |
| Compatibility | Select Extron interfaces, AAP AV connectivity mounting frames, Cable Cubby series, AVEdge, TMK, SMB, EWB, rack/wall mounts |
| Mounting | Insertion into triple-space AAP positions |
| Materials | Metal construction |
| Finish | Black (standard) |
| Applications | Analog audio + S-video pass-through in architectural AV setups |
Compare Chart
| Aspect | Extron AAP 135 SMJSC | Extron AAP 1 HD F + 1 MJCS | Extron AAP 1 MJCS |
|---|---|---|---|
| Size/Coverage | Triple Space | Single Space | Single Space |
| Connectors | 3.5 mm stereo captive screw + S-video F/F | HDMI F/F + 3.5 mm captive screw | 3.5 mm captive screw |
| Signal Types | Analog audio + S-video | HDMI video/audio + analog audio | Analog audio only |
| Installation | Modular AAP insertion | Modular AAP insertion | Modular AAP insertion |
| Material | Metal | Metal | Metal |
| Finish Options | Black (standard) | Black (standard) | Black (standard) |
| Primary Use | Audio + legacy S-video pass-through | HDMI + secure audio pass-through | Secure analog audio pass-through |
| Customization Level | Moderate (dual signal) | Moderate (dual signal) | Low (single audio) |
FAQ
- What is the AAP 135 SMJSC used for? It provides pass-through for unbalanced stereo audio via captive screw terminals and S-video signals in a triple AAP space.
- Which Extron products is it compatible with? It fits triple-space positions in AAP-compatible frames and enclosures, including Cable Cubby series, AVEdge, TMK table mounts, and wall/rack solutions.
- Why use captive screw terminals for audio? They offer secure, tool-tightened connections that resist vibration and ensure reliable analog audio performance.
- How is installation performed? The metal plate inserts modularly into triple-space AAP positions, typically without specialized tools.
- What material and finish are used? It features durable metal construction with a standard black finish to match Extron AAP hardware aesthetics.
- Can it be used for future modifications? Yes, the design allows easy removal and replacement with other AAP modules or configurations as AV connectivity needs evolve.
